CREAT BY ART
Pb
RoHS
COMPLIANCE
2.0 AMPS. Silicon Rectifiers
DO-15
2A01 - 2A07
Features
High efficiency, Low VF
High current capability
High reliability
High surge current capability
Low power loss
Green compound with suffix "G" on packing
code & prefix "G" on datecode
Mechanical Data
Cases: Molded plastic
Epoxy: UL 94V-0 rate flame retardant
Lead: Pure tin plated, lead free, solderable per
MIL-STD-202, Method 208 guaranteed
Polarity: Color band denotes cathode
High temperature soldering guaranteed: 260℃/10s
/.375", (9.5mm) lead lengths at 5 lbs, (2.3kg) tension
Weight: 0.40 grams
Dimensions in inches and (millimeters)
Marking Diagram
2A0X
G
Y
WW
= Specific Device Code
= Green Compound
= Year
= Work Week
Maximum Ratings and Electrical Characteristics
Rating at 25
℃
ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%
Type Number
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
.375"(9.5mm) Lead Length @T
A
=75℃
Peak Forward Surge Current, 8.3 ms Single Half Sine-wave
Superimposed on Rated Load (JEDEC method)
Maximum Instantaneous Forward Voltage (Note 1)
@2A
Maximum DC Reverse Current at
Rated DC Blocking Voltage
@ T
A
=25
℃
@ T
A
=125℃
Symbol
2A01 2A02
2A03
200
140
200
2A04
400
280
400
2
60
1.0
5
50
30
20
60
2A05
600
420
600
2A06
800
560
800
2A07
1000
700
1000
Units
V
V
V
A
A
V
uA
uA
uA
pF
O
V
RRM
V
RMS
V
DC
I
F(AV)
I
FSM
V
F
I
R
I
R(AV)
Cj
R
θJA
T
J
T
STG
50
35
50
100
70
100
Maximum Full Load Reverse Current, Full Cycle Average
.375"(9.5mm) Lead Length @T
A
=75℃
Typical Junction Capacitance (Note 2)
Typical Thermal Resistance (Note 3)
Operating Temperature Range
Storage Temperature Range
Note1: Pulse Test with PW=300 usec, 1% Duty Cycle
C/W
O
O
- 65 to + 150
- 65 to + 150
C
C
Note2: Measured at 1 MHz and Applied Reverse Voltage of 4.0V D.C.
Note3: Mount on Cu-Pad Size 10mm × 10mm on P.C.B.
Version:C10
RATINGS AND CHARACTERISTIC CURVES (2A01 THRU 2A07)
FIG.1- MAXMUM FORWARD CURRENT DERATING
CURVE
2.5
AVERAGE FORWARD
RECTIFIED CURRENT (A)
2
1.5
1
0.5
0
0
25
50
75
100
125
o
FIG. 2- TYPICAL REVERSE CHARACTERISTICS
10
INSTANTANEOUS REVERSE CURRENT (uA)
RESISTIVE OR
INDUCTIVE LOAD
1
TA=125℃
0.1
150
175
AMBIENT TEMPERATURE( C)
TA=25℃
FIG. 3- MAXIMUM NON-REPETITIVE FORWARD
SURGE CURRENT
100
PEAK FORWARD SURGE
CURRENT(A)
80
60
40
20
0
1
10
NUMBER OF CYCLES AT 60 Hz
100
0.01
0
20
40
60
80
100
120
140
PERCENT OF RATED PEAK REVERSE VOLTAGE (%)
FIG. 5- TYPICAL FORWARD CHARACTERISTICS
100
FIG. 4- TYPICAL JUNCTION CAPACITANCE
1000
JUNCTION CAPACITANCE(pF)
INSTANTANEOUS FORWARD CURRENT
(A)
10
100
TA=25℃
1
10
0.1
1
1
10
REVERSE VOLTAGE (V)
100
0.01
0.6
0.7
0.8
0.9
1
1.1
1.2
1.3
FORWARD VOLTAGE, VOLTS
1.4
1.5
Version:C10
