310-020050-XXX
Configurable Switched Filter Banks
20-7500 MHz, 2 to 7 Channels
Key Features
Passband Frequency 20-7500 MHz
Up to 7 Customizable Channels
Single +5.0 Volt Supply
TTL Selectable
Low Insertion Loss of < 5.0 dB
Fast Switching Speed of < 500 ns
High Rejection > 60 dB typical
Small Form Factor
API Technologies’ configurable switched filter banks (310-020050-XXX series) offer customer-defined passband
frequencies from 20 MHz to 7500 MHz with 2-7 channels. This series features the same high performance of a
custom designed switched filter at a reduced cost. This cost reduction is achieved by using common switch manifolds
and machined parts that are populated with custom filters. The filter banks are ideal for a wide range of applications
were low cost and high performance is required.
Electrical Specifications
Parameter
Frequency Range
Insertion Loss (≥ 35% bandwidth)
Input / Output VSWR (Across Passband)
Passband Flatness
Rejection (3.6:1 Shape Factor)
Switching Speed
Supply Voltage
+5.0 (±0.5) Volt Supply Current
Min
20
-
-
-
55
-
+4.5
Typ
-
5.0
1.8:1
1.0
60
200
+5.0
50
Max
7500
6.5
2.0:1
1.2
-
500
+5.5
75
Units
MHz
dB
Ratio
dB
dBc
ns
VDC
mA
Notes
Narrower bandwidth filters will have more loss
Dependent on filter bandwidth
Rejection level decreases with lower shape factor
50% TTL to 90%/10% RF
Example of 500-6000 MHz Harmonic Rejection Filter Bank
Channel
1
2
3
4
5
6
7
All Off
Passband
Frequency
(MHz)
500-715
715-1015
1015-1450
1450-2070
2070-2950
2950-4210
4210-6000
Center
Relative
50 dBc Rejection
Frequency Bandwidth Bandwidth
Sub-Harmonic
(MHz)
(MHz)
(%)
(MHz)
607.5
210
35.4
10-357
865
300
34.7
10-507
1232.5
435
35.3
10-725
1760
620
35.2
10-1035
2510
880
35.1
10-1475
3580
1260
35.2
10-2105
5105
1790
35.1
10-3000
50 dB Isolation From 10 MHz to 8420 MHz
50 dBc Rejection
Sub-Harmonic
(MHz)
1000-1430
1430-2030
2030-2900
2900-4140
4140-5900
5900-8420
8420-12000
TTL Selection
Code
b2
b1
b0
0
0
1
0
1
0
0
1
1
1
0
0
1
0
1
1
1
0
1
1
1
0
0
0
Revision Date: 4/14/2014
