AS85049/53, AS85049/54 and AS85049/55
Straight, 45° and 90° Qwik-Ty Strain Reliefs
Optional Self-Locking • Optional Ground Lug
Qwik-Ty®
Strain Reliefs
CONNECTOR DESIGNATOR:
AS50151 Series AS34001
MIL-DTL-26482 Series II
AS81703 Series III
MIL-DTL-83723 Series I and III
40M39569, DEF 5326-3, EN2997
EN3646, ESC 10, ESC 11, LN 29504
NFC93422 Series HE302
PAN 6432-1, PAN 6432-2, PATT 602
A
Configuration
––
= Non-Self-Locking
N
= Non-Detented
G
= Self-Locking with Ground Lug
H
= Non-Detented with Ground Lug
S
= Self-Locking without Ground Lug
Shell
Size
Finish
A
= Anodize, Black
N
= Electroless Nickel
W
= 1,000 Hour Cadmium Olive Drab
over Electroless Nickel
X
= Pure Dense Electrodeposited
Aluminum
Y
= Passivated
Z
= Zinc-Nickel, Black
OPTIONAL
SELF-LOCKING
COUPLING
Basic Part Number
M85049/53
= Straight
M85049/54
= 45°
M85049/55
= 90°
M85049/55
G
22
N
FOR NEW DESIGN APPLICATIONS USE
M85049/43 (45°), M85049/51 (90°) and M85049/52 (Straight)
45
TABLE I: Shell Size, Thread, Cable Entry and Backshell Dimensions
Shell
Size
03
08
10
12
14
16
18
20
22
24
28
A Thread
Class 2B
562 - 24 UNEF
.500 - 20 UNF
.625 - 24 UNEF
.750 - 20 UNEF
.875 - 20 UNEF
1.000 - 20 UNEF
1.062 - 18 UNEF
1.188 - 18 UNEF
1.313 - 18 UNEF
1.438 - 18 UNEF
1.750 - 18 UNS
C Dia
Max
.780
.660
.780
.940
1.050
1.240
1.380
1.500
1.630
1.750
1.970
(19.8)
(16.8)
(19.8)
(23.9)
(26.7)
(31.5)
(35.1)
(38.1)
(41.4)
(44.5)
(50.0)
E Dia
Max
1.010
.890
1.010
1.140
1.260
1.390
1.510
1.640
1.760
1.890
2.140
(25.7)
(22.6)
(25.7)
(29.0)
(32.0)
(35.3)
(38.4)
(41.7)
(44.7)
(48.0)
(54.4)
F
Cable Entry
.260
.260
.365
.501
.575
.700
.779
.904
1.029
1.144
1.379
(6.6)
(6.6)
(9.3)
(12.7)
(14.6)
(17.8)
(19.8)
(23.0)
(26.1)
(29.1)
(35.0)
G
Max
.954
.954
.954
.954
1.204
1.204
1.204
1.310
1.430
1.560
1.560
(24.0)
(24.0)
(24.0)
(24.0)
(30.6)
(30.6)
(30.6)
(33.3)
(36.3)
(39.6)
(39.6)
H
Max
1.232
1.232
1.232
1.232
1.232
1.232
1.232
1.482
1.482
1.482
1.469
(31.3)
(31.3)
(31.3)
(31.3)
(31.3)
(31.3)
(31.3)
(37.6)
(37.6)
(37.6)
(37.3)
J
Max
.730 (18.5)
.730 (18.5)
.730 (18.5)
.730 (18.5)
.730 (18.5)
.730 (18.5)
.730 (18.5)
.750 (19.1)
.750 (19.1)
.750 (19.1)
.750 (19.1)
K
Max
1.290
1.290
1.290
1.620
1.660
1.720
1.720
1.790
1.850
1.910
2.060
(32.8)
(31.0)
(32.8)
(41.1)
(42.2)
(43.7)
(43.7)
(45.5)
(47.0)
(48.5)
(52.3)
APPLICATION NOTES
1.
2.
3.
4.
Assembly identified with manufacturer’s name and part number, space permitting.
For complete dimensions, see the applicable Military Specification.
Cable entry is defined as the accomodation range for the wire bundle or cable. Dimensions shown are not
intended for inspection criteria.
Metric dimensions (mm) are in parentheses.
© 2012 Glenair, Inc.
CAGE Codes 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
E-Mail: sales@glenair.com
www.glenair.com
45-4
