39-00-0048 (Cut Strip) datasheet, PDF

Datasheet> All Categories > The connector> 39-00-0048 (Cut Strip)

39-00-0048 (Cut Strip): Descriptionheaders & wire housings MN-FT term 22-28g M cut strip of 100; CategoryThe connector; File Size89KB，2 Pages; ManufacturerMolex; Websitehttps://www.molex.com/molex/home; Environmental Compliance

Download Datasheet Parametric Compare View All

39-00-0048 (Cut Strip) Overview

headers & wire housings MN-FT term 22-28g M cut strip of 100

39-00-0048 (Cut Strip) Parametric

Parameter Name	Attribute value
Manufacture	Molex
Product Category	Headers & Wire Housings
RoHS	Yes
Pitch	-
Number of Positions	-
Number of Rows	-
Contact Gende	Pin (Male)
Contact Plating	Ti
Housing Material	-
Termination Style	Crim
Mounting Style	-
Mounting Angle	-
Contact Material	Brass
Latching Type	-
Mating Post Length	-
Row Spacing	-
Factory Pack Quantity	100
Termination Post Length	-
Voltage Rating	600 V
Wire Gauge	28-22

Preview

Download Datasheet

View All

This document was generated on 04/03/2014

PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION

Part Number:

Status:

Overview:

Description:

39-00-0048

Active

Mini-Fit Jr.™ Power Connectors

Mini-Fit® Male Crimp Terminal, Tin (Sn) over Plated Brass Contact, 22-28 AWG, Reel

Documents:

Drawing (PDF)

Product Specification PS-51010-005 (PDF)

Product Specification PS-51010-006 (PDF)

Product Specification PS-51096-001 (PDF)

Product Specification PS-52034-003 (PDF)

Product Specification PS-52034-004 (PDF)

Product Specification PS-5556-002 (PDF)

Packaging Specification PK-5558-001 (PDF)

Test Summary TS-5556-002 (PDF)

RoHS Certificate of Compliance (PDF)

Series

image - Reference only

EU RoHS

ELV and RoHS

Compliant

REACH SVHC

Contains SVHC: No

Low-Halogen Status

Low-Halogen

China RoHS

General

Product Family

Series

Application

Crimp Quality Equipment

Overview

Product Name

UPC

Crimp Terminals

5558

Power

Yes

Mini-Fit Jr.™ Power Connectors

Mini-Fit®

800753584617

Physical

Durability (mating cycles max)

Gender

Material - Metal

Material - Plating Mating

Material - Plating Termination

Net Weight

Packaging Type

Plating min - Mating

Plating min - Termination

Termination Interface: Style

Wire Insulation Diameter

Wire Size AWG

Wire Size mm²

Male

Brass

Tin

0.154/g

Reel

0.889µm

Crimp or Compression

0.90-1.80mm

22, 24, 26, 28

N/A

Need more information on product

environmental compliance?

Email productcompliance@molex.com

For a multiple part number RoHS Certificate of

Compliance, click here

Please visit the Contact Us section for any

non-product compliance questions.

Search Parts in this Series

5558Series

Mates With

5556 Mini-Fit® Crimp Terminal

Use With

5559 Mini-Fit Jr.™ Plug Housing, 30068

Mini-Fit® TPA Plug Housing, 42475 Mini-

Fit® BMI Plug Housing

Application Tooling

FAQ

Tooling specifications and manuals are

found by selecting the products below.

Crimp Height Specifications are then

contained in the Application Tooling

Specification document.

Global

Description

Product #

FineAdjust™

0639002700

Applicator for

Insulation OD

1.30-1.50mm - 22-28

AWG

Electrical

Current - Maximum per Contact

Voltage - Maximum

600V

Material Info

Old Part Number

5558T2

Reference - Drawing Numbers

Packaging Specification

Product Specification

PK-5558-001

PS-51010-005, PS-51010-006, PS-51096-001,

PS-52034-003, PS-52034-004, PS-5556-002,

RPS-30067-002

SD-5558****

TS-5556-002

Sales Drawing

Test Summary

39-00-0048 (Cut Strip) Related Products

	39-00-0048 (Cut Strip)	39-00-0048 (Mouser Reel)
Description	headers & wire housings MN-FT term 22-28g M cut strip of 100	headers & wire housings MN-FT term 22-28g M reel of 1000
Manufacture	Molex	Molex
Product Category	Headers & Wire Housings	Headers & Wire Housings
RoHS	Yes	Yes
Contact Gende	Pin (Male)	Pin (Male)
Contact Plating	Ti	Ti
Termination Style	Crim	Crim
Contact Material	Brass	Brass
Factory Pack Quantity	100	1000
Voltage Rating	600 V	600 V
Wire Gauge	28-22	28-22
