30,88
+ 0,31
- 0,45
24,99
+ 0,13
- 0,12
12,6
+ 0,33
- 0,43
16,41
+ 0,05
- 0,2
10
°
7,39
+ 0,41
- 0,19
1,2
`
0,2
DSSNXSMAD01X
CONEC ABC
SEE NOTE 4
APPROVAL # FREIGABE # DEBLOCAGE # AUTORIZACION
APPROVAL # FREIGABE # DEBLOCAGE # AUTORIZACION # APPROVAL
CUSTOMER APPROVAL DATE:
NOTES:
1. METALSHELLS: COPPER ALLOY; min. 315µin TIN over 40-80µin NICKEL
2. INSULATORS: PBT GF UL 94 V-0, BLACK
3. CONTACTS: COPPER ALLOY
PLATING: 8µin HARD GOLD over min. 50µin NICKEL
SOLDER CUP ACCEPTS CABLE AWG 20
4. CONNECTOR IS PART MARKED: DSSNXSMAD01X CONEC ABC
NAME:
TITLE:
COMPANY NAME:
APPROVAL # FREIGABE # DEBLOCAGE # AUTORIZACION # APPROVAL
THIS DRAWING MAY NOT BE COPIED OR
REPRODUCED IN ANY WAY, AND MAY NOT
BE PASSED ON TO A THIRD PARTY WITHOUT
WRITTEN PERMISSION.
OWNERSHIP AND COPYRIGHT OF CONEC GmbH
DO NOT ALTER CAD DRAWING BY HAND
tolerance
dim. in mm
date
drawn
appd.
norm
d-old
scale:
material:
title:
6,13
+ 0,17
- 0,08
n
3,1
`
0,1
0,8
5,55
n
1,16
8
+ 0,23
-
0,02
APPROVAL # FREIGABE # DEBLOCAGE # AUTORIZACION
2:1
SEE NOTES
name
10.02.09
10.02.09
DIN 41652
Fischer
Petker
D-SUB FEMALE
9pos. SOLDER CUP
Inventor
DIN-
A4
dwg no:
R
a
Origin
16K1A2449
rev. description
date
name
part no:
DSSNXSMAD01X
sh: 1
