RF/Microwave Capacitors
RF/Microwave Multilayer Capacitors (MLC)
800B Series NP0 Porcelain, High RF Power Ultra-Low ESR
FEATURES
•
•
•
•
•
•
•
Case B Size (.110” x .110”)
Rugged, reliable NPO dielectric
Case optimized for highest self resonant frequency
Capacitance Range 0.1 pF to 1000 pF
Lowest ESR
Capable of highest RF Power
RoHS Compliant/Lead-Free
PACKAGING OPTIONS
GENERAL DESCRIPTION
AVX’s 800B Series offers superb performance in demanding
high RF power applications requiring consistent and
reliable operation. The combination of highly conductive
metal electrode systems, optimized case geometries, and
proprietary dielectrics, yields the lowest ESR. AVX’s new NPO
low loss rugged dielectrics are designed to provide superior
heat transfer in high RF power applications. Ultra-low ESR and
superior thermal performance insure that the 800B Series
products are your best choice for high RF power applications
from VHF through microwave frequencies.
Tape & Reel
Vertical
Orientation
Tape & Reel
Special
Packaging
Available
Cap-Pak
®
(100 pcs)
ENVIRONMENTAL CHARACTERISTICS
Quality Factor (Q)
Temperature Coefficient
of Capacitance (TCC)
Insulation Resistance
(IR)
Working Voltage (WVDC)
Dielectric Withstanding
Voltage (DWV)
Retrace
Aging Effects
Piezoelectric Effects
Capacitance Drift
Operating
Temperature Range
Termination Styles
> 2000 @ 1 MHz
0 ±30 PPM/°C (-55°C to +125°C)
0.1 pF to 1000 pF:
10
5
Megohms min. @
+25°C at rated WVDC
10
4
Megohms min. @
+125°C at rated WVDC
See Capacitance Values Table
Case B: 250% of rated
WVDC for 5 secs
Less than ±(0.02% or 0.02 pF),
whichever is greater
None
None
±(0.02% or 0.02 pF),
whichever is greater
From -55°C to +125°C
(No derating of working voltage)
See Mechanical Configurations
Terminations for chips withstand a
pull of 5 lbs. min., 15 lbs. typical, for
5 seconds in direction perpendicular
to the termination surface of the
capacitor. Test per MIL-STD-202,
method 211.
TYPICAL APPLICATIONS
• Avionics
• Public Safety Radio
• Wireless
Communications
• VHF / UHF / HDTV
Broadcast Transmitters
• Telecom
• WiMAX
• Microwave Communication
Systems and Satellite Systems
TYPICAL CIRCUIT APPLICATIONS
•
•
•
•
High RF Power Filter Networks
Matching Networks
Couplers
Combiners
•
•
•
•
Output Coupling
Antenna Coupling
DC Blocking
Bypassing
ENVIRONMENTAL TEST
Thermal Shock
Moisture Resistance
MIL-STD-202, Method 107, Condition A
MIL-STD-202, Method 106
MIL-STD-202, Method 103, Condition A,
with 1.5 Volts DC applied while subjected
Low Voltage Humidity
to an environment of 85°C with 85%
relative humidity for 240 hours min.
Life Test
MIL-STD-202, Method 108, for 2000
hours, at 125°C
200% WVDC applied
Terminal Strength
The Important Information/Disclaimer is incorporated in the catalog where these specifications came from or
available online at www.avx.com/disclaimer/ by reference and should be reviewed in full before placing any order.
113020
511
RF/Microwave Capacitors
RF/Microwave Multilayer Capacitors (MLC)
800B Series NP0 Porcelain, High RF Power Ultra-Low ESR
CAPACITANCE VALUES
Cap.
Code
0R1
0R2
0R3
0R4
0R5
0R6
0R7
0R8
0R9
1R0
1R1
1R2
1R3
1R4
1R5
1R6
1R7
1R8
1R9
2R0
2R1
2R2
Cap.
(pF)
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1.0
1.1
1.2
1.3
1.4
1.5
1.6
1.7
1.8
1.9
2.0
2.1
Tol.
B
B, C
Rated
WVDC
Cap.
Code
2R4
2R7
3R0
3R3
3R6
3R9
4R3
4R7
5R1
5R6
6R2
6R8
7R5
8R2
9R1
100
110
120
130
150
160
180
Cap.
(pF)
2.4
2.7
3.0
3.3
3.6
3.9
4.3
4.7
5.1
5.6
6.2
6.8
7.5
8.2
9.1
10
11
12
13
15
16
18
Tol.
Rated
WVDC
Cap.
Code
200
220
240
270
300
330
360
390
430
470
510
560
620
680
750
820
910
101
111
121
131
Cap.
(pF)
20
22
24
27
30
33
36
39
43
47
51
56
62
68
75
82
91
100
110
120
130
Tol.
Rated
WVDC
Cap.
Code
151
161
181
201
221
241
271
301
331
361
391
431
471
511
561
621
681
751
821
911
102
Cap.
(pF)
150
160
180
200
220
240
270
300
330
360
390
430
470
510
560
620
680
750
820
910
1000
Tol.
Rated
WVDC
300
B, C,
D
500
F, G,
J, K,
M
200
F, G,
J, K,
M
100
500
B, C,
D
500
B, C,
J, K,
M
F, G,
J, K,
M
50
300
VRMS = 0.707 X WVDC
• SPECIAL VALUES, TOLERANCES AND MATCHING AVAILABLE. PLEASE CONSULT FACTORY.
HOW TO ORDER
800
Series
Case Size
See mechanical dimensions below
B
910
J
T
500
X
T
Packaging
T = Tape & Reel: 500 and 1000 pc.
qty. std.*
TV = Vertical Orientation of Product,
Tape & Reel: 500 and 1000 pc. qty. std.*
I = Special Packaging. Consult Factory
Please see last Column Mechanical Configuration Table for
other options
Capacitance
EIA Capacitance Code in pF.
First two digits = significant figures or “R” for decimal place.
Third digit = number of zeros or after “R” significant figures
Capacitance Tolerance Code
Code
Tol.
B
C
D
F
G
J
K
M
Laser Marking
WVDC
Termination Code
Please see 2nd Column Mechanical
Configuration Table
±10%
±20%
±0.1 pF ±0.25 pF ±0.5 pF
±1%
±2%
±5%
The above part number refers to a 800 B Series (case size B) 91 pF capacitor, J tolerance (±5%), 500 WVDC, with T termination
(Tin Plated over Nickel Barrier Termination, RoHS Compliant), laser marking and tape and reel packaging.
512
The Important Information/Disclaimer is incorporated in the catalog where these specifications came from or
available online at www.avx.com/disclaimer/ by reference and should be reviewed in full before placing any order.
041921
