DUAL-IN-LINE
SOCKETS
SERIES 223...101 • MIL
-
DTL
-
83734 APPROVED, 3 LEVEL WRAPOST • CLOSED FRAME
.015-.025
.010 .018
B
•
Sockets are XY stackable
•
Socket pins feature closed end construction
eliminating any solder wicking problems
3 amps. See page 253 for details
See page 198 for details
.110
.193
.093
.162
•
Hi-Rel, 4- nger BeCu #30 contact is rated at
•
Series 223 uses MM #0038-3 or #0088-3 pins.
.025
SQUARE
.510
•
Insulators are high temperature thermoplastic,
suitable for all soldering operations
Data, see page 264 for details
See page 131 for Insulator Details
•
For Electrical, Mechanical and Environmental
Total number
of pins
A
B
.100
C
Quantity
per tube
ORDERING INFORMATION
Mill-Max Part Number
223-XX-306-41-101000
223-XX-308-41-101000
223-XX-314-41-101000
223-XX-316-41-101000
223-XX-318-41-101000
223-XX-320-41-101000
223-XX-422-41-101000
223-XX-624-41-101000
223-XX-628-41-101000
223-XX-632-41-101000
223-XX-636-41-101000
223-XX-640-41-101000
223-XX-964-41-101000
A
0.3
0.4
0.7
0.8
0.9
1.0
1.1
1.2
1.4
1.6
1.8
2.0
3.2
B
0.3
0.3
0.3
0.3
0.3
0.3
0.4
0.6
0.6
0.6
0.6
0.6
0.9
C
0.4
0.4
0.4
0.4
0.4
0.4
0.5
0.7
0.7
0.7
0.7
0.7
1.0
Military Part Number
M83734/1-YYY
M83734/2-YYY
M83734/3-YYY
M83734/4-YYY
M83734/5-YYY
M83734/13-YYY
M83734/6-YYY
M83734/8-YYY
M83734/7-YYY
M83734/17-YYY
M83734/9-YYY
M83734/10-YYY
M83734/15-YYY
6
8
14
16
18
20
22
24
28
32
36
40
64
67
50
28
25
22
20
18
16
14
12
11
10
6
PAGE 102 | IC SOCKETS / TO SOCKETS
XX=Plating Code
See Below
SEE PAGE 103 FOR COMPLETE MIL DTL 83734 QPL
SPECIFY MILL MAX PLATING CODE XX =
SPECIFY MILL MAX PLATING CODE XX =
32 PIN ONLY YYY =
Sleeve (Pin)
Contact (Clip)
33
010
007
30
µ”
min. Au
30
µ”
min. Au
83
011
008
300
µ”
Sn/Pb
30
µ”
min. Au
88
012
009
300
µ”
Sn/Pb
100
µ”
Sn/Pb
