MIL-DTL-39030/3 SMA Terminations
SV Microwave offers military SMA terminations that are 39030 approved. QPL-39030 parts are
designed and made under DSCC qualifications in order to resist harsh environments within
military applications.
SMA terminations operate under low power and frequency rance up to 19 GHz. These
terminations are used in military applications due to their high performance, compact size,
and outstanding mechanical durability. Built in accordance with MIL-PRF-39030, SMA
terminations can be mated with all connectors that meet these spec mating diameters
regardless of manufacturer.
Features & Benefits
●
Broadband performance up to 19 GHz
●
Nominal impedance up to 95 Ohms
●
Terminations in accordance with MIL-DTL-39030
Applications
●
Military Systems
●
Test and Instrumentation
●
Base Stations
●
Telecom
To more easily illustrate the ordering procedure for SV Microwave QPL Attenuators, part number
M39030/3-08S
is shown below.
M39030
Military designator
Termination
Connector interface series
SMA
Dash number designation on specification sheet
DC to 18.0 GHz female interface with bead chain
S
= Screened
/3
-08
S
or
N
SV Microwave
Non-Screened
N
=
• 2400 CentrePark West Drive • West Palm Beach, Florida 33409 USA
Telephone: 561.840.1800 • Fax: 561.842.6277
www.svmicrowave.com
MIL-DTL-39030/3 SMA Dash numbers and characteristics
Dash
number
N and S
01, 16
02, 17
03, 18
04, 19
05
06
07
08
09, 20
10, 21
11, 22
12, 23
13, 24
14, 25
15, 26
Operating
frequency
(GHz)
DC to 18
DC to 18
DC to 18
DC to 18
DC to 18
DC to 18
DC to 18
DC to 18
DC to 10
DC to 10
DC to 18
2 to 19
2 to 19
2 to 19
4.4 to 5.0
VSWR
(max)
(1.05 +.010f ):1
(1.05 +.010f ):1
(1.05 +.010f ):1
(1.05 +.010f ):1
(1.05 +.010f ):1
(1.05 +.010f ):1
(1.05 +.010f ):1
(1.05 +.010f ):1
1.10:1
2.10:1
1.15:1
1.30:1
1.30:1
1.30:1
(1.025 +.005f ):1
Power handling
capability (max)
Average
(watts)
.5
.5
.5
.5
.5
.5
.5
.5
1.0
2.0
1.0
1.0
.5
1.0
.5
Peak
(watts)
50
50
50
50
50
50
50
50
100
200
100
100
50
100
50
Nominal
characteristic
impedance
(ohms)
50
50
50
50
50
50
50
50
50
95
50
50
50
75
50
Bead
chain
Lock
wire
holes
Sex
Finish
M
M
M
M
F
F
F
F
M
M
M
M
M
M
M
Gold
Passivated
Gold
Passivated
Gold
Passivated
Gold
Passivated
Gold
Gold
Gold
Gold
Gold
Gold
Gold
Specifications
Material
Body and connector
Contact pin and socket
Bead chain and lug
Corrosion-resistant steel per SAE-AMS-QQ-S-763 or
ASTM A484/A484M and ASTM A582
Beryllium copper per ASTM B194, ASTM B196, or ASTM B197
Corrosion-resistant steel or plastic
Gold plated per ASTM B488, type 3, grade C, class 1.27 or Passivated per ASTM
A967 or SAE-AMS-QQ-P-35
ASTM B488, type II, code C, class 1.27, Nickel per SAE-AMS-QQ-N-290, class I
Finish
Body and connector
Contact pin and socket
SV Microwave • 2400 CentrePark West Drive • West Palm Beach, Florida 33409 USA
Telephone: 561.840.1800 • Fax: 561.842.6277
www.svmicrowave.com
MIL-DTL-39030/5 TNC Terminations
SV Microwave manufactures TNC terminations in accordance with MIL-DTL-39030. Military
qualified TNC terminations are rated up to 5 watts average power, constant impedance of
75 Ohms and operate from 0.3 to 12.4 GHz. TNC terminations feature a threaded coupling
that offers extra mating stability.
Features & Benefits
●
Frequency range .03 to 12.4 GHz
●
Nominal impedance 50 and 75 Ohms
●
Terminations in accordance with MIL-DTL-39030
Applications
●
Antennas
●
Cellular
●
Mil-Aero
●
Telecom
●
Base Stations
●
Components
●
Networks
●
Cable Assembly
●
Instrumentation
●
Radar
To more easily illustrate the ordering procedure for SV Microwave QPL Attenuators, part number
M39030/5-03N
is shown below.
M39030
Military designator
Termination
Connector interface series
TNC
/5
-03
S or N
Dash number designation on specification sheet
DC to 10.0 GHz with average power of 2.0 watts and bead chain
S
= Screened
SV Microwave • 2400 CentrePark West Drive • West Palm Beach, Florida 33409 USA
Telephone: 561.840.1800 • Fax: 561.842.6277
www.svmicrowave.com
N
= Non-Screened
MIL-DTL-39030/5 TNC Dash numbers and characteristics
Dash
number
N and S
01
02
03
04
05
06
07
Operating
frequency
(GHz)
DC to 10.0
.06 to .08
DC to 10.0
VSWR
( max )
1.40:1
1.12:1
1.15:1
1.05:1
(DC to 2.4 GHz)
1.20:1
(2.4 to10.0 GHz)
1.10:1
1.15:1
1.15:1
Power handling
capability (max )
Average
Peak
(watts)
(watts)
5.0
.5
2.0
3.5K
.6K
2.5K
Nominal
characteristics
Impedance
(ohms)
50
75
50
Sex
Bead
chain
Male
Male
Male
DC to 10.0
DC to 11.0
.03 to 12.4
.03 to 12.4
5.0
3.0
1.0
1.0
3.5K
1K
1.2K
1.2K
50
51
50
50
Male
Male
Male
Female
Specifications
Material
Body and connector
Contact pin and socket
Bead chain and lug
Corrosion-resistant steel per SAE-AMS-QQ-S-763 or ASTM A484/A484M and
ASTM A582
Beryllium copper per ASTM B194, ASTM B196, or ASTM B197/B197M
Corrosion-resistant steel or plastic
Gold plated per ASTM B488, type 3 class 1.27 or Nickel plated per with
SAE-AMS-QQ-N-290, class 1 or Passivated per ASTM-A967 or SAE-AMS2700
Gold plated ASTM B488, type II, code C, class 1.27
Nickel per SAE-AMS-QQ-N-290, class 1
Finish
Body and connector
Contact pin and socket
SV Microwave • 2400 CentrePark West Drive • West Palm Beach, Florida 33409 USA
Telephone: 561.840.1800 • Fax: 561.842.6277
www.svmicrowave.com
