F-215 (Rev 31DEC15)
TSM–116–02–S–DV–LC
TSM–121–01–T–SV
(2.54 mm) .100"
SMT .025" SQ POST HEADER
Mates with:
SSW, SSQ, SSM, BSW,
ESW, ESQ, BCS, SLW,
CES, HLE, IDSS, IDSD,
SMSD, SMSS
TSM
1
NO. PINS
PER ROW
LEAD
STYLE
PLATING
OPTION
ROW
OPTION
SPECIFICATIONS
For complete specifications
and recommended PCB layouts
see www.samtec.com?TSM
Insulator Material:
Black Liquid
Crystal Polymer
Terminal Material:
Phosphor Bronze
Plating:
Au or Sn over
50 µ" (1.27 µm) Ni
Operating Temp Range:
-55 °C to +105 °C with Tin;
-55 °C to +125 °C with Gold
Voltage Rating:
475 VAC -SV/-DV mated with
BCS or SSM
RoHS Compliant:
Yes
Lead–Free Solderable:
Yes
-DH/-SH Lead Coplanarity:
(0.15 mm) .006" max (02-36)
-DV/-SV Lead Coplanarity:
(0.10 mm) .004" max (02-05)
(0.13 mm) .005" max (06-10)
(0.15 mm) .006" max (11-36)
MATES
TSM/SSW
TSM/SSM
TSM/HLE
CURRENT RATING
(PER PIN)
4.9 A
5.4 A
4.1 A
02
thru
36
.230" (5.84
–01
= (Mates withmm) Post Height IDSS, IDSD)
SSW, BCS, SSM,
= Gold flash on post,
Matte Tin on tail
–F
–L
= 10 µ" (0,25 µm) Gold on post,
Matte Tin on tail
Post
Height
–02
= .320" (8.13 mm) Post Height
(Mates with SSM -DH)
(10.67
Height
–03
= .420"Bottom mm) PostPass Through)
(For
Mount &
= 30 µ" (0,76 µm) Gold on post,
Matte Tin on tail
–S
–T
–04
= .120" (3.05 mm) Post Height
(Mates with SLW, CES, HLE)
–SV
–DV
= Matte Tin
= Single Row Vertical Pin
(2.54) .100 x No. of positions
(2.54)
.100
(2.54)
.100
01
(0.64)
.025
SQ
(1.14)
.045
REF
Post
Height
(2.54)
.100
(3.81)
.150
= Double Row Vertical Pin
02
(2.54) .100 x No. of positions
72
(2.54) (5.08)
.100 .200
01
(2.54) .100
71
(0.64) .025 SQ
Post
Height
(2.54)
.100 (3.81)
.150
(2.79)
.110
–LC Option
36
(1.14)
.045
REF
1 PIN POWERED PER ROW
(2.54)
.100
–A Option
(1.58) .062 DIA
(No. of positions -2) x (2.54) .100)
RECOGNITIONS
For complete scope
of recognitions see
www.samtec.com/quality
= Single Row
Horizontal Pin
–SH
= Double Row Horizontal Pin
(Style –01, –02 or –03 only)
Optional
Alignment
Pin (–A)
(2.54) .100 x No. of positions
02
72
(2.54)
.100
01
(1.78)
.070 (1.40)
.055
(1.58)
.062 DIA(2)
(No. of positions x
(2.54) .100) – (5.08) .200
(0.64)
.025
71
(6.10)
.240
–DH
FILE NO: 090871_0_000
APPLICATIONS
SSM
TSM
(1.40)
.055
(1.78)
.070
36
(2.54) .100 x No. of positions
01
(3.05)
.120
Optional Alignment Pin (–A)
(1.58)
.062
DIA
(2)
(No. of positions x (2.54) .100)
– (5.08) .200
(2.54)
.100
Post
Height
(0.64)
.025
SQ
HORIZONTAL
(2.54)
.100
–01= (4.57) .180
–02, –03, –04 = (4.82) .190
(2.03)
.080
Post
Height
(2.54)
.100
(7.87)
.310
(3.68)
.145
Note:
Some lengths,
styles and options are
non-standard, non-returnable.
(1.16) .046
WWW.SAMTEC.COM
Due to technical progress, all designs, specifications and components are subject to change without notice.
TSM–115–01–T–SH–A
TSM–110–01–T–DV
TSM–126–02–L–DH–K
TSM SERIES
OTHER OPTIONS
= Alignment Pin
metal or plastic
at Samtec discretion
(Not available
with –TM or –MT)
(02 positions min.)
(Not available with –LC)
–A
= (6.50 mm) .256" DIA
Polyimide Film
Pick & Place Pad
(–SH: 4 positions
minimum without –TR;
2 & 3 positions
available with –TR)
(–DH: 4 positions
minimum
without –TR)
–K
= Plastic Pick & Place Pad
(–DV: 4 positions minimum
without –TR; 2 & 3 positions
available with –TR)
(–SH: 4 positions
minimum without –TR;
2 & 3 positions
available with –TR)
(–DH: 5 positions
minimum without –TR)
(–SV: 4 positions
minimum without –TR;
2 & 3 positions
available with –TR)
(6.86)
.270
–P
(10.16)
.400
x
(4.06)
.160
–SV
(6.35)
.250
x
(7.62)
.300
(13.27)
.050
= Tape & Reel Packaging
–SV = 02-22 positions
–DV = 02-28 positions
–SH = 02-30 positions
–DH = 02-29 positions
Not available with –MT or –TM
–TR
= Locking Clip
(Not available with –TM)
(3 positions min.)
(Not available with –A)
(Manual placement
required)
–LC
–“XXX”
= Polarized
Position
–SH & –DH
ABILITY
No to
Minimum o oling charges.
a full ree rder is the lesse
Order any l quantity or 125 pier of
ce
qu
In-house d antity above minimus.
esign, man
m
ufacture. .
Quick turn
-around.
Call Sa
mtec
and orderi for specifications
ng informa
tion.
TAPE & R
EEL AVAIL
= Triple Row Vertical Mixed Technology (Style –01 only)
–TM
02 thru 30 positions only
(2.54) .100 X No. of positions
ALSO AVAILABLE
(MOQ Required)
• Edge Mount and Locking Clips for –SV
• Solder Locks for –DH and Shrouds for –DV
• Other platings
Contact Samtec.
(11.43)
.450
03
90
(2.54)
.100 (7.62)
.300
Post
Height
01
(2.54) .100
88
(3.56)
(0.64) .025 SQ .140
= Mixed Technology Pin
(Style –01, –02 or –03 only)
–MT
B o a rd
S t a ck i n g
SO C KE T
PR O FI LE
(2.54)
.100
(2.54) .100 x No. of positions
02
72
(2.54) (6.10)
.100 .240
01
(1.78)
.070
(0.64)
.025
(2.54)
.100
(7.87)
.310
(1.16) .046
(2.54)
.100
(1.52)
.060
71
BO A RD
SP A C E
PO ST
Post
Height
O V ER A LL
PI N
(O A L)
ST A C KE R
HE IG H T
WWW.SAMTEC.COM
Due to technical progress, all designs, specifications and components are subject to change without notice.
