210784-6 Product Details
Live Product Chat
PGA Sockets
Not re vie we d for R oHS C om pliance
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
210784-6
T E I nternal N umber: 2 1 0 7 8 4 - 6
Product Highlights:
l
Very Low Insertion Force
l
68 Positions
l
PC B Mount Style = Through Hole
l
Grid Size = 11x11
l
Grid Spacing = Standard: 2.54 x 2.54 mm
View all Features
Obsolete
C ontact Product Information C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Insertion Force
= Very Low
l
Number of Positions
= 68
l
PC B Mount Style = Through Hole
l
Grid Size
= 11x11
l
Grid Spacing (mm [in])
= Standard: 2.54 x 2.54 [.100 x .100]
l
C hip C ompatibility
= Other
l
Frame Style
= C losed
l
Sleeve Material = Brass
l
Heat Sink Attachment
= Without
l
Profile
= Standard
l
Leg Style = Standard
Termination Related Features:
l
Termination Post Length (mm [in])
= 2.84 [0.112]
l
Socket Identifier = None
l
Solder Tail C ontact Plating = Tin-Lead over Nickel
Body Related Features:
l
Assembly Process Feature = None
l
Socket Overall Height (mm [in]) = 4.46 [0.176]
Contact Related Features:
l
C ontact Style
= Stamped + Formed
l
C ontact Base Material
= Beryllium C opper
l
C ontact Plating, Mating Area, Material = Gold Flash
l
Sleeve Plating = Tin-Lead (200) over nickel
Housing Related Features:
l
Housing C olor = Black
l
Housing Material = Thermoplastic - GF
l
Housing Flammability Rating = UL 94V-0
l
Housing Material Temperature = High
Industry Standards:
l
RoHS/ELV C ompliance
= Not reviewed for ELV/RoHS compliance
l
Lead Free Solder Processes
= Not reviewed for lead free solder
process
Operation/Application:
l
Application
= Production
Packaging Related Features:
l
Packaging Method = Tube
Other:
l
Brand = AMP
