Multilayer Ceramic Capacitors Epoxy Coated Radial Type
HIGH VOLTAGE 250V-3KV
ENTERPRISE CORP.
®
Application
NPO：Temperature compensation type, have little or no
change in capacitance with variation in temperature.
Hence, they are used in radio-frequency oscillators,
precision timing circuits, ultra stable amplifiers, etc.
X7R
：Temperature
stable type for by-pass and decoupling
in radio and television receivers, computers servo
systems. Audio tone, and coupling, etc., where
moderate capacitance variations are permissible and
dissipation factor is not critical.
Z5U/Y5V：
General type for by-pass and filtering applications.
Construction
Part No. Designation
R15
SIZE
R15
R20
R25
Z
T.C
N=NPO
W=X7R
Z=Z5U
Y=Y5V
102
Capacitance-Code
Two significant digits
＋NO.
of zeros.
Example
102=1000pf
223=22000pf
104=100000pf
M
Tolerance
A=±0.05PF
B=±0.10PF
C=±0.25PF
D=±0.50PF
F=±1%
G=±2%
J=±5%
K=±10%
M=±20%
Z=+80/-20%
2H
Voltage
2E=250V
2H=500V
3A=1KV
3D=2KV
3F=3KV
L
Lead shape
L=Straight
Y=Inside
Crimp
H=High
seated
A=Slope
5
2=2.54±0.8
5=5.08±0.8
(mm)
L
R=Tape/Reel
B=Tape/Box
6=6±1mm
L=25.4mm(min)
Lead shape Package-Lead-length
1.
LEAD SHAPE:
R15
L
R20
Y
R25
L
R15
H
R20
H
R15
A
15
High Voltage 250v-3kv
2.
Lead Space (F)
Code
2
5
LEAD SPACE (mm/inch)
2.54±0.8
5.08±0.8
0.1±0.032
0.2±0.032
3.
Lead Length (L)
Code
6
L
LEAD LENGTH
6mm±1mm
25.4mm (min)
REMARK
Specified lead length
upon request.
4.
Body Size & Dimension
Size
code
R15
Lead style
available
H,A
Capacitance Range
NPO
250V: 10 – 820pF
500V: 10 – 390pF
250V: 1000 – 5600pF
500V: 470 – 3300pF
R20
H
1KV: 10 – 1000pF
2KV: 10 – 560pF
3KV: 10 – 220pF
250V: 0.0068 – 0.01uF
500V: 3900 – 6800pF
R25
L
1KV: 2700 – 2200pF
2KV: 680 – 1200pF
3KV: 270 – 470pF
X7R
250V: 100pF – 0.022uF
500V: 100 – 15,000pF
250V: 0.022 – 0.1uF
500V: 0.01 – 0.047uF
1KV: 220 – 10,000pF
2KV: 220 – 1800pF
3KV: ------
250V: 0.12 – 0.47uF
500V: 0.056 – 0.15uF
1KV: 0.012 – 0.018uF
2KV: 2200 – 4700pF
3KV: 100 – 2200pF
250V:
0.1-0.47uF
6.5
6.5
4.0
0.5
5.08
---
---
5.0
6.0
3.0
0.5
5.08
2.0
Z5U
---
H max
3.8
W max
H=3.8
A=5.0
Dimensions (mm)
T max.
2.5
d±0.05
0.5
F±0.08
5.08
P
2.0
Typical Performance Characteristics
Specifications
Temperature coefficient
NPO:
±
30PPM/℃, -55℃ to +125℃
●
X7R:
±
15%, -55℃ to +125℃
●
Z5U: +22%,-56%, +10℃ to +85℃
●
Y5V: +22%, -82%, -30℃ to +85℃
●
Dielectric strength 25℃ (Flash Test)
NPO: 250V-2.0 X Vrated, 500V-1.5 X Vrated,
≧1KV-1.2
X Vrated
X7R : 250V-2.0 X Vrated, 500V-1.5 X Vrated,
≧1KV-1.2
X Vrated
●
Z5U : 2.0 X Vrated
●
●
Capacitance test 25℃
NPO: 1 VRMS max at 1 KHz (1 MHz for 100pF or less)
●
X7R: 1 VRMS max at 1 KHz
Z5U: 1 VRMS max at 1 KHz
●
LifeTest :
(1000 hrs at max temp. applied with Flash test voltage
Recovery: 6-24 hrs for NPO and 24± 2 hrs for X7R & Z5U )
∆C/C
D.F.
I .R.
NPO
≦±
3%
≦
2 x initial
X7R
≦
±
20%
≦
±7%
≥0.25
x initial
Z5U
≦±20%
≦2
x initial
Dissipation Factor 25℃
NPO: 0.15% max at 1KHz, 1 Vrms max.
(1MHz for 1000pF or less)
●
X7R: 2.5% max at 1KHz, 1 Vrms max
●
Z5U: 5 % max at 1 KHz, 1 Vrms max.
●
Insulation Resistance after 60 secs, charging at rated
voltage, 25℃, 55%R.H. max
NPO: 100GΩ or 1000MΩ-uF whichever is less
●
X7R : 10GΩ or 100MΩ-uF whichever is less
●
Z5U : 10GΩ or 100MΩ-uF whichever is less
●
16
