LFCN-2500D datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> filter> LFCN-2500D

LFCN-2500D: Description7 SECTIONS - 7 SECTIONS, 3075 MHz, CERAMIC LPF; CategoryAnalog mixed-signal IC filter; File Size132KB，1 Pages; ManufacturerMini-Circuits; Websitehttps://www.minicircuits.com

Download Datasheet Parametric Compare View All

LFCN-2500D Overview

7 SECTIONS - 7 SECTIONS, 3075 MHz, CERAMIC LPF

LFCN-2500D Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Reach Compliance Code	unknow
Other features	TAPE AND REEL
Maximum attenuation frequency (+/- delta f)	3025000 kHz
Attenuation frequency (+/-Δf) - minimum value	600000 kHz
Attenuation at maximum frequency	40 dB
Attenuation@frequency min	20 dB
average input power	10 W
Center frequency or cutoff frequency (fo/fc)	3075 MHz
filter type	CERAMIC LPF
high	0.94 mm
Input/output impedance	50 OHM
Maximum insertion loss	3 dB
JESD-609 code	e0
length	3.2 mm
Manufacturer's serial number	LFCN-2500
Installation type	SURFACE MOUNT
Number of partitions-max	7
Number of partitions - minimum	7
Maximum operating temperature	100 °C
Minimum operating temperature	-55 °C
physical size	L3.2XB1.6XH0.94 (mm)/L0.126XB0.063XH0.037 (inch)
Terminal surface	Tin/Lead (Sn/Pb)
voltage standing wave ratio	1.2
width	1.6 mm
Base Number Matches	1

Preview

Download Datasheet

View All

Ceramic

Low Pass Filter

DC to 2500 MHz

Maximum Ratings

Operating Temperature

Storage Temperature

RF Power Input*

-55°C to 100°C

10W max. at 25°C

EW!

LFCN-2500

Features

•

excellent power handling, 10W

small size

7 sections

temperature stable

patent pending

CASE STYLE: FV1206

Model

LFCN-2500

LFCN-2500D

Price

$1.99

$2.49

Qty.

(10-49)

DC Current Input to Output 0.5A max. at 25°C

*Passband rating, derate linearly to 3.5W at 100°C ambient.

Applications

• harmonic rejection

• VHF/UHF transmitters/receivers

• lab use

Pin Connections

RF IN

RF OUT

GROUND

**RF IN & RF OUT can be interchanged

1**

3**

2,4

Low Pass Filter Electrical Specifications

AMB

=25°C)

MODEL

NO.

PASSBAND

(MHz)

(loss < 1 dB)

Max.

LFCN-2500

DC-2500

Outline Drawing

fco, MHz

Nom.

(loss 3 dB)

Typ.

3075

STOP BAND (MHz)

(loss, dB)

f 20

Min.

3675

Typ.

3800-6100

fr 20

Typ.

8000

VSWR (:1)

Stopband

Typ.

Passband

Typ.

1.2

NO. OF

SECTIONS

1. For Applications requiring DC voltage to be applied to the Input or output, use LFCN-2500D (DC Resistance to

ground is 100 Mohms min.)

typical frequency response

RF IN

ATTENUATION (dB)

40dB

20dB

schematic

RF OUT

3dB

1dB

f co f 20

FREQUENCY

fR 20 dB

Typical Performance Data at 25°C

Frequency

(MHz)

2000

2530

3000

3660

3760

4000

5000

6000

7000

8000

10000

12000

15000

20000

Insertion Loss

(dB)

0.05

0.50

0.80

2.72

24.30

29.63

43.19

34.98

34.38

26.29

22.85

19.22

14.60

17.48

15.48

VSWR

(:1)

1.02

1.26

1.24

2.58

23.81

28.03

31.03

26.33

24.48

26.74

27.59

18.30

13.09

3.73

4.84

Outline Dimensions (

inch

)

.126

3.20

.087

2.21

.063

1.60

.024

0.61

.037

0.94

.122

3.10

.020

0.51

.024

0.61

.032

0.81

.087

2.21

.009

0.23

.012

0.30

.169

4.29

.071 grams

1.80

.020

Demo Board MCL P/N: TB-270

Suggested PCB Layout (PL-137)

50.0

INSERTION LOSS (-dB)

40.0

LFCN-2500

INSERTION LOSS

1000

LFCN-2500

VSWR

20.0

10.0

0.0

5000

10000

15000

20000

FREQUENCY (MHz)

VSWR

5000

10000

15000

20000

FREQUENCY (MHz)

30.0

100

Mini-Circuits

INTERNET

http://www.minicircuits.com

P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661

Distribution Centers

NORTH AMERICA 800-654-7949 • 417-335-5935 • Fax 417-335-5945 • EUROPE 44-1252-832600 • Fax 44-1252-837010

Mini-Circuits

ISO 9001 & ISO 14001

Certified

REV. B

M96263

LFCN-2500

EDR-6783/2

RVN/AD/CP

050113

LFCN-2500D Related Products

	LFCN-2500D	LFCN-2500
Description	7 SECTIONS - 7 SECTIONS, 3075 MHz, CERAMIC LPF	7 SECTIONS - 7 SECTIONS, 3075 MHz, CERAMIC LPF
Is it lead-free?	Contains lead	Contains lead
Is it Rohs certified?	incompatible	incompatible
Reach Compliance Code	unknow	compliant
Other features	TAPE AND REEL	TAPE AND REEL
Maximum attenuation frequency (+/- delta f)	3025000 kHz	725000 kHz
Attenuation frequency (+/-Δf) - minimum value	600000 kHz	600000 kHz
Attenuation at maximum frequency	40 dB	40 dB
Attenuation@frequency min	20 dB	20 dB
average input power	10 W	10 W
Center frequency or cutoff frequency (fo/fc)	3075 MHz	3075 MHz
filter type	CERAMIC LPF	CERAMIC LPF
high	0.94 mm	0.94 mm
Input/output impedance	50 OHM	50 OHM
Maximum insertion loss	3 dB	3 dB
JESD-609 code	e0	e0
length	3.2 mm	3.2 mm
Installation type	SURFACE MOUNT	SURFACE MOUNT
Number of partitions-max	7	7
Number of partitions - minimum	7	7
Maximum operating temperature	100 °C	100 °C
Minimum operating temperature	-55 °C	-55 °C
physical size	L3.2XB1.6XH0.94 (mm)/L0.126XB0.063XH0.037 (inch)	L3.2XB1.6XH0.94 (mm)/L0.126XB0.063XH0.037 (inch)
Terminal surface	Tin/Lead (Sn/Pb)	Tin/Lead (Sn10Pb90)
voltage standing wave ratio	1.2	1.2
width	1.6 mm	1.6 mm
Base Number Matches	1	1
