Catalog Number NH
Special
Purpose Fuses
HRC Fuse Links
Class of Operation:
Amp Ratings:
Voltage Ratings:
Sizes:
Standards/Approvals:
gG/gL
2 to 1250 Amps
500Vac
000 to 4
IEC 60269, VDE0636, DIN 43620
part 1 to 4, VDE mark and CE
Description:
A square bodied range of industrial fuse
links for a wide variety of applications.
Packaging:
3's, except size 4 packed in 1
Ordering Code:
Rating/Type Size Category, e.g.,
63NHG000B
Technical Data:
Contact Edison Customer Satisfaction
for curves and I
2
t Data.
Rated Voltage:
500Vac
Rated Breaking Capacity:
120kA
Rated Frequency:
50 Hz
Operating Frequency:
45 - 62 Hz
Selectivity:
1 : 1.6 up to 500Vac
Design - Insulator:
Ceramic
- Metal Parts:
Corrosion-proof (top plate also
galvanic plated)
Contact Blades:
Full contact and insulated blades
available, silver-plated brass.
Protection Type:
IP00 according to DIN40050
Dimensions:
DIN 43620
Tests:
VDE 0636/22
Constancy of Characteristics:
Resistant of aging.
On/Off Indicator:
Patented spring dual indication
Mechanical Stress:
Vibrations 7 up to 50Hz with 1 g,
shocks with 5 g.
Environmental:
100% recyclable, RoHS compliant,
cadmium and lead free across entire
range, corrosion free screws.
Canadian
Fuses & Holders
Dimensions - mm
Size a
000
00
0
01
1
02
2
03
3
4
a2
a1
(max)
78.5±1.5
54
78.5±1.5
54
125±2.5
68
135±2.5
75
135±2.5
75
150±2.5
75
150±2.5
75
150±2.5
75
150±2.5
75
200
84
a3
45±1.5
45±1.5
62+3/-1.5
62±2.5
62±2.5
62±2.5
62±2.5
62±2.5
62±2.5
80
a4
49±1.5
49±1.5
68+1.5/-3
68±2.5
68±2.5
68±2.5
68±2.5
68±2.5
68±2.5
90
b
(rated)
15
15
15
15
20
20
25
25
32
50
c1
c2
(±8) (rated)
35
10
35
11
35
11
40
11
40
11
48
11
48
11
60
11
60
11
85
10
D
(rated)
2±0.5
2±0.5
2.5±0.5
2.5±0.5
2.5±0.5
2.5±0.5
2.5±0.5
2.5±0.5
3±0.5
3
e1
(max)
41
48
48
48
53
53
61
61
75
102
e2
(max)
21
30
30
30
52
52
60
60
70
87
e3
(max)
16
25
25
25
25
25
25
25
25
-
e4
(rated)
6
6
6
6
6
6
6
6
6
8
f
(max)
8
15
15
15
15
15
15
15
18
30
Medium
Voltage Fuses
Fuse Blocks,
Holders & Misc.
Application
Section
For additional information, visit www.edisonfuse.com
91
