6000 series
Toggle switches for military applications
Distinctive features and specifications
❑
Suitable for military applications (portable measuring
equipment generators, beacons, fixed and mobile
radiotransmitters)
A
❑
Sealing and locking lever options available
❑
Matt black finish on actuator and bushing
ELECTRICAL SPECIFICATIONS
• Max. current/voltage rating : see table below
• Initial contact resistance : 10 mΩ max. at 1A 2VDC
• Insulation resistance : 1.000 MΩ min. at 500VDC
• Dielectric strength :
2.000 Vrms 50 Hz min. between terminals
3.000 Vrms 50 Hz min. between terminals and frame
• Electrical life : 10.000 cycles at full load
CURRENT/VOLTAGE RATING
30VDC
Resistive load
Inductive load
Lamp load
6,5A
5A
3A
250VAC
5A
3A
1A
125VAC
10A
6A
3A
115V 400Hz
7A
5A
3,5A
MATERIALS
GENERAL SPECIFICATIONS
• Case : diallylphthalate (DAP)
• Actuator : brass, chrome
plated, black
• Bushing : brass, chrome plated,
black
• Contacts :
A
: silver
• Torque : 1,50 Nm (1.10 Ft.lb) max. applied to nut
• Panel thickness : 5 mm (.196) max.
• Operating temperature : -40°C to +85°C
ABOUT THIS SERIES
Dimensions
: first dimensions are in mm while inches are shown as bracketted numbers.
Security caps
are available to prevent inadvertent lever operation. They are presented in section I.
Sealing boots
are available to protect the switches against dust and water. They are presented in section H.
Mounting accessories
: standard hardware supplied with all models : 2 matt black nuts U41, matt black locking ring U12,
zinc plated lockwasher U13
They are presented in section I.
Packaging unit
: 25 pieces, except model 6421 (20 pieces)
A-118
www.apem.com
APEM
6000 series
Toggle switches for military applications
➞
Keyway
•
Screw terminals standard
• Solder lug or quick-connect terminals optional
• 1, 2, 3 and 4-pole configurations
Ø3.00x0.5 SI
(.118DIAx0.5 IS)
3.00
(.118)
7.00
(.275)
1
2
3
2
1
1 pole
2, 3 and 4 pole
6.35x0.80
(.25x.031)
A
MODEL
STRUCTURE
Single pole
I
II
➞
Keyway
14.00
(.551)
17.50
(.689)
11.00
(.433)
21.00
(.826)
6421A-03
ON
-
OFF
17.00
(.669)
II
30˚
I
˚11.90 32NS
(15/32" 32NS)
19.50
(.767)
Double pole
III
2-1
5-4
6641-03
6642-03
6643-03
6644-03
▲
6645-03
6646-03
6647-03
6648-03
6649-03
ON
ON
MOM
ON
MOM
ON
MOM
ON
ON
II
I
2-3
5-6
➞
Keyway
17.50
(.689)
11.50
(.453)
27.50
(1.082)
-
OFF
- mom.OFF
-
OFF
ON
ON
-
ON
-
ON
OFF
MOM
OFF
MOM
OFF
ON
1
33.60
(1.323)
4
10.00 10.00
(.393) (.393)
I
II
3
6
III
Ø11.90 32NS
(15/32" 32NS)
▲
Function 4 : SP in DP case, see end of catalogue.
Three pole
III*
6651-03
6652-03
6653-03
6655-03
6656-03
6657-03
6658-03
6659-03
* (2-1) (5-4) (8-7)
➞
Keyway
II
I**
1
34.50
(1.358)
4
7
I
34.00
(1.338)
2
5
8
II
30˚
17.50
(.689)
11.50
(.453)
32.00
(1.26)
ON
ON
MOM
MOM
ON
MOM
ON
ON
-
OFF
- mom.OFF
-
OFF
-
ON
-
ON
OFF
MOM
OFF
MOM
OFF
ON
III
Ø11.90 32NS
(15/32" 32NS)
3
12.00
(.472)
6
12.00
(.472)
9
** (2-3) (5-6) (8-9)
APEM
www.apem.com
36˚
2
5
A-119
6000 series
Toggle switches for military applications
Four pole
III*
6661-03
6662-03
6663-03
6664-03
▲
6665-03
6666-03
6667-03
6668-03
6669-03
* (2-1) (5-4) (8-7) (11-10)
➞
Keyway
II
I**
1
4
46.50
(1.83)
7
10
I
34.00
(1.338)
2
5
8
11
30˚
II
17.50
(.689)
11.50
(.453)
32.00
(1.26)
A
ON
ON
MOM
ON
MOM
ON
MOM
ON
ON
-
OFF
- mom.OFF
-
OFF
ON
ON
-
ON
-
ON
OFF
MOM
OFF
MOM
OFF
ON
3
9
6
11.00 11.00
(.433) (.433)
12
11.00
(.433)
III
Ø11.90 32NS
(15/32" 32NS)
** (2-3) (5-6) (8-9) (11-12)
▲
Function 4 : 2P in 4P case, see end of catalogue.
STANDARD PANEL CUT
-
OUT
Ø12.20
(.48DIA)
Ø12.20
(.48DIA)
Ø12.50
(.492DIA)
PANEL CUT
-
OUT WITH
5.10
(.20)
1.70
(.066)
"
K
"
SEALING
Recommended cut-out and mounting depending on panel thickness
3 Max
(.118 Max)
4 Max
(.157 Max)
U60
FINISH
B
LM
8
Lever and bushing with grey satin chrome finish
Nickel plated bushing - lever and upper nut bright chrome plated
Matt black lever with fluorescent tip
A-120
www.apem.com
9.60
(.377)
Ø3.50
(.137DIA)
APEM
6000 series
Toggle switches for military applications
SEALING
1
2
K
Frontal sealing by O-ring and sealing washer.
Protects the switch against water and dust.
Panel seal withstands 1 bar pressure and remains sealed even when
switch is operated
A
➀
O-ring
➁
Sealing washer
LOCKING LEVERS
➞
Keyway
19.40
(.763)
19.40
(.763)
Ø11.90 32NS
(15/32'' 32NS)
11.90
(.468)
Ø11.90 32NS
(15/32'' 32NS)
11.90
(.468)
Ø11.90 32NS
(15/32'' 32NS)
11.90
(.468)
-1V
1 locked position
-2V
2 locked positions
-3V
3 locked positions
TERMINALS
Not available on single pole
models.
Blank
/2
/3
Screw terminals
Solder lug terminals
Quick-connect terminals 6,35 x 0,8 (.250 x .031)
6.50
(.255)
2.50
(.098)
8.00
(.314)
Ø2.50
(.098DIA)
20.60
(.811)
Ø1.60
(.062DIA)
Ø5.00
(.196DIA)
6.35x0.80
(.25x.031)
/2
/3
NEOPRENE PROTECTION CAPS
These caps are designed to insulate terminals against electrical short circuit.
For 1-pole
models
U58
For 2-pole
models
U120
For 3-pole
models
U46
For 4-pole
models
U47
To be ordered separately. Example : PROTECTION CAP U58
APEM
www.apem.com
A-121
