Amphenol
Miniature Box Interconnects
G802
Materials
Housing
Contacts
– 94V-0 thermoplastic
– P/B with 50µ” Ni
– 1A
– 250 VAC/rms 60Hz
1.27mm Pin Headers PCB Mount
Durability
Gold Flash
15µ” Gold
30µ” Gold
– 75 cycles
– 150 cycles
– 250 cycles
Board to Board system, modular, fine pitch.
Electrical
Current
Voltage
Mating Half
1.27mm SIL Rec
– Page G-6
1.27x1.27mm Rec – Page G-7
1.27x2.54mm Rec – Page G-6
Part Number System:
G802 XXX X X X X
1.27mm Pin Headers
Through hole PCB Mount
NUMBER OF POSITIONS
Single row: 002 to 050
Dual row: 004 to 100
MOUNTING STYLE
1: Single row
2: Double row (1.27x2.54mm)
3: Double row (1.27x1.27mm)
Suffix may be added to Part Number.
This Suffix is for Internal use mainly.
Additional Suffix ‘EU’ or ‘LF’ may be
added for RoHS compliant product.
INSULATOR HEIGHT
1: 3mm
2: 2.54mm
3: 1.7mm
4: 2.64mm (single row only)
CONTACT FINISH
0: Full gold flash
1: Gold flash
2: 15µ” Gold
3: 30µ” Gold
Single Row (SIL)
Dimensions
No. of
Positions
A
B
18
22.86
21.59
19
24.13
22.86
20
25.4
24.13
21
26.67
25.4
22
27.94
26.67
23
29.21
27.94
24
30.48
29.21
25
31.75
30.48
26
33.02
31.75
27
34.29
33.02
28
35.56
34.29
29
36.83
35.56
30
38.1
36.83
31
39.37
38.1
32
40.64
39.37
33
41.91
40.64
No. of
Positions
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
Dimensions
A
B
2.54
1.27
3.81
2.54
5.08
3.81
6.35
5.08
7.62
6.35
8.89
7.62
10.16
8.89
11.43
10.16
12.7
11.43
13.97
12.7
15.24
13.97
16.51
15.24
17.78
16.51
19.05
17.78
20.32
19.05
21.59
20.32
No. of
Positions
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
Dimensions
A
B
43.18
41.91
44.45
43.18
45.72
44.45
46.99
45.72
48.26
46.99
49.53
48.26
50.8
49.53
52.07
50.8
53.34
52.07
54.61
53.34
55.88
54.61
57.15
55.88
58.42
57.15
59.69
58.42
60.96
59.69
62.23
60.96
63.5
62.23
No. of
Positions
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
AMTA
Dimensions
A
B
2.54
1.27
3.81
2.54
5.08
3.81
6.35
5.08
7.62
6.35
8.89
7.62
10.16
8.89
11.43
10.16
12.7
11.43
13.97
12.7
15.24
13.97
16.51
15.24
17.78
16.51
19.05
17.78
20.32
19.05
21.59
20.32
No. of
Positions
36
38
40
42
44
46
48
50
52
54
56
58
60
62
64
66
Double Row (DIL)
Dimensions
A
B
22.86
21.59
24.13
22.86
25.4
24.13
26.67
25.4
27.94
26.67
29.21
27.94
30.48
29.21
31.75
30.48
33.02
31.75
34.29
33.02
35.56
34.29
36.83
35.56
38.1
36.83
39.37
38.1
40.64
39.37
41.91
40.64
No. of
Positions
68
70
72
74
76
78
80
82
84
86
88
90
92
94
96
98
100
Dimensions
A
B
43.18
41.91
44.45
43.18
45.72
44.45
46.99
45.72
48.26
46.99
49.53
48.26
50.8
49.53
52.07
50.8
53.34
52.07
54.61
53.34
55.88
54.61
57.15
55.88
58.42
57.15
59.69
58.42
60.96
59.69
62.23
60.96
63.5
62.23
Dimensions in mm
PNS-802 Rev. B/HEAD-G8021XX4-13 Rev. A
G-3
