SMPS - Switch Mode Power Supply Filter Capacitors
Today's high frequency switch mode power supplies (SMPS) require
high performance capacitors in the input and output filters. Union Technology
has developed a line of MLCC SMPS filter caps with extremely low equivalent
series resistance (ESR) and low equivalent series inductance (ESL) that offer
improved performance at higher frequencies. These capacitors have been
extensively tested and have performance characteristics meeting the demands
for efficient capacitors in these stringent applications.
Union Technology is approved to DSCC Drawings 87106 and 88011. Parts
can be screened to the requirements of MIL-PRF-49470 or customer drawings.
Maximum Capacitance for each Case-Values in uF
Case
Code
Voltage
X7R
NPO
Case
Code
Voltage
X7R
NPO
50V
15.0
0.56
100V
8.2
0.47
50V
100
4.7
100V
56.0
3.3
4
200V
3.9
0.27
500V
1.8
0.12
50V
5.6
0.27
100V
3.3
0.22
1
200V
27.0
1.8
500V
12.0
0.82
50V
150
5.6
100V
82.0
4.7
5
200V
1.5
0.1
500V
0.68
0.047
50V
270
15.0
100V
180
12.0
2
200V
39.0
2.7
500V
18.0
1.2
50V
47.0
2.2
100V
27.0
1.8
6
200V
120
5.6
500V
39.0
2.2
3
200V
12.0
1.0
500V
5.6
0.39
Dimensions
Case
Code
1
2
3
4
5
6
D
C + .025
Min
.450
.800
.450
.400
.250
1.250
1.950
1.450
.950
.350
.224
1.950
Max
2.075
1.535
1.075
.425
.275
2.075
Number
E(max) of leads
per side
.500
.870
.500
.440
.300
1.350
20
15
10
4
3
20
* For Refer to Table 1 and 2 on pages 9 and 10.
** For maximum "B" Dimension add .065 inch to the appropriate
"A" Dimension.
4
Union Technology Corp.
• 718 Monterey Pass Road, Monterey Park, CA 91754
(323) 266-6603 • Fax (323) 266-7890 • www.uniontechcorp.com
Ordering Terminology
SMPS Ceramic Capacitors - Ordering Information
P
SMPS Capacitor Family
B 4 N 1 BX 475 K
B
Voltage
G
B
50V
100V
R
S
200V
500V
Case Code
(see dimension chart)
Lead Style
N
J
Straight (thru hole)
Leads formed in
Coating
1
2
Uncoated
Coated
TC
BX
BR
BX
BR
BG
BY
X7R
NPO
Capacitance
(expressed
in pF)
L
M
Leads formed out
Without leads
First two digits are significant, third digit is number of zeros.
J
K
Tolerance
+5%
M
+ 10%
+ 20%
Test Level
A
B
Electrical Screening Only
MIL-PRF-49478 Group A
C
X
HiRel Group B or C
Special Screening
Ordering Information for DSCC Drawings 87106 & 88011
Part Identification Number
Drawing Number
Dash Number
Lead - N Standard - Do not specify - For J or L lead use suffix
87106
XXX
X
Vendor CAGE Number
OYBX7
Notes:
1. Dimensions are in inches.
2. Unless otherwise specified, tolerances are
+ .010 inch (0.25 mm).
3. Lead frame configuration is shown as typical above the
seating plane.
4. See Table I for specific maximum A dimension. For maxi-
mum B dimension, add .065 inch
(1.65 mm) to the
appropriate A dimension. For all lead styles, the number of
chips is determined by the capacitance and voltage rating.
5. For case code 5, dimensions shall be .100 inch (2.54 mm)
maximum and .012 inch (0.30 mm) minimum.
6. Lead alignment within pin rows shall be within + .005
inch (0.13 mm).
5
718 Monterey Pass Road, Monterey Park, CA 91754 •
Union Technology Corp.
www.uniontechcorp.com • (323) 266-6603 • Fax (323) 266-7890
