DMM1W4P7K: DescriptionFilm Capacitor, Polyester, 100V, 10% +Tol, 10% -Tol, 4.7uF, Through Hole Mount, RADIAL LEADED; CategoryPassive components capacitor; File Size3MB，2 Pages; ManufacturerCDE [ CORNELL DUBILIER ELECTRONICS ]

Download Datasheet Parametric View All

DMM1W4P7K Overview

Film Capacitor, Polyester, 100V, 10% +Tol, 10% -Tol, 4.7uF, Through Hole Mount, RADIAL LEADED

DMM1W4P7K Parametric

Parameter Name	Attribute value
Objectid	1938915268
package instruction	,
Reach Compliance Code	unknown
ECCN code	EAR99
capacitance	4.7 µF
Capacitor type	FILM CAPACITOR
dielectric materials	POLYESTER
Installation features	THROUGH HOLE MOUNT
negative tolerance	10%
Number of terminals	2
Maximum operating temperature	85 °C
Minimum operating temperature	-55 °C
Package shape	RECTANGULAR PACKAGE
positive tolerance	10%
Rated (AC) voltage (URac)	65 V
Rated (DC) voltage (URdc)	100 V
surface mount	NO
Terminal shape	WIRE

Preview

Download Datasheet

View All

Type DMM

Polyester Film Capacitors

Metallized

Radial Leads

DC Applications

Self Healing

Type DMM

radial-leaded, metallized polyester

capacitors have non-inductive windings and multi-

layered epoxy resin enhancing performance

characteristics and humidity resistance. Self healing

characteristics prevent permanent shorting due to

high-voltage transients. When long life and perfor-

mance stability are critical,

Type DMM

is the ideal

solution.

Specifications

Voltage Range:

100-630 Vdc (65-250 Vac,

60 Hz)

Dielectric Strength:

150% (1 minute)

Capacitance Range:

.01-10 µF

Dissipation Factor:

1% Max. (25 °C, 1kHz)

Capacitance Tolerance:

±10% (K) standard

Insulation Resistance:

5,000 M x µF

±5% (J) optional

10,000 M Min.

Operating Temperature Range:–55

°C to 125 °C*

Life Test:

1,000 Hours at 85°C at

*Full-rated voltage at 85°C–Derate linearly to 50%-rated voltage at 125°C

125% Rated Voltage

Pulse Capability

Body Length

Rated

Volts

100

250

400

630

.550

20

28

46

72

.710

.940

1.024-1.220

1.380

dV/dt—volts per microsecond, maximum

12

8

6

17

12

8

7

28

15

14

12

43

28

21

17

.06

MAX.

(1.5)

.787

MIN.

(20)

S

d

L

T

H

NOTE:

Other capacitance values, sizes and performance specifications are

available. Contact us.

Ratings and Dimensions

Cap.

(µF)

.150

.220

.330

.470

.680

1.000

1.500

2.200

3.300

4.700

6.800

10.000

.068

.100

.150

.220

.330

.470

.680

Normally Stocked

T Max.

Inches (mm)

.236

.276

.354

.433

.453

.512

.630

.709

.236

.276

.315

.354

(6.0)

(7.0)

(9.0)

(11.0)

(11.5)

(13.0)

(16.0)

(18.0)

(6.0)

(7.0)

(8.0)

(9.0)

Catalog

Part Number

DMM1P15K

DMM1P22K

DMM1P33K

DMM1P47K

DMM1P68K

DMM1W1K

DMM1W1P5K

DMM1W2P2K

DMM1W3P3K

DMM1W4P7K

DMM1W6P8K

DMM1W10K

DMM2S68K

DMM2P1K

DMM2P15K

DMM2P22K

DMM2P33K

DMM2P47K

DMM2P68K

H Max.

Inches (mm)

L Max.

Inches (mm)

.551

.709

1.024

1.221

.551

.709

1.024

(14.0)

(18.0)

(26.0)

(31.0)

(14.0)

(18.0)

(26.0)

S

±.06

(±1.5)

Inches (mm)

.394

.591

.886

1.083

.390

.590

.886

(10.0)

(15.0)

(22.5)

(27.5)

(10.0)

(15.0)

(22.5)

d

Inches (mm)

.024

.032

.024

.032

(.6)

(.8)

(.6)

(.8)

100 Vdc (65 Vac)

.394 (10.0)

.414 (10.5)

.473 (12.0)

.551 (14.0)

.591 (15.0)

.670 (17.0)

.788 (20.0)

.906 (23.0)

1.024 (26.0)

1.221 (31.0)

250 Vdc (160 Vac)

.394 (10.0)

.433 (11.0)

.473 (12.0)

.512 (13.0)

.591 (15.0)

.610 (15.5)

CDE Cornell Dubilier•1605 E. Rodney French Blvd.•New Bedford, MA 02744•Ph: (508)996-8561•Fax: (508)996-3830• www.cde.com
