MKT 1802
Vishay Roederstein
Multilayer Film Chip Capacitors
FEATURES
• Multilayer metallized polymer surface mount chips
• Use of high temperature metallized polymer film makes
the MKT1802 capacitor suitable for infrared or vapor
phase reflow solder processes.
• The self-healing property of metallized film technology
provides a safe open circuit failure mode and excellent
reliability.
• Open construction provides larger capacitance values in
smaller size for a given voltage
• EIA standard chip sizes
• Exellent thermal shock resistance.
Such as -
• Telecommunications : Switching systems
Modems
Telephone sets
Cellular
• Automotive:
Airbag
Fuel injection
Switch mode power supplies
Power converter module
• Low dissipation factor, ESR and ESL.
• No piezoelectric effect.
• Nonpolar construction.
• Tape and reel packaging
• Tape and Reel packaging supplied in hermetically sealed
bags.
APPLICATIONS
General purpose, low voltage applications where miniatur-
ization and surface mount capability are critical parameters:
• Industrial :
GENERAL CHARACTERISTICS
Capacitance Range (E6 Series)
Tolerance on Capacitance
DC Rated Voltage Range Vr
Temperature Range
Insulation Resistance Minimum
.001µF to 4.7µF
±
5%
25VDC, 63VDC, 100VDC, 250VDC
- 55˚C to + 125°C with Voltage derating of 1.25%/°C from 105°C to 125°C
For C
≤
0.33µF ; IR > 1000 MΩ at 20°C for 1 min. charge at 10VDC for
Vr < 100VDC and 100VDC for Vr
≥
100VDC
For C > 0.33µF ; IR • C > 400 sec at 20°C for 1 min. charge at 10VDC for
Vr < 100VDC and 100VDC for Vr
≥
100VDC
55/125/56
1.4Vr 2s
<10 x 10
-3
@ 1kHz
IR or vapor phase reflow (MKT1802 is not suitable for wave soldering)
Climatic Catagory
Surge Voltage
Dissipation Factor
Soldering Methods
Document Number: 26054
Revision 13-Jul-00
www.vishay.com
1
MKT 1802
Vishay Roederstein
Multilayer Film Chip Capacitors
2)
±
0.0
.2 (
07)
W
0.3
1
(0.0
0
H
L
EIA SIZES AND DIMENSIONS
SIZE
L
mm
inch
W
mm
inch
1206
1210
1812
2220
2824
4030
5040
6054
3.2
±
0.3
3.2
±
0.3
4.5
±
0.5
0.126
±
0.012 0.126
±
0.012 0.177
±
0.020
5.7
±
0.5
7.1
±
0.5
10.2
±
0.6
12.7
±
0.6
15.2
±
0.6
0.224
±
0.020 0.280
±
0.020 0.401
±
0.024 0.500
±
0.024 0.598
±
0.024
1.6
±
0.3
2.5
±
0.3
3.2
±
0.5
5.0
±
0.5
6.1
±
0.5
7.6
±
0.8
10.2
±
0.8
13.7
±
0.8
0.063
±
0.012 0.098
±
0.012 0.126
±
0.020 0.197
±
0.020 0.240
±
0.020 0.299
±
0.031 0.401
±
0.031 0.539
±
0.031
MOUNTING AND SOLDERING RECOMMENDATIONS
For infrared and vapor phase reflow soldering, the temperature profile below shows allowable time temperature combination.
These capacitors are NOT suitable for wave soldering.
In case of hand soldering, the temperature of the soldering iron should not be above 250°C. Special care must be taken to
avoid touching the body with the iron tip.
PHASE
Preheating
Soldering
TEMPERATURE (
°
C)
160 to 180°C max.
180 to 235°C max.
TIME (s)
180s max.
30s max.
Solder Paste Thickness
For optimum solderability, the recommended soldering paste thickness is as follows:-
CHIP SIZE
1206 / 1210 / 1812 / 2220 / 2824
4030 / 5040 / 6054
SOLDER PASTE THICKNESS
150 to 200µm
200 to 300µm
Board Cleaning Recomendations
To clean the flux from the PC board assembly, use a suitable solvent such as Isopropylalcohol, or deionized water wash.
Solvents such as Toluene , Xylene and Trichloroethylene should be avoided.
SOLDER PAD DIMENSIONS
CASE SIZE
C
B
A
mm
inch
0.051
0.079
0.118
0.197
0.236
0.295
0.441
0.575
1.3
2.0
3.0
5.0
6.0
7.5
11.2
14.6
DIMENSIONS
B
mm
inch
1.3
1.3
1.5
1.9
2.5
3.0
3.5
3.6
0.051
0.051
0.059
0.075
0.098
0.118
0.138
0.142
C
mm
2.4
2.4
3.5
4.5
5.7
8.0
10.3
12.6
inch
0.090
0.090
0.140
0.180
0.220
0.310
0.410
0.500
1206
1210
1812
2220
A
2824
4030
5040
6054
www.vishay.com
2
Document Number: 26054
Revision 13-Jul-00
MKT 1802
Multilayer Film Chip Capacitors
Vishay Roederstein
CAPACITANCE AND VOLTAGE RANGE
25V (105
°
C) / 16VAC (105
°
C) - 5% CAPACITANCE TOLERANCE
VISHAY PART NUMBER
MKT 1802-210/024
MKT 1802-215/024
MKT 1802-222/024
MKT 1802-233/024
MKT 1802-247/024
MKT 1802-268/024
MKT 1802-310/024
MKT 1802-315/024
MKT 1802-322/024
MKT 1802-333/024
MKT 1802-347/024
MKT 1802-368/024
MKT 1802-410/024
CAPACITANCE VALUE
µ
F
.001µF
.0015µF
.0022µF
.0033µF
.0047µF
.0068µF
.01µF
.015µF
.022µF
.033µF
.047µF
.068µF
.1µF
EIA SIZE
1206
1206
1206
1206
1206
1206
1206
1206
1206
1210
1210
1210
1210
H DIMENSION MAX.
mm
inches
1.1
1.1
1.1
1.1
1.1
1.1
1.3
1.3
1.3
2.2
1.8
2.2
2.2
0.043
0.043
0.043
0.043
0.043
0.043
0.051
0.051
0.051
0.087
0.071
0.087
0.087
REEL SIZE
inch
7
7
7
7
7
7
7
7
7
7
7
7
7
QUANTITY
pcs/reel
3900
3900
3900
3900
3900
3900
3400
3400
3400
2000
2500
2000
2000
63V (105
°
C) / 40VAC (105
°
C) - 5% CAPACITANCE TOLERANCE
MKT 1802-210/064
MKT 1802-215/064
MKT 1802-222/064
MKT 1802-233/064
MKT 1802-247/064
MKT 1802-268/064
MKT 1802-310/064
MKT 1802-315/064
MKT 1802-322/064
MKT 1802-333/064
MKT 1802-347/064
MKT 1802-368/064
MKT 1802-410/064
MKT 1802-415/064
MKT 1802-422/064
MKT 1802-433/064-C
MKT 1802-447/064-C
MKT 1802-468/064-C
MKT 1802-510/064-C
MKT 1802-515/064-C
MKT 1802-522/064-C
MKT 1802-533/064-C
MKT 1802-547/064-C
.001µF
.0015µF
.0022µF
.0033µF
.0047µF
.0068µF
.01µF
.015µF
.022µF
.033µF
.047µF
.068µF
.1µF
.15µF
.22µF
.33µF
.47µF
.68µF
1µF
1.5µF
2.2µF
3.3µF
4.7µF
1812
1812
1812
1812
1812
1812
1812
1812
1812
1812
1812
1812
1812
1812
1812
2220
2220
2220
2824
5040
5040
6054
6054
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
2.0
2.0
2.0
2.5
3.0
3.4
4.0
4.5
5.0
4.6
5.5
5.7
6.0
0.059
0.059
0.059
0.059
0.059
0.059
0.059
0.059
0.059
0.059
0.079
0.079
0.079
0.098
0.118
0.134
0.157
0.177
0.197
0.181
0.217
0.224
0.236
7
7
7
7
7
7
7
7
7
7
7
7
7
7
7
13
13
13
13
13
13
13
13
1500
1500
1500
1500
1500
1500
1500
1500
1500
1500
1200
1200
1200
900
700
2800
2300
1900
1100
700
700
400
400
All 1812 case size values in 7 inch reels are available on request in a 13 inch reel option; to order add suffix -C to standard part
number.
QUANTITIES PER 1812 REEL
7 inch Reel
1,500
1,200
13 inch Reel
5,800
4,500
7 inch Reel
900
700
13 inch Reel
3,600
3,000
