ZSSC3026
Low Power 16 Bit Sensor Signal Conditioner IC
ZSSC3026 Block Diagram
Ordering Information
Ordering Examples *
ZSSC3026CC1B
ZSSC3026CI1B
ZSSC3026CI4
ZSSC30x6KIT
Description
Temperature range: –40°C to +85 °C,
Consumer-Level: Parameter according Data Sheet
Temperature range: –40°C to +85 °C,
Industrial-Level: 10 years MTP-Data Retention
Temperature range: –40°C to +110 °C, Industrial
Evaluation Kit for ZSSC30x6 Product Family
Package
Chips, Wafer (304um) unsawn, tested
Chips, Wafer (304um) unsawn, tested
PQFN24 4x4, tested
Boards, cable, software-CD, 1 sample
* Please contact ZMDI Sales for additional options.
