SPECIFICATIONS
Contact material:
Contact plating:
Housing material:
Shield material:
Shield plating:
Alloy C5102, ø0.46mm
Gold over nickel
Engineering thermoplastic, UL94V-0
Brass
Nickel alloy
E
LED Color Codes
Code
LED
R
Red
G
Green
Y
Yellow
D
Red/Green
E
Red/Yellow
W Yellow/Green
K
Blank
D
E
F
RoHS compliant
Rev.
Description
Date
Series Positions Ports
Body Style
Contacts
Color
Plating
Options
SGCTJ
0X
X
3028LXX
X
X
PX
XX
Mod jack, 8, 10
2, 4, 8 3028 style
4, 6, 8
BK=Black P1=15µ” gold [blank]=None
ganged,
L=LEDs
P2=30µ” gold S=Full shield
stacked
XX=left/right (see chart)
P3=50µ” gold S6=Top & side panel grounds
Approved
Drawing
Name
Approved Howard
Checked Lizzy
Drawn Tina
0.0 ± 0.35
Date
07/14/06
07/14/06
07/14/06 Part No.:
F
Central Components Manufacturing
440 Lincoln Blvd., Middlesex, New Jersey 08846
Phone 732 469-5720 888 288-5152 Fax 732 469-1919
SGCTJ-08-2-3028LXX-8-BK-PX-SX
G
7
8
9
G
0.00 ± 0.20 Angles ± 3’
UNIT: mm
5
6
Description: Modular jack, 2 ports, stacked, LEDs, shielded
