LFCN-2000D: Description5 SECTIONS - 5 SECTIONS, 2275 MHz, CERAMIC LPF; CategoryAnalog mixed-signal IC filter; File Size134KB，1 Pages; ManufacturerMini-Circuits; Websitehttps://www.minicircuits.com

Download Datasheet Parametric Compare View All

LFCN-2000D Overview

5 SECTIONS - 5 SECTIONS, 2275 MHz, CERAMIC LPF

LFCN-2000D Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Reach Compliance Code	unknow
Other features	TAPE AND REEL
Maximum attenuation frequency (+/- delta f)	1225000 kHz
Attenuation frequency (+/-Δf) - minimum value	725000 kHz
Attenuation at maximum frequency	30 dB
Attenuation@frequency min	20 dB
average input power	9 W
Center frequency or cutoff frequency (fo/fc)	2275 MHz
filter type	CERAMIC LPF
high	0.94 mm
Input/output impedance	50 OHM
Maximum insertion loss	3 dB
JESD-609 code	e0
length	3.2 mm
Manufacturer's serial number	LFCN-2000
Installation type	SURFACE MOUNT
Number of partitions-max	5
Number of partitions - minimum	5
Maximum operating temperature	100 °C
Minimum operating temperature	-55 °C
physical size	L3.2XB1.6XH0.94 (mm)/L0.126XB0.063XH0.037 (inch)
Terminal surface	Tin/Lead (Sn/Pb)
voltage standing wave ratio	1.3
width	1.6 mm
Base Number Matches	1

Preview

Download Datasheet

View All

Ceramic

Low Pass Filter

DC to 2000 MHz

Maximum Ratings

Operating Temperature

Storage Temperature

RF Power Input*

DC Current Input to Output

-55°C to 100°C

9W max. at 25°C

1A max. at 25°C

EW!

LFCN-2000

Features

•

excellent power handling, 9W

small size

5 sections

temperature stable

patent pending

CASE STYLE: FV1206

Model

LFCN-2000

LFCN-2000D

Price

$1.99

$2.49

Qty.

(10-49)

*Passband rating, derate linearly to 4W at 100°C ambient.

Applications

• harmonic rejection

• VHF/UHF transmitters/receivers

• lab use

Pin Connections

RF IN

RF OUT

GROUND

**RF IN & RF OUT can be interchanged

1**

3**

2,4

Low Pass Filter Electrical Specifications

AMB

=25°C)

MODEL

NO.

PASSBAND

(MHz)

(loss < 1.5 dB)

Max.

LFCN-2000

DC-2000

Outline Drawing

fco, MHz

Nom.

(loss 3 dB)

Typ.

2275

STOP BAND (MHz)

(loss, dB)

f 20

Min.

3000

Typ.

3100-3500

fr 20

Typ.

4600

VSWR (:1)

Stopband

Typ.

Passband

Typ.

1.3

NO. OF

SECTIONS

1. For Applications requiring DC voltage to be applied to the Input or output, use LFCN-2000D (DC Resistance to

ground is 100 Mohms min.)

typical frequency response

ATTENUATION (dB)

40dB

20dB

schematic

RF IN

RF OUT

3dB

1dB

f co f 20

FREQUENCY

fR 20 dB

Typical Performance Data at 25°C

Frequency

(MHz)

10.00

258.75

507.50

756.25

1005.00

1253.75

1502.50

1751.25

2250.00

2500.00

2750.00

3000.00

4244.00

4422.00

4600.00

Insertion Loss

(dB)

0.14

0.30

0.35

0.51

0.49

0.56

0.60

0.74

4.73

11.34

19.65

32.99

20.09

19.52

20.32

VSWR

(:1)

1.04

1.19

1.23

1.28

1.21

1.18

1.14

1.13

5.33

16.41

43.44

102.19

217.15

66.82

46.96

Outline Dimensions (

inch

)

.126

3.20

.024

0.61

.063

1.60

.122

3.10

.039

0.99

.024

0.61

.020

0.51

.087

2.21

.032

0.81

.012

0.30

.009

0.23

.169

4.29

.087

2.21

wt.

.071 grams

1.80

.020

Demo Board MCL P/N: TB-270

Suggested PCB Layout (PL-137)

LFCN-2000

INSERTION LOSS

1000

LFCN-2000

VSWR

INSERTION LOSS (dB)

1000

2000

3000

4000

5000

FREQUENCY (MHz)

1000

2000

3000

4000

5000

FREQUENCY (MHz)

100

VSWR

designers kit available

Kit

No.

K2-LFCN

No. of

Units in Kit

Description

5 of each: LFCN-800,-900,-1000,-1200,-1325,-1700,

-2000,-2250,-2400,-5000,-6000,-6700

Price $

per Kit

119.95

Mini-Circuits

INTERNET

http://www.minicircuits.com

P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661

Distribution Centers

NORTH AMERICA 800-654-7949 • 417-335-5935 • Fax 417-335-5945 • EUROPE 44-1252-832600 • Fax 44-1252-837010

Mini-Circuits

ISO 9001 & ISO 14001

Certified

REV. F

M96263

LFCN-2000

ED-9913/4

AD/RS/CP

050113
