RB083L-20: Description5 A, 25 V, SILICON, RECTIFIER DIODE; CategoryDiscrete semiconductor diode; File Size59KB，2 Pages; ManufacturerROHM Semiconductor; Websitehttps://www.rohm.com/; Environmental Compliance

Download Datasheet Parametric View All

RB083L-20 Overview

5 A, 25 V, SILICON, RECTIFIER DIODE

RB083L-20 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	ROHM Semiconductor
package instruction	R-PDSO-C2
Contacts	2
Reach Compliance Code	_compli
ECCN code	EAR99
Other features	HIGH RELIABILITY
application	GENERAL PURPOSE
Configuration	SINGLE
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
Maximum forward voltage (VF)	0.39 V
JESD-30 code	R-PDSO-C2
JESD-609 code	e1
Humidity sensitivity level	1
Maximum non-repetitive peak forward current	70 A
Number of components	1
Phase	1
Number of terminals	2
Maximum operating temperature	125 °C
Maximum output current	5 A
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	260
Certification status	Not Qualified
Maximum repetitive peak reverse voltage	25 V
surface mount	YES
technology	SCHOTTKY
Terminal surface	Tin/Silver/Copper (Sn96.5Ag3.0Cu0.5)
Terminal form	C BEND
Terminal location	DUAL
Maximum time at peak reflow temperature	10
Base Number Matches	1

Preview

Download Datasheet

View All

RB083L-20

Diodes

Schottky barrier diode

RB083L-20

!Applications

High frequency rectification

For switching power supply

!External

dimensions

(Units : mm)

1.5±0.2

!Features

1) Compact power mold type. (PMDS)

2) Ultra low V

/ Low I

3) I

=5A guaranteed despite the size.

CATHODE MARK

4.5±0.2

1.2±0.3

0.1

+0.02

−0.1

2.0±0.2

2.6±0.2

!Construction

Silicon epitaxial planar

ROHM : PMDS

EIAJ :

−

JEDEC : SOD-106

Date of manufacture EX. 1999.12

→

9,C

!Absolute

maximum ratings

(Ta=25°C)

Parameter

Peak reverse voltage

DC reverse voltage

Mean rectifying current

∗

Symbol

FSM

Tstg

Limits

125

−40~+125

Unit

°C

Peak forward surge current

(60Hz 1

)

Junction temperature

Storage temperature

∗

When mounted on alumina PCBs (82×30×1.0mm), Tc Max.=90°C

!Electrical

characteristics

(Ta=25°C)

Parameter

Forward voltage

Reverse current

Symbol

Min.

−

Typ.

−

Max.

0.39

500

Unit

µA

Conditions

=3.0A

=20V

5.0±0.3
