Ferrules
Insulated
Industry Standard
Ferrules insure reliable elec-
trical connections when ter-
minating stranded flexible
wire in terminal blocks, cir-
cuit breakers or other con-
trol devices. Insulated fer-
rules
prevent conductor
breakage due to bending,
wire stress or vibration
while facilitating wire inser-
tion into the terminal clamp.
Altech’s standard insulated
ferrules are color coded by
conductor size for conven-
ient identification.
To ensure efficient ferrule
crimping, always select the
smallest ferrule diameter
that fits the wire and use
only professional crimping
tools. (Please refer to the
ordering pages and the
Crimper Selector Guide on
page 98.)
• Sleeve: polypropylene
• Tube: tin-plated copper
INDUSTRY STANDARD FERRULES
220672
Tested According To:
CSA Std C22.2 No. 65-93
CSA Std C22.2 No. 188-M1983
ANSI/UL Std No.
486A
ANSI/UL Std No.
486C
- Wire Connectors
- Splicing Wire and Cable Connectors
- Wire Connectors and Soldering Lugs for Use with Copper Conductors
- Splicing Wire Connectors
AWG
(mm2)
24 (.25)
24 (.25)
22 (.34)
22 (.34)
20 (.50)
20 (.50)
18 (.75)
18 (.75)
18 (1.00)
18 (1.00)
16 (1.50)
16 (1.50)
16 (1.50)
14 (2.50)
14 (2.50)
14 (2.50)
12 (4.00)
12 (4.00)
12 (4.00)
10 (6.00)
10 (6.00)
8 (10.00)
8 (10.00)
6 (16.00)
6 (16.00)
4 (25.00)
4 (25.00)
2 (35.00)
2 (35.00)
1 (50.00)
2/0 (70.00)
Color
Lt. Blue
Lt. Blue
Type
H0.25/6
H0.25/8
Cat. Stripping Length
No.
2620.0
2621.0
2622.0
2623.0
2397.0
2201.0
2398.0
2202.0
2399.0
2203.0
2204.0
2400.0
2205.0
2206.0
2401.0
2207.0
2208.0
2402.0
2209.0
2210.0
2211.0
2212.0
2213.0
2214.0
2215.0
2267.0
2272.0
2276.0
2390.0
2500.0
2786.0
2787.0
mm (in.)
6.0(.24)
8.0(.31)
6.0(.24)
8.0(.31)
6.0(.24)
8.0(.31)
6.0(.24)
8.0(.31)
6.0(.24)
8.0(.31)
8.0(.31)
10.0(.39)
18.0(.71)
8.0(.31)
12.0(.47)
18.0(.71)
10.0(.39)
12.0(.47)
18.0(.71)
12.0(.47)
18.0(.71)
12.0(.47)
18.0(.71)
12.0(.47)
18.0(.71)
18.0(.71)
22.0(.87)
18.0(.71)
25.0(.98)
20.0(.79)
20.0(.79)
25.0(.98)
A
10.0 (.39)
12.0 (.47)
10.0 (.39)
12.0 (.47)
12.0 (.47)
14.0 (.55)
12.0 (.47)
14.0 (.55)
12.0 (.47)
14.0 (.55)
14.0 (.55)
16.0 (.63)
24.0 (.94)
14.0 (.55)
18.0 (.71)
24.0 (.94)
17.0 (.67)
20.0 (.79)
26.0 (1.02)
20.0 (.79)
26.0 (1.02)
22.0 (.87)
28.0 (1.10)
24.0 (.94)
28.0 (1.10)
30.0 (1.18)
36.0 (1.42)
30.0 (1.18)
39.0 (1.54)
36.0 (1.42)
37.0 (1.46)
44.0 (1.73)
Ferrule Dimensions mm (in.)
B
6.0 (.24)
8.0 (.31)
6.0 (.24)
8.0 (.31)
6.0 (.24)
8.0 (.31)
6.0 (.24)
8.0 (.31)
6.0 (.24)
8.0 (.31)
8.0 (.31)
10.0 (.39)
18.0 (.71)
8.0 (.31)
12.0 (.47)
18.0 (.71)
10.0 (.39)
12.0 (.47)
18.0 (.71)
12.0 (.47)
18.0 (.71)
12.0 (.47)
18.0 (.71)
12.0 (.47)
18.0 (.71)
18.0 (.71)
22.0 (.87)
18.0 (.71)
25.0 (.98)
20.0 (.79)
20.0 (.79)
25.0 (.98)
27.0 (1.06)
32.0 (1.26)
C
1.2 (.05)
1.2 (.05)
1.2 (.05)
1.2 (.05)
1.3 (.05)
1.3 (.05)
1.5 (.06)
1.5 (.06)
1.7 (.07)
1.7 (.07)
2.0 (.08)
2.0 (.08)
2.0 (.08)
2.5 (.10)
2.5 (.10)
2.5 (.10)
3.2 (.13)
3.2 (.13)
3.2 (.13)
3.9 (.15)
3.9 (.15)
4.9 (.19)
4.9 (.19)
6.2 (.24)
6.2 (.24)
7.7 (.30)
7.7 (.30)
8.7 (.34)
8.7 (.34)
10.9(.43)
13.4(.53)
15.4(.61)
17.6(.69)
20.5(.81)
D
2.3 (.09)
2.3 (.09)
2.5 (.10)
2.5 (.10)
2.8 (.11)
2.8 (.11)
3.3 (.13)
3.3 (.13)
3.5 (.14)
3.5 (.14)
4.0 (.16)
4.0 (.16)
4.0 (.16)
4.7 (.19)
4.7 (.19)
4.7 (.19)
5.4 (.21)
5.4 (.21)
5.4 (.21)
6.9 (.27)
6.9 (.27)
8.4 (.33)
8.4 (.33)
9.6 (.38)
9.6 (.38)
12.0(.47)
12.0(.47)
13.5(.53)
13.5(.53)
16.0(.63)
17.0(.67)
19.0(.75)
22.4(.88)
25.0(.98)
Std.
Pk.*
500/100
500/100
500/100
500/100
500/100
500/100
500/100
500/100
500/100
500/100
500/100
500/100
500/100
500/100
500/100
500/100
500/100
500/100
100
100
100
100
100
100
100
50
50
50
50
50
25
25
25
25
Turquoise H0.34/6
Turquoise H0.34/8
Orange
Orange
White
White
Yellow
Yellow
Red
Red
Red
Blue
Blue
Blue
Gray
Gray
Gray
Black
Black
Ivory
Ivory
Green
Green
Brown
Brown
Beige
Beige
Olive
Yellow
Red
Blue
H0.50/6
H0.50/8
H0.75/6
H0.75/8
H1.00/6
H1.00/8
H1.50/8
H1.50/10
H1.50/18
H2.50/8
H2.50/12
H2.50/18
H4.00/10
H4.00/12
H4.00/18
H6.00/12
H6.00/18
H10.0/12
H10.0/18
H16.0/12
H16.0/18
H25.0/18
H25.0/22
H35.0/18
H35.0/25
H50.0/20
H70.0/21
H95.0/25
CRIMPER SELECTOR
GUIDE
See page 109.
3/0 (95.00)
4/0 (120.00)
H120.0/27 2788.0
H150.0/27 2789.0
27.0(1.06) 48.0 (1.89)
32.0(1.26) 58.0 (2.28)
250MCM(150.0)Yellow
* Different standard packs are available as shown. To order the desired standard pack, please use the quantity required as a suffix to the cat. no.
Example for 100 standard pack: Type H0.25/6, Cat. No. 2620.0/100
Altech Corp.
®
• 35 Royal Road • Flemington, NJ 08822-6000 • Phone (908)806-9400 • FAX (908)806-9490 • www.altechcorp.com
105
Ferrules
Insulated
DIN Standard
Ferrules insure reliable
electrical
connections
when terminating strand-
ed flexible wire in termi-
nal blocks, circuit breakers
or other control devices.
Insulated ferrules prevent
conductor breakage due
to bending, wire stress or
vibration while facilitating
wire insertion into the ter-
minal clamp.
Altech’s DIN standard fer-
rules are in compliance
with DIN requirements,
making them ideal for
export applications. They
also have a specified color
code convention that dif-
fers from the color code
used for Altech’s industry
standard ferrules.
To ensure efficient ferrule
crimping, always select
the smallest ferrule diam-
eter that fits the wire and
use only professional
crimping tools. (Please
refer to the ordering
pages and the Crimper
Selector Guide on page
98.)
• Sleeve: polypropylene
• Tube: tin plated copper
Tested According To:
CSA Std C22.2 No. 65-93
CSA Std C22.2 No. 188-M1983
ANSI/UL Std No.
486A
ANSI/UL Std No.
486C
- Wire Connectors
- Splicing Wire and Cable Connectors
- Wire Connectors and Soldering Lugs for Use with Copper Conductors
- Splicing Wire Connectors
DIN STANDARD FERRULES
220672
AWG
(mm2)
20 (.50)
20 (.50)
20 (.50)
18 (.75)
18 (.75)
18 (.75)
18 (.75)
18 (1.00)
18 (1.00)
18 (1.00)
18 (1.00)
16 (1.50)
16 (1.50)
16 (1.50)
16 (1.50)
14 (2.50)
14 (2.50)
14 (2.50)
12 (4.00)
12 (4.00)
12 (4.00)
10 (6.00)
10 (6.00)
8 (10.00)
8 (10.00)
6 (16.00)
6 (16.00)
4 (25.00)
4 (25.00)
2 (35.00)
2(35.00)
Color
White
White
White
Gray
Gray
Gray
Gray
Red
Red
Red
Red
Black
Black
Black
Black
Blue
Blue
Blue
Gray
Gray
Gray
Yellow
Yellow
Red
Red
Blue
Blue
Yellow
Yellow
Red
Red
Blue
Type
H0.50/6
H0.50/8
H0.50/10
H0.75/6
H0.75/8
H0.75/10
H0.75/12
H1.00/6
H1.00/8
H1.00/10
H1.00/12
H1.50/8
H1.50/10
H1.50/12
H1.50/18
H2.50/8
H2.50/12
H2.50/18
H4.00/10
H4.00/12
H4.00/18
H6.00/12
H6.00/18
Cat. Stripping Length
No.
2863.0
2864.0
2865.0
2866.0
2867.0
2868.0
2869.0
2870.0
2871.0
2872.0
2840.0
2841.0
2842.0
2843.0
2844.0
2845.0
2846.0
2847.0
2848.0
2849.0
2850.0
2851.0
2852.0
mm (in.)
6.0(.24)
8.0(.31)
10.0(.39)
6.0(.24)
8.0(.31)
10.0(.39)
12.0(.47)
6.0(.24)
8.0(.31)
10.0(.39)
12.0(.47)
8.0(.31)
10.0(.39)
12.0(.47)
18.0(.71)
8.0(.31)
12.0(.47)
18.0(.71)
10.0(.39)
12.0(.47)
18.0(.71)
12.0(.47)
18.0(.71)
12.0(.47)
18.0(.71)
12.0(.47)
18.0(.71)
18.0(.71)
22.0(.87)
18.0(.71)
25.0(.98)
20.0(.79)
A
12.0 (.47)
14.0 (.55)
16.0 (.63)
12.0 (.47)
14.0 (.55)
16.0 (.63)
18.0 (.71)
12.0 (.47)
14.0 (.55)
16.0 (.63)
18.0 (.71)
14.0 (.55)
16.0 (.63)
18.0 (.71)
24.0 (.94)
14.0 (.55)
18.0 (.71)
24.0 (.94)
17.0 (.71)
20.0 (.79)
26.0 (1.02)
20.0 (.79)
26.0 (1.02)
22.0 (.87)
28.0 (1.10)
24.0 (.87)
28.0 (1.10)
30.0 (1.18)
36.0 (1.5)
30.0 (1.18)
39.0 (1.54)
36.0 (1.5)
Ferrule Dimensions mm (in.)
B
6.0 (.24)
8.0 (.31)
10.0 (.39)
6.0 (.24)
8.0 (.31)
10.0 (.39)
12.0 (.47)
6.0 (.24)
8.0 (.31)
10.0 (.39)
12.0 (.47)
8.0 (.31)
10.0 (.39)
12.0 (.47)
18.0 (.71)
8.0 (.31)
12.0 (.47)
18.0 (.71)
10.0 (.39)
12.0 (.47)
18.0 (.71)
12.0 (.47)
18.0 (.71)
12.0 (.47)
18.0 (.71)
12.0 (.47)
18.0 (.71)
18.0 (.71)
22.0 (.87)
18.0 (.71)
25.0 (.98)
20.0 (.79)
C
1.3 (.05)
1.3 (.05)
1.3 (.05)
1.5 (.06)
1.5 (.06)
1.5 (.06)
1.5 (.06)
1.7 (.07)
1.7 (.07)
1.7 (.07)
1.7 (.07)
2.0 (.08)
2.0 (.08)
2.0 (.08)
2.0 (.08)
2.5 (.10)
2.5 (.10)
2.5 (.10)
3.2 (.13)
3.2 (.13)
3.2 (.13)
3.9 (.16)
3.9 (.16)
4.9 (.20)
4.9 (.20)
6.2 (.24)
6.2 (.24)
7.7 (.30)
7.7 (.30)
8.7 (.34)
8.7 (.34)
10.9(.43)
D
2.8 (.11)
2.8 (.11)
2.8 (.11)
3.3 (.13)
3.3 (.13)
3.3 (.13)
3.3 (.13)
3.5 (.14)
3.5 (.14)
3.5 (.14)
3.5 (.14)
4.0 (.16)
4.0 (.16)
4.0 (.16)
4.0 (.16)
4.7 (.19)
4.7 (.19)
4.7 (.19)
5.4 (.21)
5.4 (.21)
5.4 (.21)
6.9 (.27)
6.9 (.27)
8.4 (.33)
8.4 (.33)
9.6 (.38)
9.6 (.38)
12.0(.47)
12.0(.47)
13.5(.53)
13.5(.53)
16.0(.63)
Std.
Pk.*
500/100
500/100
500/100
500/100
500/100
500/100
500/100
500/100
500/100
500/100
500/100
500/100
500/100
500/100
500/100
500/100
500/100
500/100
500/100
500/100
100
100
100
100
100
100
100
50
50
50
50
50
H10.00/12 2853.0
H10.00/18 2854.0
H16.00/12 2855.0
H16.00/18 2856.0
H25.00/18 2857.0
H25.00/22 2858.0
H35.00/18 2859.0
H35.00/25 2860.0
H50.00/20 2861.0
CRIMPER SELECTOR
GUIDE
See page 109.
1 (50.00)
* Different standard packs are available as shown. To order the desired standard pack, please use the quantity required as a suffix to the cat. no.
Example for 100 standard pack: Type H0.50/6, Cat. No. 2863.0/100
106
Altech Corp.
®
• 35 Royal Road • Flemington, NJ 08822-6000 • Phone (908)806-9400 • FAX (908)806-9490 • www.altechcorp.com
Ferrules
Uninsulated
Ferrules insure reliable elec-
trical connections when ter-
minating stranded flexible
wire in terminal blocks, cir-
cuit breakers or other con-
trol devices.
Uninsulated ferrules pre-
vent wire strands from fray-
ing and breaking and are
extremely cost effective.
Their shorter lengths and
uninsulated bodies offer
advantages when making
terminations in printed cir-
cuit board terminal blocks
and in other terminal blocks
with smaller clamps or nar-
row widths.
To ensure efficient ferrule
crimping, always select the
smallest ferrule diameter
that fits the wire and use
only professional crimping
tools. (Please refer to the
ordering pages and the
Crimper Selector Guide on
page 109.)
• Tube: tin plated copper
UNINSULATED FERRULES
220672
Tested According To:
CSA Std C22.2 No. 65-93
CSA Std C22.2 No. 188-M1983
ANSI/UL Std No.
486A
ANSI/UL Std No.
486C
- Wire Connectors
- Splicing Wire and Cable Connectors
- Wire Connectors and Soldering Lugs for Use with Copper Conductors
- Splicing Wire Connectors
AWG
(mm2)
20 (.50)
18 (.75)
18 (.75)
18 (1.00)
18 (1.00)
16 (1.50)
16 (1.50)
14 (2.50)
14 (2.50)
12 (4.00)
12 (4.00)
10 (6.00)
10 (6.00)
8 (10.00)
8 (10.00)
8 (10.00)
6 (16.00)
6 (16.00)
6 (16.00)
4 (25.00)
4 (25.00)
2 (35.00)
1 (50.00)
2/0 (70.00)
3/0 (95.00)
4/0 (120.00)
250MCM(150.00)
350MCM(185.00)
Type
H0.50/6
H0.75/6
H0.75/10
H1.00/6
H1.00/10
H1.50/7
H1.50/10
H2.50/7
H2.50/12
H4.00/9
H4.00/12
H6.00/12
H6.00/15
H10.00/12
H10.00/15
H10.00/18
H16.00/12
H16.00/15
H16.00/18
H25.00/15
H25.00/18
H35.00/18
H50.00/32
H70.00/25
H95.00/32
H120.00/32
H150.00/32
H185.00/32
Cat.
No.
2216.0
2217.0
2218.0
2219.0
2220.0
2221.0
2222.0
2223.0
2224.0
2225.0
2226.0
2227.0
2388.0
2228.0
2389.0
2229.0
2391.0
2392.0
2393.0
2394.0
2395.0
2396.0
2816.0
2790.0
2791.0
2792.0
2793.0
2815.0
Stripping Length
mm (in.)
6.0 (.24)
6.0 (.24)
10.0 (.39)
6.0 (.24)
10.0(.39)
7.0 (.28)
10.0 (.39)
7.0 (.28)
12.0 (.47)
9.0 (.35)
12.0 (.47)
12.0 (.47)
15.0 (.59)
12.0 (.47)
15.0 (.59)
18.0 (.71)
12.0 (.47)
15.0 (.59)
18.0 (.71)
15.0 (.59)
18.0 (.71)
18.0 (.71)
32.0 (1.26)
25.0 (0.98)
32.0 (1.26)
32.0 (1.26)
32.0 (1.26)
32.0 (1.26)
Ferrule Dimensions mm (in.)
A
B
C
6.0 (.24)
6.0 (.24)
10.0 (.39)
6.0 (.24)
10.0 (.39)
7.0 (.28)
10.0 (.39)
7.0 (.28)
12.0 (.47)
9.0 (.35)
12.0 (.47)
12.0 (.47)
15.0 (.59)
12.0 (.47)
15.0 (.59)
18.0 (.71)
12.0 (.47)
15.0 (.59)
18.0 (.71)
15.0 (.59)
18.0 (.71)
18.0 (.71)
32.0 (1.26)
25.0 (.98)
32.0 (1.26)
32.0 (1.26)
32.0 (1.26)
32.0 (1.26)
1.3 (.05)
1.5 (.06)
1.5 (.06)
1.7 (.07)
1.7 (.07)
2.3 (.09)
2.3 (.09)
2.5 (.10)
2.5 (.10)
3.2 (.13)
3.2 (.13)
3.9 (.15)
3.9 (.15)
4.9 (.19)
4.9 (.19)
4.9 (.19)
6.2 (.24)
6.2 (.24)
6.2 (.24)
7.7 (.30)
7.7 (.30)
8.7 (.34)
10.9 (.43)
13.3 (.52)
15.3 (.60)
17.5 (.69)
19.5 (.77)
21.2 (.83)
2.1 (.08)
2.3 (.09)
2.3 (.09)
2.5 (.10)
2.5 (.10)
2.8 (.11)
2.8 (.11)
3.4 (.13)
3.4 (.13)
4.0 (.16)
4.0 (.16)
4.7 (.19)
4.7 (.19)
5.8 (.23)
5.8 (.23)
5.8 (.23)
7.5 (.30)
7.5 (.30)
7.5 (.30)
9.5 (.37)
9.5 (.37)
11.0 (.43)
13.0 (.51)
15.0 (.59)
17.0 (.67)
19.0 (.75)
21.0 (.83)
23.5 (.93)
Std.
Pk.*
1000/100
1000/100
1000/100
1000/100
1000/100
1000/100
1000/100
1000/100
1000/100
1000/100
1000/100
500/100
500/100
500/100
500/100
500/100
500/100
500/100
100
500/100
100
100
100
100
50
25
25
25
CRIMPER SELECTOR
GUIDE
See page 109.
* Different standard packs are available as shown. To order the desired standard pack, please use the quantity required as a suffix to the cat. no.
Example for 100 standard pack: Type H0.50/6, Cat. No. 2216.0/100
Altech Corp.
®
• 35 Royal Road • Flemington, NJ 08822-6000 • Phone (908)806-9400 • FAX (908)806-9490 • www.altechcorp.com
107
Ferrules
Dual Wire
Insulated
Dual Wire Ferrules have
larger diameters and spe-
cial shaped sleeves that
accept two conductors of
the same or different size.
They provide an efficient
connection of multiple
wires in the same terminal
clamp or simplify wire
jumpering between termi-
nal clamps. They are color
coded with the same con-
vention as the insulated
DIN standard ferrules.
To ensure efficient ferrule
crimping always select the
smallest ferrule diameter
that fits the wire and use
only professional crimping
tools. (Please refer to the
ordering pages and the
Crimper Selector Guide on
page 109.)
• Sleeve: polypropylene
• Tube: tin plated copper
DUAL WIRE FERRULES
220672
Tested According To:
CSA Std C22.2 No. 65-93
CSA Std C22.2 No. 188-M1983
ANSI/UL Std No.
486A
ANSI/UL Std No.
486C
- Wire Connectors
- Splicing Wire and Cable Connectors
- Wire Connectors and Soldering Lugs for Use with Copper Conductors
- Splicing Wire Connectors
Wires x AWG
Color
(mm2)
2x20 (2x.50)
2x18 (2x.75)
2x18 (2x.75)
2x18 (2x1.0)
2x18 (2x1.0)
2x16 (2x1.5)
2x16 (2x1.5)
2x14 (2x2.5)
2x14 (2x2.5)
2x12 (2x4.0)
2x10 (2x6.0)
2x8 (2x10.0)
2X6 (2x16.0)
Type
Cat. Stripping Length
No.
mm (in.)
2794.0
2775.0
2795.0
2776.0
2796.0
2777.0
2797.0
2778.0
2798.0
2799.0
2800.0
2801.0
2802.0
11.0 (.43)
11.0 (.43)
13.0 (.51)
11.0 (.43)
21.0 (.83)
12.0 (.47)
16.0 (.63)
14.0 (.55)
17.0 (.67)
16.0 (.63)
18.0 (.71)
18.0 (.71)
20.0 (.79)
A
Ferrule Dimensions mm (in.)
B
C
D1
8.2 (.32)
8.2 (.32)
10.0 (.39)
8.2 (.32)
18.0 (.71)
8.2 (.32)
12.0 (.47)
10.0 (.39)
12.0 (.47)
12.0 (.47)
12.0 (.47)
12.0 (.47)
1.7 (.07)
2.0 (.08)
2.0 (.08)
2.4 (.09)
2.4 (.09)
2.6 (.10)
2.6 (.10)
3.3 (.13)
3.3 (.13)
3.9 (.15)
5.0 (.20)
6.2 (.24)
8.9 (.35)
3.0 (.12)
3.0 (.12)
3.0 (.12)
3.2 (.13)
3.2 (.13)
3.6 (.14)
3.6 (.14)
4.5 (.18)
4.5 (.18)
5.2 (.20)
6.2 (.24)
7.6 (.30)
9.5 (.37)
D2
Std.
Pk.*
White H2x0.50/8
Gray
Gray
Red
Red
H2x0.75/8
H2x0.75/10
H2x1.00/8
H2x1.00/18
14.6 (.57)
14.6 (.57)
16.4 (.65)
15.4 (.61)
25.2 (.99)
15.8 (.62)
19.6 (.77)
18.5 (.73)
20.5 (.80)
22.0 (.87)
23.0 (.91)
24.0 (.94)
5.0 (.20) 500/100
5.5 (.22) 500/100
5.5 (.22) 500/100
5.8 (.23) 500/100
5.8 (.23) 500/100
6.5 (.26) 500/100
6.5 (.26) 500/100
8.0 (.31) 500/100
8.0 (.31) 500/100
9.0 (.35) 100
11.4 (.45) 100
13.4 (.53) 100
17.2 (.68) 100/50
Black H2x1.50/8
Black H2x1.50/12
Blue
Blue
Gray
H2x2.50/10
H2x2.50/12
H2x4.00/12
Yellow H2x6.00/12
Red
Blue
H2x10.00/12
H2x16.00/16
29.0 (1.14) 16.0 (.63)
INSULATED FERRULES
Assortment Box
Handy Assortment Boxes for
convenient dispensing and
storage of Industry and DIN
Standard Insulated Ferrules.
Types AB1-S and AB1-D are
equipped with five different
ferrule sizes. Types AB2-S
and AB2-D are equipped with
four different ferrule sizes.
Contents of each box is list-
ed. Dimensions for industry
and DIN standard insulated
ferrules are listed on pages
106.
* Different standard packs are available for many
ferrules. To order the desired standard pack, please
use the quantity required as a suffix to the Cat. No.
Example: Type H2x0.50/0,
Cat. No. 2794.0/100 for a standard pack of 100
Ferrule
Qty.
AWG
(mm2)
Ferrule
Type
Ferrule
Cat. No.
Ferrule
Color
Type
AB1-S
Cat. No.
2884.9
Std.
Pk.
1
AB1-S Industry Standard
50
20 (.50)
H0.50/8
100
20 (.75)
H0.75/8
100
18 (1.00)
H1.00/6
100
16 (1.50)
H1.50/8
50
14 (2.50)
H2.50/8
AB2-S Industry Standard
50
12 (.4.0)
H4.00/10
20
10 (6.0)
H6.00/12
20
8 (10.0)
H10.00/12
10
6 (16.0)
H16.00/12
AB1-D DIN Standard
50
20 (.50)
100
20 (.75)
100
18 (1.0)
100
16 (1.5)
50
14 (2.5)
AB2-D DIN Standard
50
12 (4.00)
20
10 (6.00)
20
8 (10.00)
10
6 (16.00)
2201.0
2202.0
2399.0
2204.0
2206.0
Orange
Whiite
Yellow
Red
Blue
AB2-S
2885.9
1
2208.0
2210.0
2212.0
2214.0
Gray
Black
Ivory
Green
AB1-D
2884.0
1
AB1-S
H0.50/6
H0.75/8
H1.00/8
H1.50/8
H2.50/8
2864.0
2867.0
2871.0
2841.0
2845.0
White
Gray
Red
Black
Blue
AB2-D
2885.0
1
AB2-S
H4.00/10
H6.00/12
H10.00/12
H16.00/12
2848.0
2851.0
2853.0
2855.0
Gray
Yellow
Red
Blue
108
Altech Corp.
®
• 35 Royal Road • Flemington, NJ 08822-6000 • Phone (908)806-9400 • FAX (908)806-9490 • www.altechcorp.com
Robotics Development
京公网安备 11010802033920号
EEWORLD
