NEW
Thin Film High Value SMD Resistor (Ceramic Package)
Features
■ Realized excellent stability and moisture‐proof performance using
hermetically sealed ceramic package with new developed thin film element.
■ High resistance value available (100kΩ to 10MΩ） with small package
■ Low TCR and high accuracy, no influence from outside strains
■ High ambient temperature is available up to 200 deg.C
TCR, Resistance Range, Tolerance, Rated Power
TCR (ppm/deg.C)
Resistance Value (Ω)
‐25deg.C to +125deg.C
Resistance
Tolerance
(%)
±0.02(Q)
±0.05(A)
±0.1(B)
±0.05(A)
±0.1(B)
±0.5(D)
±1.0(F)
Rated Power
(W)
at 125deg.C
Type
100k to 1M
TCB
0±5(X)
0±10(C)
1M to 10M
0.1
Composition of Type Number
Example：
Power Derating Curve
(％)
100
TCB X 500K0 B
Rated Power Percentage
80
60
40
20
Tolerance
Resistance Value
TCR
Tyoe
Resistance value in ohm is expressed by 4 significant
digits and the R or K or M is a dual purpose letter
that designates both the value and location of decimal point.
½
½
-65
75
100
125
150
175
200 (℃)
Ambient Temperature
Performance
Configuration
L
Parameters
T
Maximum Rated Operating Temp.
Test Condition
Typical
125deg.C
‐65deg.C to +200deg.C
Working Temp. Range
Maximum Working Voltage
300V
Rated Power x 2.5, 5sec.
+65deg.C to ‐10deg.C, 90%RH to 98%RH, Rated Power, 10 cycles
Overload
※
Moisture Resistance
Life (Rated Power)
±500ppm
±100ppm
±500ppm
±50ppm
±200ppm
±100ppm
±100ppm
±100ppm
±500ppm
±100ppm
>10,000MΩ
±100ppm
±200ppm
±200ppm
<0.1ppm/V
125deg.C, Rated Voltage, 1.5 hrs ON/0.5 hrs OFF, 1000hrs.
15deg.C to 35deg.C, 15%RH to 75%RH, No load, 10000hrs.
W
Storage Life
High Temp. Exposure
Vending Substrate
Pressure Cooker Test
※
200deg.C, No load, , 1000hrs.
3mm, 60 sec.
120 deg.C, 100%RH, 2 bar, No load, 96hrs.
‐65deg.C to +175deg.C/30min., 5cycles
‐65deg.C, no load, 24hrs.‐> Rated Voltage, 45min.
※terminals are dummy
Thermal Shock
Low Tem. Storage and Operation
Type
L
W
T
TCB
3.8±0.2
3.8±0.2
1.25±0.2
mm
Dielectric Withstand Voltage
AC200V, 1min.
Insulation Resistance
Solderability
Shock
DC100V, 1min.
260deg.C. 10 sec.
100G, 6msec., Sawtooth Wave, X, Y, Z 10shocks
High Frequency Vibration
20G, 10 to 2K to10Hz, 20min., X, Y, Z 2.5hrs. each
Voltage Coefficient
MG Ikenohata Bldg. 4F 1‐2‐18 Ikenohata Taito‐ku, Tokyo 110‐0008
TEL: 03‐5823‐6450 FAX: 03‐5832‐6451
＊Descriptions and specifications in this catalog are subjected to change without notice.
0910M0
