ZLED7020
High Current 40V LED Driver with Internal Switch
ZLED7x20 Block Diagram
Typical Applications
Illuminated LED signs and other displays
LED street and traffic lighting (low voltage)
Architecture/building LED lighting
LED backlighting
Interior/exterior LED lighting
MR16 LED spot lights
Retrofit LED lighting fixtures
General purpose industrial and consumer LED applications
Ordering Information
Product Sales Code Description
ZLED7020-ZI1R
ZLED7320-ZI1R
ZLED7520-ZI1R
ZLED7720-ZI1R
ZLED7020KIT-D1
ZLED-PCB8
ZLED7020 – High Current (1200mA) 40V LED Driver with Internal Switch
ZLED7320 – High Current (1000mA) 40V LED Driver with Internal Switch
ZLED7520 – High Current (750mA) 40V LED Driver with Internal Switch
ZLED7720 – High Current (350mA) 40V LED Driver with Internal Switch
ZLED7020-D1 Demo Board, 1 ZLED-PCB8 and 5 ZLED7020 ICs
Test PCB with one 5W white High Brightness (HB) LED, cascadable to one
multiple LED string
Package
SOT89-5 (Tape & Reel)
DFN-5 (Tape & Reel)
DFN-5 (Tape & Reel)
