INDEX
Size
21
25
31
37
51
51-2
67
69
100
A Max.
In.
mm.
1.150
1.250
1.400
1.550
1.500
1.910
2.310
1.810
2.235
29.21
31.75
35.56
39.37
38.10
48.51
58.67
45.97
56.77
B Max.
In.
mm.
.370
.370
.370
.370
.410
.370
.370
.410
.460
9.40
9.40
9.40
9.40
10.41
9.40
9.40
10.41
11.68
B
A
C
Micro-D Backshells
Sample Part Number
Series
Shell Finish
Connector Size
Hardware Option
EMI Band Strap Option
507-142
E
– Chem Film (Alodyne)
M
– Electroless Nickel
G
F
D
.175 (4.4)
507-142
EMI/RFI Dual Entry Banding Backshell
Round Cable Entry
Dual Cable Entry
EMI backshell allows
attachment of two separate wire bundles to
the same Micro-D connector. This backshell
accepts both standard and micro shield
termination straps.
Materials
• Shell: Aluminum Alloy 6061 -T6
• Clips: 17-7PH Stainless Steel
• Hardware: 300 Series Stainless Steel
How To Order EMI/RFI Dual Entry Backshell
507-142
J
– Cadmium, Yellow Chromate
NF
– Cadmium, Olive Drab
H
– Hex Head Jackscrew
F
– Jackpost, Female
M
– Micro Band (2 supplied) .125" Wide
M
25
h
B
Z2
– Gold
09, 15, 21, 25, 31, 37 51, 51-2, 67, 69, 100
(See Table I)
B
– Fillister Head Jackscrew
E
– Extended Jackscrew
Omit
(Leave Blank)
– Band Not Included
B
– Standard Band (2 supplied) .250" Wide
Table I: Dimensions
E
CODE B
FILLISTER HEAD
JACKSCREW
.44 (11.1)
CODE H
HEX HEAD
JACKSCREW
H
CONNECTOR ORDERED
SEPARATELY
CODE F
FEMALE
JACKPOST
#2-56 UNC THDS. 9-69 PIN
#4-40 UNC THDS. 100 PIN
CODE E
EXTENDED
JACKSCREW
C
In.
.865
.965
1.115
1.265
1.215
1.615
2.015
1.515
1.800
mm.
21.97
24.51
28.32
32.13
30.86
41.02
51.18
38.48
45.72
D Max.
In.
mm.
1.030
1.090
1.150
1.190
2.130
2.130
2.130
2.130
1.280
26.16
27.69
29.21
30.23
54.10
54.10
54.10
54.10
32.51
E Max.
In.
mm.
.740
.850
.980
1.130
1.080
1.510
1.880
1.380
1.470
18.80
21.59
24.89
28.70
27.43
38.35
47.75
35.05
37.34
F
In.
.125
.188
.250
.344
.312
.281
.281
.312
.500
mm.
3.18
4.78
6.35
8.74
7.92
7.13
7.13
7.93
12.70
In.
.281
.344
.406
.500
.469
.469
.469
.469
.688
G
mm.
7.13
8.74
10.31
12.70
11.91
11.91
11.91
11.91
17.48
H Max.
In.
mm.
.590
.650
.710
.750
.780
.780
.780
.780
.840
14.99
16.51
18.03
19.05
19.81
19.81
19.81
19.81
21.34
© 2013 Glenair, Inc.
High Performance Micro-D Connectors and Cables
U.S. CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
M-8
