206063-2 Product Details
Subminiature D Pins/Sockets for
MIL-C-24308 and MIL-C-39029
Alw ays EU RoHS/ELV Compliant
(
Statement of
Compliance
)
Quick Links
Check Pricing & Availability
Search for Tooling
Product Feature Selector
Contact Us About This Product
Product Highlights:
206063-2
(311P407-3P-B-15)
TE Internal Number: 206063-2
Active
View 3D PDF
Connector
Product Series = 90
Connector Style = Plug
Accepts Contact Gender = Pin
Density = High
View all Features
Add to My Part List
Request Sample
Find Similar Products
Buy Product
Documentation & Additional Information
Product Drawings:
PLUG, PIN CONTACTS HI-DENSITY HDD CONNECTOR SIZE 3 (...
(PDF, English)
Catalog Pages/Data Sheets:
None Available
Product Specifications:
None Available
Application Specifications:
None Available
Instruction Sheets:
AMPLIMITE* NON-MAGNETIC HIGH DENISTY 22 (HD-22) CONN...
(PDF, English)
CAD Files:
(CAD
Format & Compression Information)
2D Drawing
(DXF, Version AP)
3D Model
(IGES, Version AP)
3D Model
(STEP, Version AP)
Additional Information:
Product Line Information
Additional Product Images:
Insert Arrangement
Related Products:
Tooling
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
Product Type
= Connector
Product Series
= 90
Shell Size
= 3
Shell Material
= Brass
Termination Method to Wire/Cable
= Crimp
Mounting Hole Diameter (mm [in]) = 3.91 [.154]
Body Features:
Number of Positions
= 44
Blindmate
= No
Non-Magnetic
= Yes
Rear Grommet
= No
Power/Signal/Coax Combination
= No
Shell Plating
= Gold
Mount Style = Mounting Holes
Retention Clip Material = Copper Alloy
Contact Features:
Accepts Contact Gender = Pin
Contact Size
= 22
Contact Style
= Crimp Snap-in
Other:
Brand = AMP
Configuration Features:
Density
= High
Industry Standards:
Government/Industry Qualification = Yes
Government/Industry Part Number = 311P407-3P-B-15
RoHS/ELV Compliance
= RoHS compliant, ELV compliant
Lead Free Solder Processes
= Wave solder capable to 240°C,
Wave solder capable to 260°C, Wave solder capable to 265°C
RoHS/ELV Compliance History = Always was RoHS compliant
Conditions for Usage:
Applies To = Wire/Cable
Housing Features:
Connector Style = Plug
