ROTARY SWITCHES
Series 92
DESCRIPTION
Integral Series 92
is a Miniature Rotary Switch of 25 mm Dia., offering premium
quality at economical price. The design of the Switch is limited to a single section
with solder/pc terminals. These are totally enclosed switches offering the most
popular combination as encountered in modern electronic circuits. Uniform,
positive indexing is provided by 2 balls housed in an Engineering Plastic case.
FEATURES
l
l
l
l
l
Miniature single section switches
Contacts totally enclosed for environmental protection
Choice of contact materials
Stoppers can be adjusted at site
Can be directly mounted on PC
integral
DIMENSIONAL DETAILS
3,000 DIA
3/8-32 UNEF 2A
6.350 DIA
11
1
12
10
PANEL MOUNTING
9
11
1
12
10
9
8
7
9
10
11
2
3
4
5
8
7
6
6
A
A
5.51 FLAT
9.5
L
9.53
12.83
1.65
26.190 DIA
6.35
26.190 DIA
2.21
1
12
1
12
6.35
3.88
1.02
0.51 THICK
1.22
3.18
11
10
9
11
10
A
A
2.29
0.51 THK
26.190 DIA
26.190 DIA
1.50
DIA. TYP
1.50
DIA. TYP
1.50
DIA. TYP
7.70
DIA.
22.20
DIA.
7.70
DIA.
22.20
DIA.
7.70
DIA.
22.20
DIA.
A
C
SHAFT
9.80
DIA.
DIA
6.3
3.18
9.5
5.4 FLAT
5
2
2
4
4
3
3
8
7
5
4
4
3
3
1.02
NUT
PANEL
LOCKWASHER
9
8
7
5
5
2
2
6
7
8
Install switch with stop ring (if used)
and lockwasher back of panel
(Switch side).
Tighten hex nut from front of panel.
PC mounted switches: use hex nut
and lockwasher to hold stop ring in
place
6
6
1.50
DIA. TYP
7.70
DIA.
22.20
DIA.
All Dimensions in mm.
C14
SPECIFICATIONS
CONTACT RATING
: 2.5 A @ 125 V AC or 28 V DC
150 mA @ 230 V AC or DC
MATERIALS & FINISHES
BODY, ROTOR AND BASE : Glass filled nylon
CONTACTS
: Copper alloy or coin silver
Silver plate or gold plate
(See contact selection)
: Brass / Steel Zinc plate
CONTINUOUS CURRENT : 5A
LIFE
: More than 20,000 cycles on full
load
: <20 milli ohms measured at
2-6V DC / 100 mA initial
HARDWARE
CONTACT RESISTANCE
INSULATION RESISTANCE : > 1000 Meg ohms
VOLTAGE PROOF
OPERATING TEMP
INDEXING ANGLE
: min. 1000 V AC
: -30
0
C to + 70
0
C
: 30
0
Order
Code
S1
S2
L
Shaft Length
HOW TO ORDER
1. For standard switch by describing as given below.
2. For special assembly use layout or send drawings.
Order
Code
2
3
Termination
Solder Type
PC type
CONTACT SELECTION
Order
Code
0
Std. Shaft 12.0 mm
Std. Shaft 40.0 mm
Specify Length
STATOR CONTACTS AND
MOVING CONTACTS
RATING
STATOR CONTACTS
MOVING CONTACTS
RATING
:
:
:
:
:
CIRCUIT CONFIGURATION
Order Code
S
Shorting
N
Non-shorting
NO. OF POSITIONS
Order
No. of
Code
positions
02
2
03
3
-
-
-
-
-
-
12
12
POLE SELECTION
Order
No. of Poles
Code
1
One
2
Two
3
Three
4
Four
Copper alloy with silver plate
150 mA @ 230 V AC or DC
Carry : 5 A continuous
Copper alloy with silver plate
Coin silver with silver plate
2.5 A @ 125 V AC or 28 V DC;
150 m A @ 230 V AC or DC;
Carry 5A continuous
Copper alloy with gold plate
over nickel plate
0.4 V A max. @ 20 V AC or DC max.
Copper alloy, with gold plate over
nickel plate over silver plate
Coin silver with gold plate, over
nickel plate over silver plate
0.4 V A max @ 20 V AC or DC max.
or 2.5 A @ 125 V AC or 28 V DC;
150 mA @ 230 V AC or DC
1
2
STATOR CONTACTS AND
MOVING CONTACTS
RATING
:
:
:
:
:
3
STATOR CONTACTS
MOVING CONTACTS
RATING
10/2011 ISSUE 03, DCR 1182
ORDERING
CODE
9 2
INTEGRAL SYSTEMS AND COMPONENTS PRIVATE LIMITED
D-388/1, 1st Block, 1st Stage, Peenya Industrial Estate, Bangalore - 560 058, India
Telefax:
(080) 2839 1707 / 2839 1708 / 2839 1709 / 2839 1710
An ISO 9001:2008 Company
Website:
www.integralsys.in
E-mail:
inty.systems@gmail.com / sales@integralsys.in
C15
