Axial Lead and Cartridge Fuses
Designed to IEC Standard
RoHS
Pb
5 x 20 mm
Fast-Acting Fuse 216 Series
®
®
• Designed to International (IEC) Standards for use globally.
• Meets the IEC 60127-2, Sheet 1 specification for Fast Acting Fuses.
• Available in Cartridge and Axial Lead Form.
• Available in ratings of 0.050 to 10 amperes.
• High breaking capacity.
•
RoHS compliant and Lead-Free version available, add XP suffix to
standard catalog number
ELECTRICAL CHARACTERISTICS:
% of Ampere
Rating
150%
210%
275%
Ampere
Rating
.05 – 6.3
8-10
.05 – 10
.05 – 4
5– 6.3
8-10
.05 – 6.3
8-10
.05 – 6.3
8-10
Opening
Time
60 minutes,
Minimum
30 minutes,
Minimum
30 minutes,
Maximum
0.01 sec.,
Min.;
2 sec.
Max.
0.01 sec.,
Min.;
3 sec.
Max.
0.04 sec.,
Min.;
20 sec.
Max.
.003 sec.,
Min.;
0.3 sec.
Max.
.01 sec.,
Min.;
1.0 sec.
Max.
.02 seconds,
Maximum
.03 seconds,
Maximum
400%
1000%
ENVIRONMENTAL SPECIFICATIONS:
Operating temperature:
-55˚C to 125˚C
Thermal Shock:
MIL-STD-202F Method 107G, Test Condition B: (5
cycles –65°C to +125°C)
Vibration:
MIL-STD-202F Method 201A
Humidity:
MIL-STD-202F Method 103B, Test Condition A. high relative
humidity (95%) and elevated temperature (40°C) for 240 hours.
Salt Spray:
MIL-STD-202F Method 101D, Test Condition B
0.7-0.8 power factor.
INTERRUPTING RATING:
1500 amperes @ 250 VAC,
PHYSICAL SPECIFICATIONS:
Material:
Body: Ceramic
Cap: Nickel Plated Brass
Leads: Tin Plated Copper
Filler Sand (160mA – 10A)
Terminal Strength:
MIL-STD-202F Method 211A,
Test Condition A
Solderability:
Reference IEC 60127 Second Edition 2003-01 Annex A
ORDERING INFORMATION:
RoHS compliant and Lead-Free version available, add XP suffix to
standard catalog number
Cartridge
Catalog
Number
216.050
216.063
216.080
216.100
216.125
216.160
216.200
216.250
216.315
216.400
216.500
216.630
216.800
216
001
216
1.25
216
01.6
216
002
216
02.5
216
3.15
216
004
216
005
216
06.3
216
008
216
010
Nominal
Resistance
Cold Ohms
15.90
10.45
7.89
5.42
3.68
5.20
3.35
2.35
1.85
1.67
1.20
0.790
0.588
0.228
0.153
0.108
0.0770
0.0575
0.0333
0.0243
0.0168
0.0125
0.0120
0.00775
Nominal
Melting I
2
t
A
2
Sec.
0.00019
0.00055
0.00086
0.0033
0.0056
0.0018
0.0045
0.0092
0.015
0.028
0.045
0.097
0.18
0.19
0.49
1.04
1.92
2.77
7.85
15.4
28.2
57.9
66.1
158.5
Ampere
Rating
.050
.063
.080
.100
.125
.160
.200
.250
.315
.400
.500
.630
.800
1
1.25
1.6
2
2.5
3.15
4
5
6.3
8*
10*
Voltage
Rating
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
Product Marking:
Cap 1: current and voltage rating.
Cap 2: Agency approval markings.
Packaging:
Available in Bulk (v=5, H=100, M=1000 pcs/pkg) or on
Tape/Reel (MRET1=1000 pcs/reel).
11
AXIAL LEAD AND
CARTRIDGE FUSES
415
w w w. l i t t e l f u s e . c o m
Axial Lead and Cartridge Fuses
Designed to IEC Standard
RoHS
Pb
5 x 20 mm
Fast-Acting Fuse 216 Series
Agency Approvals
Ampere Range
A&C
E
B&D
F
50mA – 800mA
1A – 6.3A
1A – 10A
40
®
®
Agency Approvals
20+0.5
5.2+0.1
-0.2
5.1+0.6
5.1+0.6
Certificate No.
Cartridge
NBK250702-E10480
NBK250702-E10480
Leaded
NBK250702-E10480
NBK250702-E10480
2003010207079960
2002010207007594
SU05001-2013
0216
000
2
1A – 10A
Certificate No.
Certificate No.
0216.050 XE
1
to
0216.100 XE
1
22.5 MAX
6.0 MAX
0.65
®
Recognised File No. E10480
Guide No.
JDYX2
®
File No.
Acc. Class No.
Licence No.
File No.
029862
LR1422-30
KM41462
9848103, 9931059
304518 & 304555
50mA – 10A
1A – 6.3A
0216001.XE
1
to
0216010.XE
1
40
22.5 MAX
5.8 MAX
0.65*
All dimensions in mm
32mA – 6.3A
50mA – 10A
Notes:
* Ratings above 6.3A
have 0.8 mm dia lead
1 For RoHS compliant parts
replace XE with XEP
2 For RoHS compliant parts
add suffix 'XP'
Average Time Current Curves
0.050A
0.063A
0.080A
0.100A
0.125A
0.160A
0.200A
0.250A
0.315A
0.400A
0.500A
0.630A
0.800A
1A
1.25A
1.6A
2A
2.5A
3.15A
4A
5A
6.3A
8A
10A
10000
1000
100
TIME IN SECONDS
10
1
0.1
0.01
0.001
0.01
0.1
1
10
100
1000
CURRENT IN AMPERES
416
w w w. l i t t e l f u s e . c o m
