2.5 Gb/s Electro-Absorption Laser Module
This PowerSource
TM
1916 LMM contains an Avanex DFB laser with monolithically integrated
electro-absorption modulator (EA-ILN). This chip provides much lower dispersion penalties
than a directly modulated DFB, without the complexity of LiNbO
3
external modulators. The
PowerSource
TM
1916 LMM is optimized for regional Metropolitan and long-haul amplified
transmission equipment.
FEATURES
• Very Low Dispersion Penalty over
750 km of Fiber up to 2.7 Gb/s
Operation
• Wavelength Selection According to
ITU-T G.692
• Industry-Standard 14-Pin Butterfly
Package
• High Frequency Butterfly Package
with 50
Ω
RF Impedance
• Low Drive Voltage (≤2 Vpp)
• InGaAsP Monolithically Integrated
DFB Laser and Modulator Chip (EA-
ILM)
OPTICAL CHARACTERISTICS
Table 1
Parameter
Operating Case Temperature
Threshold Current
Operating Current
Sym
Tc
I
th
I
f
Conditions
CW, V
bias
= 0 V, See [4]
WDM Application, CW,
V
bias
= 0 V
Single Channel Application,
CW, V
bias
= 0 V
Min
0
5
55
50
-4
Typ
17
Max
70
35
85
100
+1
2
Units
°C
mA
ma
mA
dBm
V
V
V
dB
APPLICATIONS
• STM-16 and OC-48 DWDM Regional
Metropolitan and Long-Haul
Equipment
• Terminals for Submarine Transmission
Systems
• Size Optimized Transceiver and
Transponder
• Digital CATV Transmission
Optical Output Power
Laser Forward Voltage
Modulator Bias Voltage
Modulator Drive Voltage
Dynamic Extinction Ratio
Emission Wavelength
Laser Chip Temperature
Range for Tunability
Side Mode Suppression
Cut Off Frequency
RF Return Loss
Dispersion Penalty
Rise Time / Fall Time
Monitor Diode Current
Dark Current
TEC Current
TEC Voltage
Thermistor Resistance
Thermistor
β
Coefficient
P
ave
V
f
V
bias
V
mod
DER
λ
Twave
SMSR
S21
S11
ΔS
S
Tr/Tf
I
m
I
d
I
t
V
t
R
TH
β
I
f
, V
mod,
[1] @ I
f
, See [4]
CW, I
f
, V
bias
= 0 V
See [1], [4] @ I
f
See [1], [4] @ I
f
See [1], [4] @ I
f
See [4] @ I
f,
See table 3
-2
0
2
10.5
1529.55
20
1569.59
35
nm
°C
dB
GHz
dB
See [4] @ I
f
See [4] @ I
f
& - 3 dB
DC to 3 GHz
See [1], [2] or [3], [4] @ I
f
See [1], 10%, 90%
See [4] @ I
f
, V = - 5 V
ΔT
= 45 °C, I
f
+20% (EOL),
Tc = 65 °C, V
bias
= - 1 V
ΔT=
45 °C, I
f
+20% (EOL),
Tc = 65 °C, V
bias
= - 1 V
Tsubmount = 25 °C
Tsubmount = 25 °C
40
4
10
2
140
20
500
1500
0.1
1.3
2.5
9.5
3800
3900
10.5
4000
dB
ps
µA
µA
A
V
kΩ
k
K
D2200
All limits start of life Tcase = 25 °C, Tsubmount = Twave for WDM applications and Tsubmount = 25 °C for Single
Channel applications, V = - 5 V, unless otherwise stated.
[1] BER = 10-10; 2.488 Gb/s modulation; 223-1 PRBS; NZR line code; DER
≥
10 .5dB
[2] 7200 ps/nm dispersion, assuming fiber with an average dispersion of 18 ps/nm/km @ 1550 nm
[3] 12800 ps/nm dispersion, assuming fiber with an average dispersion of 18 ps/nm/km @ 1550 nm
[4] For WDM application Tsubmount = Twave. Twave is the chip temperature required to meet target wavelength
(see table 3)
1
PowerSource 1916 LMM
TM
2.5 Gb/s Electro-Absorption Laser Module
MECHANICAL DETAILS
Dimensions
are in mm
Fiber
length 1600 ± 100 mm
(including
optical connector)
Mechanical details for PowerSource
TM
1916 LMM.
PIN-OUT
N˚
1
2
3
4
5
6
7
8
9
10
11
12
13
14
Description
Thermistor
Thermistor
Laser DC Bias (+)
Photodetector Anode (-)
Photodetector Cathode (+)
TEC (+)
TEC (-)
Case Ground
Case Ground
Not Connected
Laser/Modulator Ground
Modulator Anode/50 RF Input
Anode/50Ω
Laser/Modulator Ground
Not Connected
D2200
2
PowerSource 1916 LMM
TM
2.5 Gb/s Electro-Absorption Laser Module
ABSOLUTE MAXIMUM RATINGS
Exposure to absolute maximum rating conditions for extended periods may affect device reliability.
Table 2
Parameter
Min
Max
Unit
Storage Temperature
Operating Case Temperature
Laser Forward Current
Laser Reverse Voltage
Modulator Forward Voltage
Modulator Reverse Voltage
Photodiode Forward Current
Photodiode Reverse Voltage
TEC Voltage
TEC Current
Soldering Temperature (at 260°C)
Fiber Bend Radius
Packing Mounting Screw Torque
-40
0
85
70
150
2
1
5
1
20
2.8
1.4
10
°C
°C
mA
V
V
V
mA
V
V
A
s
mm
N.m
25
0.2
QUALIFICATION, RELIABILITY AND STANDARDS
Avanex policy for all products is to carry out a complete qualification program. This qualification is based on manufacturers’ qualification in
agreement with Telcordia GR-468-Core (generic reliability assurance requirements for optoelectronic devices used in telecommunications
equipment - central office level), MIL STD 883E (Test method and procedures for microelectronics) and following the standards ITU-T G652
and G-691. All products pass strict tests before shipping. Failure criteria are defined during the product qualification process.
DEVICE MARKING
The device shall be legibly and permanently marked with the following information:
Avanex logo
Product family name: 1916 LMM
Product code: 3CN number (see Ordering Information section)
Serial number
SHIPMENT PACKING
Each device is individually packed in an anti-static container and in such a manner as to prevent damage in transit.
The packing shall include the following information:
Avanex logo
Product family name: PowerSource
TM
1916 LMM
Product code: 3CN number (see Ordering Information section)
Serial number
Hazard warning label (ESD)
Laser Safety Class Label
D2200
3
PowerSource 1916 LMM
TM
2.5 Gb/s Electro-Absorption Laser Module
DELIVERABLE DATA
The following data shall be supplied with each device for WDM and Single Channel applications:
L(I) / V(I) / I
m
(I) curves from I
f
= 0 to 100 mA @ V
on
= 0 V
Values for R
TH
, Twave, I
f
, I
m
, V
on
(On-state voltage [0 data]), V
bias
(bias voltage), V
mod
, DER, Pave, S0 (received optical power without fiber) and
ΔS
@ I
f
and Twave
For Single Channel applications:
Plot of SER vs Vmod over the range 0 V to –3 V @ I
f
= 80 mA and Tc = Tsubmount = 25 °C
For WDM applications:
Plot of SER vs V
mod
over the range 0 V to –3 V @ I
f
, Twave and Tc = 25 °C
LASER SAFETY INFORMATION AND HANDLING
Take appropriate precautions to prevent undue exposure to naked eye. This product is classified Class 3A Laser Product according to
IEC-60825-1. FDA/CDRH Class IIIb laser product. All versions are Class IIIb laser products per CDRH, 21 CFR 1040 Laser. Safety require-
ments under accession number 9622256-00. This product is sensitive to electrostatic discharge and should not be handled except at a static
free workstation. Take precautions to prevent ESD; use wrist straps, grounded work surfaces and recognized anti-static techniques when
handling the PowerSource
TM
1916 LMM module. Handle the laser module by its package only, never hold it by its pigtail. Care should be
taken to avoid supply transient and over voltage. Over voltage above the maximum specified in absolute maximum rating section may cause
permanent damage to the device.
ORDERING INFORMATION
PowerSource
TM
1916 LMM
Application
Single Channel
WDM
Single Channel
WDM
Single Channel
WDM
Single Channel
WDM
Single Channel
WDM
Single Channel
WDM
12800 ps/nm
12800 ps/nm
12800 ps/nm
12800 ps/nm
12800 ps/nm
12800 ps/nm
7200 ps/nm
7200 ps/nm
7200 ps/nm
7200 ps/nm
7200 ps/nm
7200 ps/nm
Part Number
3CN00760AA
3CN00760##
3CN00761AA
3CN00761##
3CN00762AA
3CN00762##
3CN00763AA
3CN00763##
3CN00764AA
3CN00764##
3CN00765AA
3CN00765##
Optical Connector
FC/PC
FC/PC
LC/PC
LC/PC
SC/PC
SC/PC
FC/PC
FC/PC
LC/PC
LC/PC
SC/PC
SC/PC
## Defines the wavelength according to the Table 3 on the right. Customized versions are available
for large quantities.
D2200
4
PowerSource 1916 LMM
TM
2.5 Gb/s Electro-Absorption Laser Module
ORDERING INFORMATION
Table 3
λ
(nm)
1529.55
1530.33
1531.12
1531.90
1532.68
1533.47
1534.25
1535.04
1535.82
1536.61
1537.40
1538.19
1538.98
1539.77
1540.56
1541.35
1542.14
1542.94
1543.73
1544.53
1545.32
1546.12
1546.92
1547.72
1548.51
1549.32
THz
196.00
195.90
195.80
195.70
195.60
195.50
195.40
195.30
195.20
195.10
195.00
194.90
194.80
194.70
194.60
194.50
194.40
194.30
194.20
194.10
194.00
193.90
193.80
193.70
193.60
193.50
Code ##
BP
BR
BT
BV
BX
BZ
CB
CD
CF
CH
CK
CM
CP
CR
CT
CV
CX
CZ
DB
DD
DF
DH
DK
DM
DP
DR
λ
(nm)
1550.12
1550.92
1551.72
1552.52
1553.33
1554.12
1554.94
1555.75
1556.55
1557.36
1558.17
1558.98
1559.79
1560.61
1561.42
1562.23
1563.05
1563.86
1564.68
1565.49
1566.31
1567.13
1567.95
1568.77
1569.59
THz
193.40
193.30
193.20
193.10
193.00
192.90
192.80
192.70
192.60
192.50
192.40
192.30
192.20
192.10
192.00
191.90
191.80
191.70
191.60
191.50
191.40
191.30
191.20
191.10
191.00
Code ##
DT
DV
DX
DZ
EB
ED
EF
EH
EK
EM
EP
ER
ET
EV
EX
EZ
FB
FD
FF
FH
FK
FM
FP
FS
FU
All wavelengths referenced to vacuum, Twave for WDM applications.
www.avanex.com
Nasdaq: AVNX
