70-401-1 Socket/10
Amp Rating, 300 Volts
SECTION 2
Chassis Mounting
BOLD-FACED PART NUMBERS ARE NORMALLY STOCKED
Standard Part Number
Description
UL Recognized
File No. E70550
Certified
97899
70-401-1
(UL 508)
Units
Value
8
300
10
1500
1500
- 40 to + 80
- 40 to + 105
Copper Alloy, Zinc Plated
Copper Alloy, Zinc Plated
Chassis
AWG
mm2
18
0.8
18
0.8
Solder
94V-0
Light Gray
UL, CSA
CE, RoHS
6.2
8-Pin, Solder, Quick Connect
Terminals for Chassis Mount.
General Specifications
WHITE
Characteristics
Number of Terminals
Electrical Rating
Nominal Voltage Rating
Nominal Current Rating
Dielectric Strength
Output to Input Terminals
Output to Adjacent Output Terminals
Temperature
Operating Range:
Storage Range:
Construction
Internal Metal Tracks
Terminals
Miscellaneous
Socket Mounting:
Wire Size Capacity (Maximum)
Soild Cu (Output)
Stranded Cu (Output)
Wire Connection Method
Flamability Rating
Body Color
Product Certification
Conformance
Weight
Volts
Amps
V rms
V rms
°C
°C
EN 60204-1
AWG, mm2
AWG, mm2
Class
grams
2/52
M a gn e c r a ft S o lu t io n G ui de 1 0 5 A
www.magnecraft.com
847-441-2540
Optional Mating Accessories
SECTION 2
782 Relays
16-1324
16-1342
Standard Part Number
782XAX, XBX
16-1324
16-1342
Description
Metal Hold-Down Clip, Front to Back Mount, 782 Plain Cover Relay Only
Metal Hold-Down Clip, Side Mount
Relay
Catalog Location
Section 1 p.12-13
Section 3 p.8-11
Section 3 p.8-11
16-1342
Metal Hold-Down Clip
See Section 3 p.8-11
.430
(10.9)
.075
(1.90)
.390
(9.9)
.185
(4.69)
.100
(2.5)
.180
(4.57)
1.14
(28.9)
.702
(17.8)
0.83
(21)
.417
(10.5)
.078
(1.98)
0.27
(7)
2.01
(51)
.070
(1.77)
.350
(8.89)
.072 X .140
(1.8 X 3.55)
0.86
(21.5)
.300
(7.62)
.155 DIA.
(3.93)
1
12
5
14
4
42
8
44
12
41
13
A1
N.C.
N.O.
COM
INPUT
1.01
(25.7)
RECOMMENDED
CHASSIS CUTOUT
TOP VIEW
.012
(0.304)
(8)
NEMA
IEC
9
11
14
A2
.340
(8.63)
Wiring Diagram
Top View
Magnecra f t So l u t io n Gu i de 1 0 5 A
2/53
