Product data sheet
Characteristics
ZCP21
limit switch body ZCP - compact - 1NC+1NO -
snap action
Main
Range of product
Series name
Product or component
type
Device short name
Design
Body type
Associated head
OsiSense XC
Standard compact
Limit switch body
ZCP
Compact
Fixed
ZCE01
ZCE02
ZCE05
ZCE06
ZCE07
ZCE08
ZCE09
ZCE10
ZCE11
ZCE13
ZCE14
ZCE21
ZCE24
ZCE27
ZCE28
ZCE29
ZCE62
ZCE63
ZCE64
ZCE65
ZCE66
ZCE67
ZCEH0
ZCEH2
Plastic
2
1 NC + 1 NO
Snap action
Body material
Number of poles
Contacts type and com-
position
Contacts operation
Complementary
Associated connection component
ZCPEF12
ZCPEG11
ZCPEG13
ZCPEN12
ZCPEP16
ZCPEP20
Screw-clamp terminals, clamping capacity: 1 x 0.34...2 x 1.5 mm²
Zb
Silver plated contacts
With
0.01 m/s
R300, DC-13 (Ue = 250 V, Ie = 0.1 A) conforming to EN/IEC 60947-5-1 appendix
A
B300, AC-15 (Ue = 240 V, Ie = 1.5 A) conforming to EN/IEC 60947-5-1 appendix
A
300 V conforming to CSA C22.2 No 14
500 V degree of pollution 3 conforming to IEC 60947-1
300 V conforming to UL 508
1
Electrical connection
Contacts insulation form
Contacts material
Positive opening
Minimum actuation speed
Contact code designation
[Ui] rated insulation voltage
Jan 20, 2013
The information provided in this documentation contains general descriptions and/or technical characteristics of the performance of the products contained herein.
This documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of these products for specific user applications.
It is the duty of any such user or integrator to perform the appropriate and complete risk analysis, evaluation and testing of the products with respect to the relevant specific application or use thereof.
Neither Schneider Electric Industries SAS nor any of its affiliates or subsidiaries shall be responsible or liable for misuse of the information contained herein.
[Uimp] rated impulse withstand voltage
Short circuit protection
Electrical durability
6 kV conforming to IEC 60947-1
6 kV conforming to IEC 60664
10 A by gG cartridge fuse
5000000 cycles, DC-13 48 V, 7 W, operating rate: < 60 cyc/mn, load factor: 0.5
conforming to IEC 60947-5-1 appendix C
5000000 cycles, DC-13 24 V, 10 W, operating rate: < 60 cyc/mn, load factor: 0.5
conforming to IEC 60947-5-1 appendix C
5000000 cycles, DC-13 120 V, 4 W, operating rate: < 60 cyc/mn, load factor: 0.5
conforming to IEC 60947-5-1 appendix C
31 mm
65 mm
30 mm
0.07 kg
Width
Height
Depth
Product weight
Environment
Product compatibility
Ambient air temperature for operation
Ambient air temperature for storage
XCKP
-25...70 °C
-40...70 °C
Offer Sustainability
Sustainable offer status
RoHS
REACh
Product environmental profile
Product end of life instructions
Green Premium product
Compliant - since 1002 -
Available
Available
Schneider Electric declaration of conformity
Reference not containing SVHC above the threshold
Download Product Environmental
Download End Of Life Manual
Contractual warranty
Period
18 months
2
