Data Sheet No. PD60284 revC
IR3314(S)PbF
PROGRAMMABLE CURRENT SENSE HIGH SIDE SWITCH
Features
•
•
•
•
•
•
•
•
Load current feedback
Programmable over current shutdown
Active clamp
ESD protection
Input referenced to Vcc
Over temperature shutdown
Reverse battery protection
Lead-Free
Product Summary
Rds(on)
12 mΩ max.
Vcc op.
6 to 32V
Current Ratio
5300
Prog. Ishutdown 6 to 58A
Vclamp
40V
Packages
Description
The IR3314(S)PbF is a fully protected 4 terminals high
side switch. The input signal is referenced to Vcc. When
the input voltage Vcc - Vin is higher than the specified
threshold, the output power Mosfet is turned on. When the
Vcc - Vin is lower than the specified Vil threshold, the
output Mosfet is turned off. A current proportional to the
power Mosfet current is sourced to the Ifb pin. Over
current shutdown occurs when Vst-Vin > 4.5V. The current
shutdown threshold is adjusted by selecting the proper
RIfb. Either over current and over temperature latches off
the switch. The device is reset by pulling the input pin
high. Other integrated protections (ESD, reverse battery,
active clamp) make the switch very rugged in automotive
environment.
TO-220
IR3314PbF
D²Pak
Pin 4 and 5 fused
IR3314SPbF
Typical Connection
Vcc
IN
Ifb
Current feeback
Input
On
Off
IR3314
Battery
Out
10k
Rifb
Logic
Ground
Power
Ground
Load
www.irf.com
1
IR3314(S)PbF
Absolute Maximum Ratings
Absolute maximum ratings indicate sustained limits beyond which damage to the device may occur. All voltage parameters
are referenced to Vcc lead. (Tambient=25°C unless otherwise specified).
Symbol
Parameter
Min.
-16
-16
-16
-0.3
⎯
⎯
⎯
⎯
⎯
Max.
37
32
33
37
2.8
100
2
4
0.5
150
⎯
Units
V
Vcc-Vin
Maximum Vcc voltage
Vcc-Vin cont. Maximum continuous Vcc voltage
Vcc-Vfb
Maximum Ifb voltage
Vcc-Vout
Maximum output voltage
Ids cont.
Maximum body diode continuous current Rth=60°C/W (1)
Ids pulsed
Maximum body diode pulsed current (1)
Pd
Maximum power dissipation Rth=60°C/W
ESD1
Electrostatic discharge voltage (Human body) C=100pF, R=1500Ω
ESD2
Electrostatic discharge voltage (Machine Model) C=200pF,R=0Ω
Tj max.
Max. storage & operating temperature junction temperature
Min Rfb
Minimum on the resistor on Ifb pin
Ifb max.
Max. Ifb current
(1) Limited by junction temperature. Pulsed is also limited by wiring
A
W
kV
°C
kΩ
mA
-40
0.3
-50
50
Thermal Characteristics
Symbol
Rth1
Rth2
Rth3
Parameter
Thermal resistance junction to ambient D²-Pak Std footprint
Thermal resistance junction to case D²-Pak
Thermal resistance junction to case TO-220
Typ.
60
1.2
1.2
Max.
⎯
⎯
⎯
Units
°C/W
Recommended Operating Conditions
These values are given for a quick design. For operation outside these conditions, please consult the application notes.
Symbol
Iout
Parameter
Min.
⎯
⎯
Max.
18
5
3.5
⎯
Units
A
kΩ
ms
Hz
Continuous output current
Tambient=85°C, Rth=5°C/W, Tj=125°C
Tambient=85°C, Rth=60°C/W, Tj=125°C
Rifb
Recommended Ifb resistor (2)(3)
Pulse min.
Minimum turn-on pulse width
Fmax.
Maximum operating frequency
2) If Rifb is too low, the device can be damaged.
3) If Rifb is too high, the device may not switch on.
0.5
1
⎯
200
www.irf.com
2
IR3314(S)PbF
Protection Characteristics
Tj=25°C, Rifb=500 to 3.5kΩ
Symbol
Vifb-Vin@Isd
Tsd
OV
Isdf
Isd_1k
Treset
Min. pulse
WAIT
Rds(on) rev.
Parameter
Over-current shutdown threshold
Over temperature threshold
Over voltage protection (not latched)
Fixed over current shutdown
Programmable over current shutdown 1k
Time to reset protection
Min. pulse width (no WAIT state)
WAIT function timer
Reverse battery On state resistance
Min.
4
⎯
Typ.
4.7
165
35
72
24
50
400
1
10
Max.
5.6
⎯
Units
V
°C
V
A
µs
ms
mΩ
Test Conditions
See fig. 5
Vifb<Vifb-Vin@Isd
Rifb=1kΩ
See fig. 5
See fig. 4 and 5
Vcc-Vin=-14V,
Iout=20A
33
58
18.8
⎯
200
0.4
6
39
90
30
500
1200
2
18
Static Electrical Characteristics
Tj=25°C, Vcc=14V (unless otherwise specified)
Symbol
Vcc op.
Icc off
Iin, on
Vih
Vil
Vhyst
Iout
Parameter
Operating Voltage range
Supply leakage current
On state IN positive current
High level Input threshold voltage (4)
Low level Input threshold voltage (4)
Input hysteresis Vih-Vil
Drain to source leakage current
Min.
6
⎯
Typ.
⎯
Max.
32
5
6
6.2
5.8
1
5
Units
V
µA
mA
V
µA
Test Conditions
Vin=Vcc, Vcc-Vout=14V,
Vcc-Vifb=14V
Vcc-Vin=14V
1.5
3
5.4
4.9
0.4
1.2
1.5
⎯
4
0.2
⎯
Vin=Vcc, Vcc-Vifb=0V,
Vcc-Vout=14V
Rds(on)
On state resistance (5) Tj=25°C
5
9
12
Iout=20A, Vcc-Vin=14V
On state resistance (5) Tj=25°C
5
9.5
17
Iout=15A, Vcc-Vin=6V
mΩ
On state resistance (5) Tj=150°C
10
17
23
Iout=20A, Vcc-Vin=14V
⎯
Iout=50mA
V clamp1
Vcc to Vout clamp voltage 1
36
39
V
⎯
40
43
Iout=20A
V clamp2
Vcc to Vout clamp voltage 2
(4) Input thresholds are measured directly between the input pin and the tab. Any parasitic resistance in common between
the load current path and the input signal path can significantly affect the thresholds.
(5) Rdson is measured between the tab and the Out pin, 5mm away from the package.
Switching Electrical Characteristics
Vcc=14V, Resistive load=0.5Ω, Tj=25°C
Symbol
Tdon
Tr1
Tr2
Eon
Tdoff
Tf
Eoff
Parameter
Turn on delay time to 10% Vcc
Rise time to Vcc-Vout=5V
Rise time to Vcc-Vout=0.1Vcc
Turn on energy
Turn off delay time
Fall time to Vout=10% of Vcc
Turn off energy
Min.
5
2
7
⎯
Typ.
21
8
27
4.5
55
20
2
Max.
55
20
70
⎯
Units
µs
mJ
µs
mJ
Test Conditions
See figure 2
13
5
⎯
140
55
⎯
www.irf.com
3
IR3314(S)PbF
Current Sense Characteristics
Symbol
Ratio
Ratio_TC
Offset
Trst
Parameter
I Load/Iifb current ratio
I Load/Iifb variation aver temperature
Load current diagnostic offset
Ifb response time (low signal)
Min.
4,500
-5
-0.18
⎯
Typ.
5,300
⎯
Max.
6,300
+5
+0.15
⎯
Units
⎯
Test Conditions
Tj=25°C, Rfb=500Ω,
Iout=40A
Tj=-40°C to 150°C
Iout=2A
90% of the Iout step
0
1
%
A
µs
Functional Block Diagram
All values are typical
VCC
Charge
Pump
Driver
On/Off
Fast turn-off
38V
43V
43V
3mA
+
-
+
-
Reset
Set
35V
Q
43V
Latch
Wait
timer
1 ms
4.7V
timer
400µs
80Ω
-
+
Iout > 72A
Tj > 165°C
Min. Pulse
-
+
reverse
battery
protection
IN
IFB OUT
www.irf.com
4
IR3314(S)PbF
Lead Assignments
3- Vcc
3- Vcc
1- In
2- Ifb
3- Vcc (tab)
4- NC
5- Out
1 2 3 4 5
1- In
2- Ifb
3- Vcc (tab)
4- Out
5- Out
12
45
D²Pak
TO220
90%
Vcc-Vin
Vih
Vil
Vhyst
IN
Icc
Vcc
IR3314
Iin
Ifb
Out
Vcc-Vout
Vclamp1
Vclamp2
Vcc-Vin
10%
Tr-in
90%
Vcc-5V
Vout
10%
Td on
Td off
Tr1
Tr2
Tf
Ifb
Iout
Isd
Figure 1 – Voltages and current definitions
Figure 2 – Switching time definitions
www.irf.com
5
