1470009-1 Product Details
Live Product Chat
DVI Receptacles
Always EU R oHS/ELV C om plia nt
(
Sta te m e nt of C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
1470009-1
T E I nternal N umber: 1 4 7 0 0 0 9 - 1
Product Highlights:
l
Size = Slim
l
DVI-D Dual Link Series
l
1 Ports
l
Terminate To Printed C ircuit Board
l
Through Hole C ontact Termination Type
View all Features
Superseded
C ontact Product Information C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Size = Slim
l
Number of Ports = 1
l
Orientation = Right Angle
l
PC B Thickness (Minimum) (mm [in]) = 2.34 [0.092]
l
Number of Positions = 4
Mechanical Attachment:
l
Mount Location = Top
Termination Related Features:
l
Termination Method = Solder
Body Related Features:
l
Series = DVI-D Dual Link
l
Panel Ground = Without
l
PC B Retention Method = Boardlock(s)
l
Shell Plating = Nickel
l
Assembly Process Feature = Without Pick and Place C over
l
Locating Post(s) = Without
Contact Related Features:
l
C ontact Termination Type = Through Hole
l
C ontact Plating, Mating Area, Material
= Bright Tin
Housing Related Features:
l
Housing C olor = Ivory
Industry Standards:
l
RoHS/ELV C ompliance
= RoHS compliant, ELV compliant
l
Lead Free Solder Processes
= Wave solder capable to 240?C , Wave
solder capable to 260?C , Wave solder capable to 265?C
l
RoHS/ELV C ompliance History = Always was RoHS compliant
Conditions for Usage:
l
Terminate To = Printed C ircuit Board
Packaging Related Features:
l
Packaging Method = Tray
Other:
l
Brand = Tyco Electronics
