REVISIONS
DESCRIPTION
1
DATE
11-JUN-13
APPV
SAH
A INITIAL RELEASE OF LINX SOLID MODEL
D
.598
15.20
2X Ø0.018 DIMPLE(S)
EQUALLY SPACED
D
.260
6.60
C
.323
8.20
.154
3.90
.049
1.24
.047
1.20
.547
13.90
C
B
.276
7
SECTION A-A
.057
1.45
.057
1.45 .276
7
B
A
A
.039 SQ.
1
A
NOTES: (UNLESS OTHERWISE SPECIFIED)
1. ALL DIMENSIONS ARE IN INCHES [mm].
2. DIMENSIONS APPLY AFTER FINISHING.
3. MANUFACTURE TO BE COMPLIANT WITH EU RoHS DIRECTIVE.
WARNING:
THIS DRAWING CONTAINS PROPRIETARY INFORMATION
THAT IS THE SOLE PROPERTY OF LINX TECHNOLOGIES, AND SHALL BE
TREATED AS SUCH. NO DISCLOSURE OR REPRODUCTION OF THIS
DOCUMENT IS PERMITTED, IN WHOLE OR IN PART, WITHOUT THE
TITLE:
EXPRESS WRITTEN PERMISSION OF LINX TECHNOLOGIES OR ITS
DESIGNATED AGENTS.
INTERPRET DIMENSIONS AND
TOLERANCES PER ASME Y14.5.
32
159 ORT LANE
MERLIN, OR 97532
A
MATERIAL:
PROJECTION:
FINISH:
SURFACE FINISH:
ANGLES: 1
TOLERANCES: .X .1 .XX .01 .XXX .005
SIZE DWG. NO.
SOLID MODEL, APPROVED
FOR CUSTOMER USE
DRAWN: B.MURPHY DT: 3-APR-13
SMS-CONREVSMA002-G
A
ENGR: S.HOGAN
DT: 11-JUN-13 SCALE: 4:1
DO NOT SCALE DRAWING
SHEET 1 OF 1
