801-039-26MT10-26GF datasheet, PDF

Datasheet> All Categories > The connector> The connector> 801-039-26MT10-26GF

801-039-26MT10-26GF: DescriptionCircular Connector; CategoryThe connector The connector; File Size195KB，2 Pages; ManufacturerGlenair; Websitehttp://www.glenair.com/

Download Datasheet Parametric View All

801-039-26MT10-26GF Overview

Circular Connector

801-039-26MT10-26GF Parametric

Parameter Name	Attribute value
Objectid	1315758796
Reach Compliance Code	compliant
Connector type	CIRCULAR CONNECTOR
Manufacturer's serial number	801-039

Preview

Download Datasheet

View All

801-036 and 801-039

Series 801 Mighty Mouse

High-Speed

Double-Start ACME Threads

Plug Connector Ordering Information

Series 801

Mighty Mouse

Series 801

High-Speed

Plug Connector

Glenair Series 801 Mighty Mouse High-Speed

connectors feature double-start

modified stub ACME mating threads for improved protection against cross-mating

and thread damage. Connector shells are machined aluminum or stainless steel. The

connector is equipped with special PFA (Teflon) insulators and is optimized for use

with high-speed differential wire such as our 963-001 cable. Five insert arrangements

are offered with 4, 7, 10, 19 and 26 #23 AWG contacts, packaged separately. Terminate

contacts with standard M22520 tools. Metal clips inside the connector body lock

contact into place. Contacts are removable. Fluorosilicone seals and rear grommet

protect connector from water ingress. Terminate cable shield directly to connector

body with Band-Master™ ATS strap, or choose rear accessory thread to attach optional

cable clamp or backshell.

How To Order

Sample Part Number

801-036

Series

-16

Shell Style

Shell Material / Finish

7-10

Shell Size- Insert

Arrangement

Contact Type

Shell Key

Position

Plug with Anti-

Decoupling

Spring

Banding Platform

-16

Aluminum / Electroless Nickel

roHS Compliant

Aluminum / Cadmium with

olive Drab Chromate

Aluminum / Zinc-Nickel with

Black Chromate

Aluminum / Nickel-PTFE

roHS Compliant

Connector supplied

with contacts

Pin Connector,

Less Contacts

Normal

Alternate

Key

Positions:

801-036

Self-Locking

Plug with

ratchet

Mechanism

(the "Clicker")

-26

6-4

ZNU

Socket Connector,

Less Contacts

6-7

Socket

Pin with 30 AWG

Crimp Barrel

Socket with 30 AWG

Crimp Barrel

Connectors with

contacts are supplied

with signal crimp

contacts. These

contacts are not

installed.

rear Accessory

Thread

801-039

Stainless Steel / Passivated

roHS Compliant

7 - 10

9 - 19

6 3

2 4

10-26

U.S. CAGE Code 06324

Printed in U.S.A.

GLENAIR, INC.

•

1211 AIR WAY

•

GLENDALE, CA 91201-2497

•

818-247-6000

•

FAX 818-500-9912

www.glenair.com

B-4
