Thick Film Wraparound Surface
Mount Chip Resistors for
Epoxy and Solder Mount
The
ims
RCX, HCX series of thick film wraparound surface mount chip resistors is ideal
for most applications requiring epoxy or solder die attaching methods. Thick film
technology provides a stable resistor at a very affordable price. The “X” designation in
each series is a variable that allows for specifying the termination metalization. Please
see the ordering information on the back for instructions. The wraparound terminations
use gold, platinum gold, platinum silver, or platinum silver with solder coating. These chip
resistors have the following features:
• High stability thick film resistor element
• 96% Al
2
O
3
substrate material
• Platinum silver(PtAg), platinum gold(PtAu), solder coated platinum silver, solder coated
platinum gold, or gold(Au) terminations
• Tolerances to ± 1%
• Passivated resistor element available where not standard
• Available in bulk, tape and reel, and waffle pack
Termination styles
SG - Single wrap
with groundplane
Full wraparound
Thick film technology
Full Wraparound and
Single Wraparound with
Groundplane
Ideal for epoxy
attachment. Solder
coating also available
Resistance values from
1 ohm to 1000 Gigohm
Tolerances to 1 %
TCR to 100 ppm/
o
C
1 - 9.1
10 - 24
10%
1%
2%
5%
10%
25 - 50K
1%
2%
5%
10%
50K - 6.2M 1%
2%
5%
10%
6.2M - 25M 1%
2%
5%
10%
26M - 50M 5%
10%
50M - 200M 5%
10%
15%
220M - 1G 10%
15%
1.2G - 100G 15%
30%
110G - 1T 30%
50 Schoolhouse Lane
Portsmouth, RI 02871
Tel (401) 683-9700
Fax (401) 683-5571
e-mail: ims@ims-resistors.com
http://www.ims-resistors.com
Consult factory for additional values.
1
Lowest resistor value is 11MΩ.
HCC,3-1206
Features
RC1-0302SG
RC4,D-0302
RC3-0402(SG)
RCC-0402
RC3,C-0502
RC3-0504
RCC-0504
RC3-0603
RCC-0603
1
RC3-0805
RCC-0805
RC3,C-1005
RC3,C-1206
RC3,C-1505
RC3,C-2010
RC3,C-2512
HCC,3-0805
Dimensions
Part Number
RC1-0302SG*
RC4,D-0302
RC3,C-0402(SG)
RCX-0502
RCX-0504
RCX-0603
RCX,HCX-0805
RCX-1005
RCX,HCX-1206
RCX-1505
RCX-2512
Length
0.030 ±
.002
-
.004
0.030 ± .005
0.040 ± .005
0.050 ± .005
0.050 ± .005
0.060 ± .005
0.080 ± .005
+ .010
0.100 ±
.005
-
.010
0.126 ± .008
+ .010
0.150 ±
.005
-
.010
0.248 ± .008
+ .004
Width
0.020 ± .003
0.020 ± .003
0.020 ± .005
0.020 ± .005
0.040 ± .005
0.030 ± .005
0.050 ± .005
0.050 ± .005
0.063 ± .006
0.050 ± .005
0.126 ± .010
Height
0.020 max.
0.020 max.
0.020 max.
0.020 max.
0.020 max.
0.020 max.
0.020 max.
0.020 max.
0.020 max.
0.020 max.
0.028 max.
Terminal
0.009 ± .003
0.008 ± .005
0.008 ± .004
0.014 ± .005
0.015 ± .006
0.014 ± .006
0.018 ± .008
0.015 ± .005
0.020 ± .010
0.016 ± .006
0.026 ± .010
W
H
L
T
TCR (typical)
RCX Standard Values
RC4 ± 250
RC1 ± 250
RCC,3 ± 250
ppm/°C
*SG terminations available on all sizes as special order. Contact factory for details.
Specifications
Operating temperature
Maximum Working Voltage
RCX-0302 to RCX-0603
RCX-0805
Rated power (70°C)
RCX-0302
RC3,C-0402
RCX-0504
RCX-0502, 0603
RCX-0805
RCX-1206, 1005, 1505
RCX-2512
Resistance tolerances*
RCX-0302, 0402
RCX-0502 to RCX-2512
-55°C to +150°C
50 VDC
150 VDC
63 mW
80 mW
125 mW
100 mW
175 mW
250 mW
1W
5%, 10%
1%, 2%, 5%,
10%, 15%, 30%
± 200
± 100
±0
0
1.0
10
50K
25M
50M
Ohms
RCX, HCX 0805 Series High Megohm
and Gigohm
± 600
± 250
ppm/°C
± 200
± 75
±0
0 25M 500M 501M 1G 1.2G 20G 22G 200G
Ohms
RCX 0603 High Megohm
+0, -1000
+0, -500
ppm/°C
* Not all values available in all tolerances.
±200
±100
0
0
25M 50M 51M 1G
1.1G 20G 22G 100G
Ordering Information
Example: 100Ω, 5%, 0504, PtAg terminations, 125mW resistor
Ω
RC
1
3
4
C
Ohms
RC3 - 0504 -1000 J
Tolerance
F - 1% G - 2%
J - 5% K - 10%
L - 15% N - 30%
Au
PtAg
Pt Au (0302SG only)
PtAg with 62/36/2
solder coating
D PtAu with 62/36/2
solder coating
(0302SG only)
Form factor
0302(SG) 0402(SG) 0502
0603
0805
1005
1505
2010
2512
0504
1206
Resistance value
The first three digits are significant
values. The fourth is the number of
zeroes following. The R indicates a
decimal point when resistance value is
less than 100Ω.
50 Schoolhouse Lane
Portsmouth, RI 02871
Tel (401) 683-9700
Fax (401) 683-5571
e-mail: ims@ims-resistors.com
http://www.ims-resistors.com
RCX ver.5 03/04 Specifications subject to change without
