8
7
6
5
4
3
2
1
REVISIONS
REV.
ECO. NO
3756
4200
DESCRIPTION
ADD 32 POSITION
CHANGE TM TAIL LENGTH FROM .250 TO .230
DATE
10/10/2017
4/21/2020
BY
JT
JH
F
E
F
D
E
D
B
.156 3.96 TYP
A
E
2X
.125 3.18
.100[2.54]/.115[2.92] FOR S273
.135[3.43] FOR S664
SEE NOTE 13
E
C
A
D
+.010
+0.25
.470
11.94
- .005
- 0.13
TA = .100 .025[2.54 0.64]
TB = .180 .025[4.57 0.64]
TM = .230 .025[5.84 0.64]
.060 1.52 FOR S273
.090[2.29] FOR S664
D
.250 6.35
.610 15.49
.297 7.54
INSERTION
DEPTH
.030±.015 0.76±0.38
.060 1.52
A
F
_ _ M _ _ DTAD - S273, S664
_ _ M _ _ DTBD - S273, S664
_ _ M _ _ DTMD - S273, S664
.025 0.64
SECTION A - A
.150 3.81
C
C
2X .125 3.18
FOR Z MOUNTING ONLY
D
A
.095 2.41
B
B
A
.156 3.96 TYP
NOTES:
1. INSULATOR MATERIAL: SEE PART NUMBER CODING
2. CONTACT MATERIAL: SEE PART NUMBER CODING
3. PLATING: SEE PART NUMBER CODING
4. OPERATING TEMPERATURE: SEE PART NUMBER CODING
5. PROCESSING TEMP: SEE PART NUMBER CODING
.043[1.09] MIN HOLE
6. UL FLAMMABILITY RATING: 94V-0
7. OPERATING VOLTAGE: 950 VAC
PCB LAYOUT RECOMMENDED
8. CURRENT RATING: 3 AMP
9. CONTACT RESISTANCE: 30 MILLI OHMS MAX
10. INSULATION RESISTANCE: 5000 MEGA OHMS
11. DURABILITY: 500 CYCLES MIN
12. CONNECTOR IDENTIFICATION: THE PART SHALL BE MARKED WITH A PART NUMBER AND LOT CODE
UNLESS OTHERWISE SPECIFIED: DRAWN
13. BOARD THICKNESS ACCOMMODATED: .093 .008[2.36 0.20] FOR S273, .125 .008[3.18 0.20] FOR S664
DIMENSIONS ARE IN INCHES [MM]
14. INSERTION FORCE: S273 = 16 OZ MAX PER CONTACT PAIR WHEN USING A .093[2.36] TEST BLADE
TOLERANCES:
S664 = 16 OZ MAX PER CONTACT PAIR WHEN USING A .125[3.18] TEST BLADE
ANGULAR: 1
INTERNAL INSPECTION TO BE PER SULLIN'S WORK INSTRUCTION WI-8.6-03
15. WITHDRAWAL FORCE: S273 = 1 OZ MIN PER CONTACT PAIR USING .093[2.36] PCB
DECIMALS
.XX= .02 [.5]
S664 = 1 OZ MIN PER CONTACT PAIR USING .125[3.18] PCB
.XXX= .005 [.13]
.XXXX= .0005 [.013]
16. MODIFICATION: S273 = HIGH PROFILE CONNECTOR FOR .093 .008[2.36 0.20] PCB
RoHS
COMPLIANT
S664 = HIGH PROFILE CONNECTOR FOR .125 .008[3.18 0.20] PCB
.150 3.81
CUSTOMER COPY
DATE
6/12/06
NAME
MV
TITLE
THE INFORMATION HEREIN CONTAINS
PROPRIETARY INFORMATION OF
SULLINS ELECTRONICS AND IS NOT
TO BE REPRODUCED, USED OR
DISCLOSED TO OTHERS FOR ANY
PURPOSE EXCEPT AS SPECIFICALLY
AUTHORIZED IN WRITING BY AN
OFFICER OF SULLINS ELECTRONICS.
Pb
4
PART NUMBER
SIZE
EDGECARD, .156 CC, .093 &.125 PCB
_ _ M _ _ D(TA,TB,TM)_-S273, S664
CAGE CODE
A
SCALE: 2:1
2
C
54453
DWG. NO.
C10751
1
REV
SHEET 1 OF 3
E
8
7
6
5
3
FILE NAME: C10751, _ _M_ _D(TA,TB, TM)_-S273, S664
8
7
6
5
4
3
2
1
F
F
D
2X #4-40
THREADED INSERTS
E
C
E
.250 6.35
_ _ M _ _ DTAN - S273, S664
_ _ M _ _ DTBN - S273, S664
_ _ M _ _ DTMN - S273, S664
D
_ _ M _ _ DTAT - S273, S664
_ _ M _ _ DTBT - S273, S664
_ _ M _ _ DTMT - S273, S664
D
C
C
D
2X
.125 3.18
.095 2.41
B
B
_ _ M _ _ DTAZ - S273, S664
_ _ M _ _ DTBZ - S273, S664
_ _ M _ _ DTMZ - S273, S664
.125 3.18 TYP
CUSTOMER COPY
A
Pb
RoHS
COMPLIANT
8
7
6
5
4
UNLESS OTHERWISE SPECIFIED: DRAWN DATE NAME
DIMENSIONS ARE IN INCHES [MM]
6/12/06 MV
TOLERANCES:
ANGULAR:
1
THE INFORMATION HEREIN CONTAINS
PROPIETARY INFORMATION OF
SULLINS ELECTRONICS AND IS NOT
TO BE REPRODUCED, USED OR
DISCLOSED TO OTHERS FOR ANY
PURPOSE EXCEPT AS SPECIFICALLY
AUTHORIZED IN WRITING BY AN
OFFICER OF SULLINS ELECTRONICS.
TITLE
DECIMALS
.XX= .02 [.5]
.XXX= .005 [.13]
.XXXX= .0005 [.013]
PART NUMBER
SIZE
EDGECARD, .156 CC, .093 &.125 PCB
_ _ M _ _ D(TA,TB,TM)_-S273, S664
CAGE CODE
A
SCALE: 4:1
3
2
C
54453
DWG. NO.
C10751
1
REV
SHEET 2 OF 3
E
FILE NAME: C10751, _ _M_ _D(TA,TB, TM)_-S273, S664
8
7
6
5
4
3
2
1
F
F
E
E
D
D
C
C
B
B
CUSTOMER COPY
A
Pb
RoHS
COMPLIANT
8
7
6
5
4
UNLESS OTHERWISE SPECIFIED: DRAWN DATE NAME
DIMENSIONS ARE IN INCHES [MM]
6/12/06 MV
TOLERANCES:
ANGULAR:
1
THE INFORMATION HEREIN CONTAINS
PROPIETARY INFORMATION OF
SULLINS ELECTRONICS AND IS NOT
TO BE REPRODUCED, USED OR
DISCLOSED TO OTHERS FOR ANY
PURPOSE EXCEPT AS SPECIFICALLY
AUTHORIZED IN WRITING BY AN
OFFICER OF SULLINS ELECTRONICS.
TITLE
DECIMALS
.XX= .02 [.5]
.XXX= .005 [.13]
.XXXX= .0005 [.013]
PART NUMBER
SIZE
EDGECARD, .156 CC, .093 &.125 PCB
_ _ M _ _ D(TA,TB,TM)_-S273, S664
CAGE CODE
A
SCALE: 1:1
3
2
C
54453
DWG. NO.
C10751
1
REV
SHEET 3 OF 3
E
FILE NAME: C10751, _ _M_ _D(TA,TB, TM)_-S273, S664
