IMO Series Data Sheet
6 Watt DC-DC Converters
Input voltage range up to 72 V DC
1 or 2 outputs up to 30 V DC
1500 V DC I/O electric strength test voltage
• Wide input range
• Short circuit protection
• Industry standard 2" x 1" foot print
Model Selection
Output 1
V
o nom
I
o nom
[V DC] [mA]
3.3
1500
3.3
1500
5
1000
5
1000
12
500
12
500
15
400
15
400
+5
500
+5
500
+12
250
+12
250
+15
200
+15
200
Output 2
V
o nom
I
o nom
[V DC] [mA]
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
–5
500
–5
500
–12
250
–12
250
–15
200
–15
200
Input voltage
V
i
[V DC]
10 - 36
18 - 72
10 - 36
18 - 72
10 - 36
18 - 72
10 - 36
18 - 72
10 - 36
18 - 72
10 - 36
18 - 72
10 - 36
18 - 72
Rated power
T
A
= 71°C
P
o tot
[W]
5
5
5
5
6
6
6
6
5
5
6
6
6
6
Type
Option
24
48
24
48
24
48
24
48
24
48
24
48
24
48
IMO
IMO
IMO
IMO
IMO
IMO
IMO
IMO
IMO
IMO
IMO
IMO
IMO
IMO
6-03-2
6-03-2
6-05-2
6-05-2
6-12-2
6-12-2
6-15-2
6-15-2
6-0505-2
6-0505-2
6-1212-2
6-1212-2
6-1515-2
6-1515-2
-7
-7
-7
-7
-7
-7
-7
-7
-7
-7
-7
-7
-7
-7
Input
Input voltage
Model numbers highlighted in yellow or shaded are not recommended for new designs.
Reverse voltage protection
continuous range, 24 V
continuous range, 48 V
shunt diode
10 - 36 V DC
18 - 72 V DC
Output
Output voltage setting accuracy
V
i nom
, l
o nom
Minimum load
not required
Line regulation
V
i min
-
V
i max
, l
o nom
Load regulation
V
i nom
,
0 - 100%
l
o nom
,
single output models
dual output models
Ripple and noise
V
i nom
,
0 - 100%
l
o nom
,
peak-peak, total
Efficiency
V
i nom
, l
o nom
±2%
V
o nom
±1%
V
o nom
2%
V
o nom
max. 5%
V
o nom
max. 3%
V
o nom
up to 80%
Control and protection
Overload protection
No-load protection
V
i min
,
full load
150%
P
i nom
REV.
JUN 08, 2004
Page 1 of 2
IMO Series Data Sheet
6 Watt DC-DC Converters
Safety and EMC
Electric strength test voltage
Electromagnetic interference
I/O
conducted
conducted with external filter
1500 V DC
class A
class B
Environmental
Operating ambient temperature
Storage temperature
Relative humidity
MTBF
V
i nom
, l
o nom
non operational
non condensing
MIL-HDBK-217F, N2
–10 to 50°C
–40 to 100°C
95%
>3'000'000 h
Options
Extended temperature range
–25 - 71°C, ambient, operating
-7
Accessories
DIN and chassis mounting bracket
Mechanical data
Tolerances ±0.3 mm (0.012") unless otherwise indicated.
5 (0.2")
50.8 (2")
S09112
European
Projection
1
2
4
¯ 1 (0.04")
5
12 (0.47")
20.32 (0.8")
Pin allocation
Pin
1
2
3
4
5
Single output
Vi+
Vi–
Vo+
no pin
Vo–
Dual output
Vi+
Vi–
Vo+
COM
Vo–
NUCLEAR AND MEDICAL APPLICATIONS - Power-One products are not authorized for use as critical components in life support
systems, equipment used in hazardous environments, or nuclear control systems without the express written consent of the respective
divisional president of Power-One, Inc.
TECHNICAL REVISIONS - The appearance of products, including safety agency certifications pictured on labels, may change
depending on the date manufactured. Specifications are subject to change without notice.
REV.
JUN 08, 2004
Page 2 of 2
2 x 10.16 (0.4")
5.08 (0.2")
3
25.4 (1")
