Product Specification
IXD1216
28 V, 150 mA Voltage Regulator with Stand-by Mode
FEATURES
Operating Voltage Range 2.0 V – 28.0 V
Output Voltage Range from 2.0 V to 12.0 V with
0.1 V increments (B series) or 2.0 V – 23 V with
external resistors (C series)
Output Voltage Accuracy ± 2%
Dropout Voltage 300 mV @ I
OUT
= 20 mA
0
Temperature Stability ± 30 ppm/ C
Low Power Consumption of 5 μA at V
OUT
= 5.0 V
Output Current up to 150 mA (200 mA limit) at
V
IN
= V
OUT
+ 3 V
Standby Current less than 0.1 µA typical
Power Supply Ripple Rejection 30 dB at 1 kHz
Current Limit and Short Circuit Protection
Low ESR Ceramic Capacitor compatible
ON/OFF switch,
Thermal shutdown
0
Operating Ambient Temperature - 40 + 85 C
Packages : SOT-25, SOT- 89, SOT-89-5, SOP-
8FD, USP-6C, SOT-223, and TO-252
EU RoHS Compliant, Pb Free
DESCRIPTION
The IXD1216 is positive voltage regulator with
operation voltage up to 28V, manufactured by CMOS
process.
The IC consists of a voltage reference, an error
amplifier, a current limiter, a thermal protection, a
phase compensation circuit, and a driver transistor.
The output voltage is selectable in 0.1 V increments
within the range from 2.0 V to 12 V for B and D series
and from 2.0 V to 23 V with external resistors for C
series. High precision output voltage achieved by
laser trimming technology.
The IXD1216 is stable with low ESR ceramic output
capacitor (C
L
). The over current protection circuit and
the thermal shutdown are built-in. These two
protection circuits operate when the output current
reaches current limit level or the junction temperature
reaches temperature limit.
The Chip Enable (CE) function allows set IXD1216
into standby mode, reducing current consumption to
less than 0.1 µA typically.
The IXD1216 is available in SOT-25, SOT-89, SOT-
89-5, SOP-8FD, USP-6C, SOT-223, and TO-252
packages.
APPLICATIONS
Mobile phones
Car Audio and Navigation Systems
Cameras, VCRs
Various portable equipment
TYPICAL APPLICATION CIRCUIT
TYPICAL PERFORMANCE CHARACTERISTIC
Output Voltage vs. Input Voltage (IXD1216B/D502)
C
IN
= C
L
= 1 µF, Ta = 25 C,
0
The IXD1216B with CE function
The IXD1216C series
PS033901-0515
PRELIMINARY
1
Product Specification
IXD1216
ELECTRICAL OPERATING CHARACTERISTICS
Ta = 25
0
C
PARAMETER
Input Voltage
Output Voltage
SYMBOL
V
IN
V
OUT(E)
1)
CONDITIONS
V
CE
= V
IN
, I
OUT
= 20 mA
2% accuracy
V
FB
= V
CE
= V
IN
= 4.0 V,
I
OUT
= 20 mA
6)
1 % accuracy
V
OUT(T)
≥ 3 V
V
CE
= V
IN
= V
OUT(T)
+ 3 V
V
OUT(T)
< 3 V
2.0 V ≤ V
OUT(T)
≤ 7.0 V
V
CE
= V
IN
, 1 mA ≤
I
OUT
≤ 50 mA
7.1 V ≤ V
OUT(T)
≤ 12.0 V
V
CE
= V
IN
, I
OUT
= 20 mA
V
CE
= V
IN
, V
FB
= V
OUT
, I
OUT
= 20 mA
6)
V
CE
= V
IN
, I
OUT
= 100 mA
V
CE
= V
IN
, V
FB
= V
OUT
, I
OUT
= 100 mA
6)
V
CE
= V
IN
V
CE
= 0 V
I
OUT
= 5 mA
V
OUT(T)
+ 2 V ≤ V
IN
≤ 28 V,
V
CE
= V
IN
I
OUT
= 13 mA
V
CE
= V
IN
, I
OUT
= 30 mA
- 40
0
C ≤ T
OPR
≤ 85
0
C
V
CE
= V
IN
, I
OUT
= 20 mA, f = 1 kHz
V
IN
= (V
OUT)T)
+ 2) V
DC
+ 0.5 V p-p
AC
V
CE
= V
IN
, V
IN
= V
OUT)T)
+ 2 V
Junction Temperature
5)
MIN.
2.0
1.96
1.98
150
100
TYP.
E-0
2.00
2.00
MAX.
28.0
2.04
2.02
UNIT
V
V
CIRCUIT
Maximum Output Current
Load Regulation
I
OUT_MAX
∆V
OUT
V
DIF1
mA
50
110
E-1
4)
450
E-2
4)
1900
5
0.01
0.05
0.15
± 100
30
30
150
25
90
140
600
2600
9
0.10
0.10
0.30
mV
Dropout Voltage
2)
mV
V
DIF2
Supply Current
Standby Current
Line Regulation
Output Voltage Temperature
Characteristics
Power Supply Rejection Ratio
Short Circuit Current
Thermal Shutdown Detect
Temperature
Thermal Shutdown
Hystetresis
CE “H” Level Voltage
5)
CE “L” Level Voltage
5)
CE “H” Level Current
5)
CE “L” Level Current
5)
FB Pin Resistance
NOTE:
PSRR
I
SHORT
T
TSD
T
HYS
V
CEH
V
CEL
I
CEH
I
CEL
R
FB
I
SS
I
STB
1
µA
µA
%/V
ppm/
0
C
dB
mA
0
C
C
0
V
CE
= V
IN
= 28.0 V
V
IN
= 28.0 V, V
CE
= V
SS
V
FB
= V
IN
= V
OUT
= 5.0 V, V
CE
= V
SS
1.1
0
-0.1
-0.1
1.70
4.10
V
IN
0.35
0.1
0.1
6.30
V
V
µA
µA
MΩ
Unless otherwise stated, V
IN
= V
CE
= V
OUT (T)
+2.0 V
1) V
OUT (T)
is Nominal output voltage and V
OUT (E)
is Effective output voltage, (I.e. the output voltage when "V
OUT (T)
+1.0V" is provided at the
V
IN
pin, while maintaining a certain I
OUT
value).
2) V
DIF
= {V
IN
-V
OUT
}, where V
IN1
is the input voltage when V
OUT
= 0.98 V
OUT(T)
appears, while input voltage gradually decreases
3) Refer to the Table “Voltage Chart, Output Voltage”
4) Refer to the Table “Voltage Chart, Dropout Voltage”
5) IXD1216B/C versions only
6) IXD1216C version only
PS033901-0515
PRELIMINARY
3
