THESE DRAWINGS ARE THE PROPERTY OF QUALTEK
ELECTRONICS AND NOT TO BE REPRODUCED FOR
OR COMMUNICATED TO A THIRD PARTY WITHOUT
THE EXPRESS WRITTEN PERMISSION OF AN OFFICER
OF QUALTEK ELECTRONICS.
REVISION
REV.
B
C
D
E
F
DESCRIPTION
RoHS Compliancy
Updated Graphics and Dimensions
Added RTI Information
Updated Dimensions
Added Terminal Material and Tolerances
DATE
06-01-06
06-02-10
03-11-11
03-23-11
03-29-11
APPROVED
DP
LY
LY
LY
LY
35.2 ± 0.3
27.6 ± 0.3
15.8 ±
0
0.5
21.5 ±
0.5
0
7 ± 0.1
23 ±
14
0
0.5
0.5
0
R1
Ø1.6
6.3 ± 0.1
0.6 ± 0.2
29.5 ±
7.8MIN
24.7 ± 0.2
32.6 ±
0.2
0
24.5 ± 0.5
10 ± 0.3
0.8 ± 0.03
25.3 ±
0.2
0
16
29
R5
PANEL CUTOUT
R3
23
32
NOTES:
RATING:
UL, CSA: 15A 250V AC
VDE, NEMKO, CCC, KTL: 10A 250V AC
APPROVALS: UL, CSA, VDE, NEMKO, CCC
PANEL THICKNESS: 0.8~1.5mm
MATERIAL:
BODY INSULATOR: PC BLACK COLOR
TERMINAL: BRASS STRIP C2680 NICKEL PLATED
UL 746B RELATIVE TEMPERATURE INDEX:
TENSILE STRENGTH: 125˚C
TENSILE IMPACT STRENGTH: 115˚C
ELECTRIC STRENGTH: 125˚C
RoHS COMPLIANT
3.6 ± 0.15
17.8 ± 0.2
0.5
.0
Dim
range
(mm)
0-1
1-6
6-18
18-50
50-120
120-250
250-500
Tolerance
+/-
(mm)
0.15
0.20
0.30
0.50
0.70
0.90
1.20
CONTROLLED
Qualtek Electronics Corp.
Part Number:
Description:
PPC DIVISION
716W-X2/03
AC RECEPTACLE
UNIT: mm
REV. F
Approved / Date
JJH / 03-10-04
Drawn / Date
B.ZHANG
03-10-04
Checked / Date
03-10-04
