F-209-1
SEML–110–02–03.0–H–D–WT
TM
SEML–150–02–03.0–H–D–WT
EXTENDED LIFE PRODUCT
10 Year Mixed Flowing Gas (MFG)
Call Samtec for maximum cycles mated with TEM
SEM–135–02–03.0–H–D–WT
0,80
mm
TIGER EYE SOCKET
™
SPECIFICATIONS
For complete specifications and
recommended PCB layouts
see www.samtec.com?SEM or
www.samtec.com?SEML
Insulator Material:
Black Liquid Crystal
Polymer
Contact Material:
BeCu
Plating:
Au over 50µ" (1,27µm) Ni
RoHS Compliant:
Yes
SEM, SEML
SERIES
Mates with:
TEM
™
High reliability
Tiger Eye
™
contacts
Choice of
mated heights
STACK
HEIGHT
Processing:
Max Processing Temp:
230°C for 60 seconds, or
260°C for 20 seconds 3x
Lead-Free Solderable:
Yes
SMT Lead Coplanarity:
(0,10mm) .004" max
SEM
STACK
HEIGHT
TEM
STACK
LEAD STYLE HEIGHT
–03.0
–04.0
–07.0
6mm
7mm
10mm
(0,80mm)
.0315"
pitch
Weld Tab option
TEM
ALSO
AVAILABLE
• (1,27mm) .050"
board-to-board
and cable-to-board
Tiger Eye
™
systems
available.
• Board Stacking:
See SFM, TFM Series
• Cable Assemblies:
See SFSD, TFSD Series
• AccliMate
™
:
See SCP3/SCR3 Series
Call Samtec.
TYPE
STRIP
1
NO. PINS
PER ROW
02
STACK
HEIGHT
PLATING
OPTION
D
OPTION
OTHER
OPTION
–L
SEM
= Tiger Eye
Strip
™
05,10,15, 20, 25,
30, 35, 40, 45, 50
(Call Samtec for other sizes)
–03.0
= 6mm,
7mm or 10mm
Stack Height
when mated
with TEM Series
SEML
= Tiger Eye
™
Friction Lock
(No. of Positions x (0,80) .0315)
+ (4,50).177
02
= 10µ"
(0,25µm)
Gold on
contact,
Matte Tin
on tail
–A
= Alignment Pin
(Not available
with –LC or –WT)
–K
= (3,50mm)
.138" DIA
Polyimide
film Pick &
Place Pad
–LC
= Locking Clip
(Not available
with –A or –WT)
–TR
= Tape &
Reel
APPLICATION
SPECIFIC OPTION
Alignment Pins and
Locking Clips available.
Call Samtec.
–WT
(3,20)
.126
01
= Weld Tab
(Not available
with –A or –LC)
(3,30)
.130
(0,80) .0315
(4,50)
.177
(3,75)
.148
(3,20)
.126
SEM
(1,89)
.074
Note:
Other Gold plating
options available.
Contact Samtec.
Note:
Some sizes, styles and
options are non-standard,
non-returnable.
(No. of Positions
x (0,80) .0315)
+ (3,00).118
(0,30)
.012
(3,36)
.132
(0
(0,80) .0315
SEML
–WT OPTION
WWW.SAMTEC.COM
