UMFT240XE-01 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Development board/suite/development tools> UMFT240XE-01

UMFT240XE-01: Descriptioninterface development tools usb to 8-bit 245 fifo module; CategoryDevelopment board/suite/development tools; File Size759KB，42 Pages; ManufacturerFTDI [Future Technology Devices International Ltd.]; Environmental Compliance

Download Datasheet Parametric View All

UMFT240XE-01 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	UMFT240XE-01	-	-	View	Buy Now

UMFT240XE-01 Overview

interface development tools usb to 8-bit 245 fifo module

UMFT240XE-01 Parametric

Parameter Name	Attribute value
Manufacture	FTDI
Product Category	Interface Development Tools
RoHS	Yes
Produc	Development Modules
Type	USB to FIFO
Tool Is For Evaluation Of	FT240XQ
Interface Type	I2C, FIFO, USB
Operating Supply Voltage	3.3 V
Description/Functi	USB to 8bit 245 FIFO evaluation module
Dimensions	29.02 mm x 19.24 mm x 9.2 mm
For Use With	FT240XQ
Operating Supply Curre	1 A
Packaging	Bulk
Factory Pack Quantity	25

Preview

Download Datasheet

View All

FT240X USB 8-BIT FIFO IC Datasheet

Version 1.4

Document No.: FT_000626 Clearance No.: FTDI# 259

Future Technology

Devices International Ltd

FT240X

(USB 8-BIT FIFO IC)

The FT240X is a USB to parallel FIFO

interface with the following advanced

features:



Single chip USB to parallel FIFO bidirectional

data transfer interface.

Entire USB protocol handled on the chip. No

USB specific firmware programming required.

Fully integrated 2048 byte multi-time-

programmable (MTP) memory, storing device

descriptors and FIFO I/O configuration.

Fully integrated clock generation with no

external crystal required plus optional clock

output selection enabling glue-less interface to

external MCU or FPGA.

Data transfer rates up to 1Mbyte / second.

512 byte receive buffer and 512 byte transmit

buffer utilising buffer smoothing technology to

allow for high data throughput.

FTDI’s royalty-free Virtual Com Port (VCP) and

Direct

(D2XX)

drivers

eliminate

the

requirement for USB driver development in

most cases.

Configurable FIFO interface I/O pins.

Synchronous and

interface options.

asynchronous

bit

bang



USB Battery Charger Detection. Allows for USB

peripheral devices to detect the presence of a higher

power source to enable improved charging.

Device supplied pre-programmed with unique USB serial

number.

USB Power Configurations; supports bus- powered, self-

powered and bus-powered with power switching.

Integrated +3.3V level converter for USB I/O.

True 3.3V CMOS drive output and TTL input; operates

down to 1V8 with external pull-ups.

Configurable I/O pin output drive strength; 4 mA(min)

and 16 mA(max).

Integrated power-on-reset circuit.

Fully integrated AVCC supply filtering - no external

filtering required.

+5V Single Supply Operation.

Internal 3V3/1V8 LDO regulators

Low operating and USB suspend current; 8mA (active-

typ) and 125uA (suspend-typ).

UHCI/OHCI/EHCI host controller compatible.

USB 2.0 Full Speed capable.

Extended operating temperature range; -40 to 85⁰C.

Available in compact Pb-free 24 Pin SSOP and QFN-24

packages (both RoHS compliant).



Neither the whole nor any part of the information contained in, or the product described in this manual, may be adapted or reproduced

in any material or electronic form without the prior written consent of the copyright holder. This product and its documentation are

supplied on an as-is basis and no warranty as to their suitability for any particular purpose is either made or implied. Future Technology

Devices International Ltd will not accept any claim for damages howsoever arising as a result of use or failure of this produ ct. Your

statutory rights are not affected. This product or any variant of it is not intended for use in any medical appliance, device or system in

which the failure of the product might reasonably be expected to result in personal injury. This document provides preliminar y

information that may be subject to change without notice. No freedom to use patents or other intellectual property rights is implied by

the publication of this document. Future Technology Devices International Ltd, Unit 1, 2 Seaward Place, Centurion Business Park,

Glasgow G41 1HH United Kingdom. Scotland Registered Company Number: SC136640

FT240X USB 8-BIT FIFO IC Datasheet

Version 1.4

Document No.: FT_000626 Clearance No.: FTDI# 259

Table of Contents

1.1

1.2

1.3

Typical Applications....................................................... 2

Driver Support ........................................................................... 2

Part Numbers ............................................................................. 2

USB Compliant ........................................................................... 3

3.1

3.2

3.3

3.4

3.5

3.6

3.7

FT240X Block Diagram .................................................. 4

Device Pin Out and Signal Description ........................... 7

24-LD SSOP Package.................................................................. 7

SSOP Package Pin Out Description ............................................. 7

QFN-24 Package ...................................................................... 10

QFN-24 Package Signal Description ......................................... 10

CBUS Signal Options ................................................................ 12

FT240X FIFO READ Timing Diagrams ....................................... 13

FT240X FIFO WRITE Timing Diagrams ..................................... 14

4.1

4.2

Function Description ................................................... 15

Key Features ............................................................................ 15

Functional Block Descriptions .................................................. 16

5.1

5.2

5.3

5.4

5.5

Devices Characteristics and Ratings ............................ 17

Absolute Maximum Ratings ...................................................... 17

ESD and Latch-up Specifications .............................................. 17

DC Characteristics .................................................................... 18

MTP Memory Reliability Characteristics ................................... 21

Internal Clock Characteristics .................................................. 22

6.1

6.2

6.3

USB Power Configurations ........................................... 23

USB Bus Powered Configuration ............................................. 23

Self Powered Configuration ..................................................... 24

USB Bus Powered with Power Switching Configuration ........... 25

7.1

7.2

Application Examples .................................................. 27

USB to MCU FIFO Interface ...................................................... 27

Battery Charge Detection ......................................................... 27

8.1

Internal MTP Memory Configuration ............................ 30

Default Values ......................................................................... 30

Recommended Resources
