60W Single Output LED Power Supply
PLN-60
series
■
Features :
‧
Universal AC input / Full range (up to 295VAC)
‧
High efficiency up to 89%
‧
Protections: Short circuit / Over current / Over voltage / Over temperature
‧
Cooling by free air convection
‧
Built-in constant current limiting circuit with adjustable OCP level
‧
Fully isolated plastic case with IP64 level
‧
Built-in active PFC function
‧
IP64 design for indoor or outdoor installations
‧
Pass LPS
‧
Class 2 power unit
‧
100% full load burn-in test
‧
High reliability
‧
Suitable for LED lighting and moving sign applications
(Note.2)
‧
Suitable for dry / damp locations
‧
Compliance to worldwide safety regulations for lighting
‧
2 years warranty
F
110
M
M
SELV
LPS
20V
( for 48V only)
( except for 48V )
IP64
PLN-60-36
36V
25.2 ~ 36V
1.7A
0 ~ 1.7A
61.2W
3.6Vp-p
32.5 ~ 39V
PLN-60-48
48V
33.6 ~ 48V
1.3A
0 ~ 1.3A
62.4W
4.6Vp-p
43.6 ~ 51.8V
SPECIFICATION
MODEL
DC VOLTAGE
RATED CURRENT
CURRENT RANGE
RATED POWER
OUTPUT
PLN-60-12
12V
5A
0 ~ 5A
60W
11.5 ~ 13V
CONSTANT CURRENT REGION
Note.6
8.4 ~ 12V
PLN-60-15
15V
10.5 ~15V
4A
0 ~ 4A
60W
2.4Vp-p
14.5 ~ 16.2V
PLN-60-20
14 ~ 20V
3A
0 ~ 3A
60W
1.8Vp-p
19.5 ~ 22V
PLN-60-24
24V
16.8 ~24V
2.5A
0 ~ 2.5A
60W
2.7Vp-p
24 ~ 26V
PLN-60-27
27V
18.9 ~27V
2.3A
0 ~ 2.3A
62.1W
2.7Vp-p
25 ~ 30V
RIPPLE & NOISE (max.)
Note.2
2Vp-p
VOLTAGE ADJ. RANGE
Note.5
Can be adjusted by internal potentiometer SVR1
CURRENT ADJ. RANGE
Note.5
3% ~ -25%. Can be adjusted by internal potentiometer SVR2
VOLTAGE TOLERANCE
Note.3
±10%
LINE REGULATION
LOAD REGULATION
SETUP TIME
VOLTAGE RANGE
FREQUENCY RANGE
POWER FACTOR (Typ.)
INPUT
EFFICIENCY (Typ.)
AC CURRENT (Typ.)
INRUSH CURRENT (max.)
LEAKAGE CURRENT
OVER CURRENT
SHORT CIRCUIT
PROTECTION
OVER VOLTAGE
OVER TEMPERATURE
WORKING TEMP.
WORKING HUMIDITY
ENVIRONMENT STORAGE TEMP., HUMIDITY
TEMP. COEFFICIENT
VIBRATION
SAFETY STANDARDS
SAFETY & WITHSTAND VOLTAGE
EMC
ISOLATION RESISTANCE
EMC EMISSION
EMC IMMUNITY
MTBF
OTHERS
DIMENSION
PACKING
NOTE
1.
2.
3.
4.
5.
6.
7.
±3.0%
±5.0%
1500ms / 230VAC 3000ms / 115VAC at full load
Note.4
90 ~ 295VAC
127 ~ 417VDC
47 ~ 63Hz
PF>0.98/115VAC, PF>0.9/230VAC, PF>0.9/277VAC at full load (Please refer to "Power Factor Characteristic" curve)
85%
0.8A/115VAC
86%
0.4A/230VAC
87.5%
0.3A/277VAC
87%
88%
89%
89%
COLD START 35A(t
width
=45 s measured at 50% I
peak
) at 230VAC
μ
<0.75mA / 240VAC
95 ~ 110%
Protection type : Constant current limiting, recovers automatically after fault condition is removed
Hiccup mode, recovers automatically after fault condition is removed.
13.8 ~ 16V
17.5 ~ 21V
23 ~ 28V
28 ~ 32V
Protection type : Shut down o/p voltage, re-power on to recover
Shut down o/p voltage, recovers automatically after temperature goes down
-30 ~ +50
℃
(Refer to "Derating Curve")
20 ~ 95% RH non-condensing
-40 ~ +80
℃
, 10 ~ 95% RH
±
0.03%/
℃
(0 ~ 50
℃
)
10 ~ 500Hz, 2G 12min./1cycle, period for 72min. each along X, Y, Z axes
UL879, UL1310, UL8750, CSA C22.2 No. 207-M89(except for 48V), TUV EN61347-1, EN61347-2-13 independent, CAN/CSA
C22.2 No. 223-M91(except for 48V), CSA C22.2 No. 250.0-08(except for 48V), IP64, J61347-1, J61347-2-13 approved ; design refer to UL60950-1
I/P-O/P:3.75KVAC
I/P-FG:2KVAC
O/P-FG:0.5KVAC
I/P-O/P:100M Ohms / 500VDC / 25
℃
/ 70% RH
Compliance to EN55015, EN55022 (CISPR22) Class B, EN61000-3-2 Class C (
≧
75% load) ; EN61000-3-3
Compliance to EN61000-4-2,3,4,5,6,8,11, EN55024,EN61547, light industry level, criteria A
497.8K hrs min. MIL-HDBK-217F (25
℃
)
181*61.5*35mm (L*W*H)
0.5Kg; 24pcs/13Kg/0.75CUFT
31 ~ 35V
41 ~ 46V
54 ~ 60V
All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25
℃
of ambient temperature.
Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
Tolerance : includes set up tolerance, line regulation and load regulation.
Derating may be needed under low input voltage. Please check the static characteristics for more details.
Output voltage can be adjusted through the SVR1 on the PCB ; limit of output constant current level can be adjusted through the SVR2 on the PCB.
Please refer to "DRIVING METHODS OF LED MODULE".
The power supply is considered as a component that will be operated in combination with final equipment. Since EMC performance will be affected by the
complete installation, the final equipment manufacturers must re-qualify EMC Directive on the complete installation again.
8. Direct connecting to LEDs is suggested, but is not suitable for using additional drivers.
File Name:PLN-60-SPEC 2014-03-13
60W Single Output LED Power Supply
Power Factor Characteristic
Constant Current Mode
1
0
0
0
0
0
0
0
0
0
0
0
.0
.9
.9
.9
.9
.9
.8
.8
.8
.8
.8
.7
0
8
6
4
2
0
8
6
4
2
0
8
50%
60%
70%
80%
90%
100%
(60W)
PLN-60
series
2 7 7 V ac
2 3 0 V ac
1 1 5 V ac
LOAD
EFFICIENCY vs LOAD (48V Model)
PLN-60 series possess superi or wo rking efficienc y tha t up to 89% can be rea ched in fi eld applic ations.
92
88
84
80
76
72
68
64
60
56
52
48
44
40
10% 20% 30% 40% 50% 60% 70% 80% 90% 100%
LOAD
277Vac
230Vac
115Vac
DRIVING METHODS OF LED MODULE
This LED power supply is s ug gested to work in constan t current mod e area (C C) to driv e the LEDs.
In the constant current r eg ion, the highest voltage at the output of the dr iver
dep end s on the configur ation of the end s ystems.
Shou ld the re be any compatibility issue s, please con tact MEAN WELL .
Constant
Current area
70
(min.)
Hiccup
Protection
50
100
Io (%)
100
Typic al LED power supply I-V curve
File Name:PLN-60-SPEC 2014-03-13
