ATC, the industry leader, is announcing new improved ESR/ESL
performance for the 700 B Series RF/Microwave Capacitors. The
superior high self-resonance and zero TCC characteristic of this Series
provide excellent performance over a broad range of RF and microwave
applications requiring minimum drift, including RF power. Porcelain and
ceramic construction provide a rugged, hermetic package.
ELECTRICAL AND MECHANICAL
SPECIFICATIONS
QUALITY FACTOR (Q):
Greater than 10,000 (0.1 pF to 200 pF) @ 1 MHz.
Greater than 2000 (220 pF to 1000 pF) @ 1 MHz.
Greater than 2000 (1100 pF to 5100 pF) @ 1 KHz.
TEMPERATURE COEFFICIENT OF CAPACITANCE (TCC):
0 ±30 PPM/°C (-55°C to +125°C)
0.1 pF to 470 pF:
10
6
Megohms min. @ +25°C at rated WVDC.
Typical functional applications: Bypass, Coupling, Tuning and DC Blocking.
10
5
Megohms min. @ +125°C at rated WVDC.
Typical circuit applications: Filters, Oscillators, Timing and RF Power 510 pF to 5100 pF:
Amplifiers.
10
5
Megohms min. @ +25°C at rated WVDC.
10
4
Megohms min. @ +125°C at rated WVDC.
INSULATION RESISTANCE (IR):
ENVIRONMENTAL TESTS
THERMAL SHOCK:
MIL-STD-202, Method 107, Condition A.
WORKING VOLTAGE (WVDC):
See Capacitance Values Table, page 2.
DIELECTRIC WITHSTANDING VOLTAGE (DWV):
250% of WVDC for capacitors rated at 500 volts DC or less for 5 seconds.
150% of WVDC for capacitors rated at 1250 volts DC or less for 5 seconds.
120% of WVDC for capacitors rated above 1250 Volts DC for 5 seconds.
ATC 700 B Series Capacitors are designed and manufactured to meet and
exceed the requirements of EIA-198, MIL-PRF-55681 and MIL-PRF-123.
MOISTURE RESISTANCE:
MIL-STD-202, Method 106.
RETRACE:
Less than ±(0.02% or 0.02 pF), whichever is greater.
AGING EFFECTS:
None
PIEZOELECTRIC EFFECTS:
None
(No capacitance variation with voltage or pressure).
LOW VOLTAGE HUMIDITY:
MIL-STD-202, Method 103, Condition A, with 1.5 Volts DC applied while
subjected to an environment of 85°C with 85% relative humidity for 240
hours min.
CAPACITANCE DRIFT:
±(0.02% or 0.02 pF), whichever is greater.
OPERATING TEMPERATURE RANGE:
0.1 to 200 pF: from -55°C to +175°C
220 to 5100 pF: from -55°C to +125°C
LIFE TEST:
MIL-STD-202, Method 108, for 2000 hours, at 125°C.
200% WVDC applied.
Voltage Applied:
200% of WVDC for capacitors rated at 500 volts DC or less.
120% of WVDC for capacitors rated at 1250 volts DC or less.
100% of WVDC for capacitors rated above 1250 volts DC
TERMINATION STYLES:
Available in various surface mount and leaded styles.
See Mechanical Configurations, page 3.
TERMINAL STRENGTH:
Terminations for chips and pellets withstand a
pull of 5 lbs. min., 15 lbs. typical, for 5 seconds in direction perpendicular to
the termination surface of the capacitor. Test per MIL-STD-202, method 211.
THE ENGINEERS’ CHOICE
®
www.atce rami cs. com
ATC # 001-814 Rev. V, 8/20
ATC 700 B Capacitance Values
CAP. CAP.
CODE (pF)
0R1
0R2
0R3
0R4
0R5
0R6
0R7
0R8
0R9
1R0
1R1
1R2
1R3
1R4
1R5
1R6
1R7
1R8
1R9
2R0
2R1
2R2
2R4
2R7
3R0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1.0
1.1
1.2
1.3
1.4
1.5
1.6
1.7
1.8
1.9
2.0
2.1
2.2
2.4
2.7
3.0
RATED WVDC
RATED WVDC CAP. CAP.
TOL
CODE (pF)
STD. EXT.
STD. EXT.
3R3
3.3
B
3R6
3.6
3R9
3.9
B, C
4R3
4.3
B, C, D
4R7
4.7
5R1
5.1
5R6
5.6
6R2
6.2
6R8
6.8
7R5
7.5 B, C, J,
8R2
8.2 K, M
9R1
9.1
500 1500
500 1500 100
10
110
11
B, C, D
120
12
130
13
150
15
160
16
F, G, J,
180
18
K, M
200
20
220
22
240
24
270
27
300
30
TOL.
EXTENDED VOLTAGE
EXTENDED VOLTAGE
EXTENDED VOLTAGE
EXTENDED VOLTAGE
CAP. CAP.
CODE (pF)
330
360
390
430
470
510
560
620
680
750
820
910
101
111
121
131
151
161
181
201
221
241
271
301
TOL
RATED WVDC CAP. CAP.
CODE (pF)
STD. EXT.
331
361
391
431
471
511
561
621
681
751
821
911
102
112
122
152
182
222
272
302
332
392
472
512
VOLT
TOL
RATED WVDC
STD. EXT.
33
36
39
43
47
51
56
62
68
75
82
91
F, G, J,
100
K, M
110
120
130
150
160
180
200
220
240
270
300
1500
EXT
500
VOLTAGE
300
EXTENDED
1000
200
N/A
330
360
390
430
470
510
560
620
680
750
820
910
F, G, J,
1000
K, M
1100
1200
1500
1800
2200
2700
3000
3300
3900
4700
5100
200
150
N/A
50
VRMS = 0.707 x WVDC
• SPECIAL VALUES, TOLERANCES, HIGHER WVDC AND MATCHING AVAILABLE. • ENCAPSULATION OPTION AVAILABLE. PLEASE CONSULT FACTORY.
Capacitance values in
bold
type indicate porcelain dielectric. All other capacitance values indicate ceramic dielectric.
All 700 B Capacitors are available laser marked with ATC's identification, capacitance code and tolerance.
NOTE: EXTENDED WVDC DOES NOT APPLY TO CDR PRODUCTS.
ATC PART NUMBER CODE
700
Series
Case Size
Capacitance Code:
First 2 significant digits for capacitance.
R=Decimal Point
Indicates number of zeros following digits
of capacitance in picofarads except for decimal values.
Capacitance Tolerance
B 33 1 J W 500 X
T
Packaging
T - Tape and Reel, 1000 pc. qty.*
TV - Vertical Orientation of Product,
Tape and Reel, 1000 pc. qty.*
I - Special Packaging. Consult Factory.
*
Consult ATC for other quantities
ATC Cap-Pac® packaging (100 pc. qty. std.) is also
available. For this option, leave last field blank.
CAPACITANCE TOLERANCE
Code
Tol.
B
C
D
F
±1%
G
±2%
J
K
M
±0.1 pF ±0.25 pF ±0.5 pF
±5% ±10% ±20%
Laser Marking
WVDC
Termination Code
The above part number refers to a 700 B Series (case size B) 330 pF capacitor,
J tolerance (±5%), 500 WVDC, with W termination (Tin/Lead, Solder Plated over Nickel Barrier), laser marking and Tape and Reel packaging.
For additional information and catalogs contact your ATC
representative or call direct at (631) 622-4700.
Consult factory for additional performance data.
A M E R I C A N
2
ATC North America
sales@atceramics.com
T E C H N I C A L
ATC Europe
saleseur@atceramics.com
C E R A M I C S
ATC Asia
sales@atceramics-asia.com
w w w.a t ce r a m ics .c o m
ATC 700 B Capacitors: Mechanical Configurations
