Part Number:
Status:
Description:
39506-1016
Active
3.50mm Pitch Eurostyle™ Horizontal PCB Header, with Threaded Retention Inserts, 16
Circuits
Documents:
3D Model
Drawing (PDF)
Product Specification PS-39500-001 (PDF)
RoHS Certificate of Compliance (PDF)
Series
Terminal Blocks
39506
N/A
PCB Header
ESE, Eurostyle™Pluggable
Euro Block
822350450737
image - Reference only
EU RoHS
ELV and RoHS
Compliant
REACH SVHC
Not Reviewed
Low-Halogen Status
Not Reviewed
China RoHS
General
Product Family
Series
Application
Component Type
Product Name
Type
UPC
Physical
Circuits (Loaded)
Entry Angle
Lock to Mating Part
Net Weight
Number of Rows
Orientation
PC Tail Length
PCB Thickness - Recommended
Panel Mount
Pitch - Mating Interface
Pitch - Termination Interface
Polarized to Mating Part
Shrouded
Stackable
Temperature Range - Operating
Wire Size AWG
16
N/A
Yes
0.010/mg
1
Horizontal
3.50mm
2.50mm
No
3.50mm
3.50mm
Yes
Fully
No
-40°C to +105°C
N/A
Need more information on product
environmental compliance?
Email productcompliance@molex.com
For a multiple part number RoHS Certificate of
Compliance, click here
Please visit the Contact Us section for any
non-product compliance questions.
Search Parts in this Series
39506Series
Mates With
Most 3.50mm Pitch Industry Standard
Plugs, 39504 Horizontal Plug with Retention
Screws, 39507 Vertical Plug with Retention
Screws
Electrical
Current - Maximum per Contact
Voltage - Maximum
8A
300V
Material Info
Reference - Drawing Numbers
Product Specification
Sales Drawing
PS-39500-001
SD-39501-002, SD-39506-001
