Harmony XB5R
™
Wireless, Batteryless Push Button
Better control of your operations anytime, anywhere
Utilizing wireless technology, the Harmony XB5R wireless, batteryless push
button is easy to install in both new and existing applications, such as bottling,
packaging and conveying lines. Now, you no longer need to pass a cable
through the machine structure or cable tray to connect the push button to the
electrical panel – cutting installation costs by 20% as compared to traditional
wired solutions.
When the operator pushes the button, mechanical energy is transformed into
electrical energy, which sends a one-time radio message to one or multiple
receivers. In addition, up to 32 push buttons can be synched to a receiver,
providing even greater mobility in any environment. This batteryless solution
offers permanent availability, benefits the environment and eliminates costly
battery maintenance, re-charging and recycling.
Key features
• Quick and easy installation
• Eliminates wires and cables
• Flexible due to its mobility
• Greater control and mobility for operators
• Maintenance-free
The wireless technology helps to achieve greater productivity by providing
operators with greater freedom and mobility, allowing them to remotely control
machines at a distance of up to 25 meters in a factory environment. Similar to
other Harmony products, the wireless, batteryless push button is well-suited
for harsh industrial environments, where added protection of your people and
machines is paramount.
Reduction of wiring
• Conveying systems
• Automation systems
• Facility applications (fan control, lighting control)
• Eliminate conduit in wash down environments
Flexibility in industrial environments
• Kanban systems (inventory management)
• Call systems for work stations
Operator mobility
Scan the code and watch
how to program the
Harmony XB5R push button
• Fork trucks/garage doors
• Gate operations from a truck
• Portable operator control (on the person)
• Palletizer systems
• AGV call management
Applications
• Assembly lines
• Automotive
• Bottling
• Complex and special machines • Food and beverage
• Control and monitoring
• Packaging
• Data centers
Make the most of your energy
SM
Select the product for your needs
Catalog Number
Packages
XB5RFB01
XB5RFA02
XB5RMB03
XB5RMA04
Description
Pack XB5R 22 mm transmitter no-programmable receiver 24 VDC
Pack XB5R 22 mm transmitter programmable receiver AC/DC
Pack XB5R handheld transmitter no-programmable receiver 24 VDC
Pack XB5R handheld transmitter programmable receiver AC/DC
Components Transmitters
Transmitter
ZBRT1
Transmitter wireless batteryless (without head)
Transmitter ZB5R head, caps white without marking
Transmitter ZB5R head, caps black without marking
Transmitter ZB5R head, caps green without marking
Transmitter ZB5R head, caps green marking I white
Transmitter ZB5R head, caps red without marking
Transmitter ZB5R head, caps red marking O white
Transmitter ZB5R head, caps yellow without marking
Transmitter ZB5R head, caps blue without marking
ZB5R push button head spring return without cap
Transmitter ZB4R head, caps white without marking
Transmitter ZB4R head, caps black without marking
Transmitter ZB4R head, caps green without marking
Transmitter ZB4R head, caps green marking I white
Transmitter ZB4R head, caps red without marking
Transmitter ZB4R head, caps red marking O white
Transmitter ZB4R head, caps yellow without marking
Transmitter ZB4R head, caps blue without marking
ZB4R push button head spring return without cap
Caps set of 10 different colors
Relay antenna, AC/DC, 5 m cable output
Control station SPS empty 1 hole
Receiver programmable AC/DC – 2 relays change over output
Receiver programmable DC – 4 PNP outputs
© 2011 Schneider Electric. All Rights Reserved.
Plastic Head
ZB5RTA1
ZB5RTA2
ZB5RTA3
ZB5RTA331
ZB5RTA4
ZB5RTA432
ZB5RTA5
ZB5RTA6
ZB5RZA0
Metal Head
ZB4RTA1
ZB4RTA2
ZB4RTA3
ZB4RTA331
ZB4RTA4
ZB4RTA432
ZB4RTA5
ZB4RTA6
ZB4RZA0
Accessories
ZBA79
ZBRA1
ZBRM01
Components Receivers
ZBRRA
ZBRRC
