ADWISM-322522-015K-T datasheet, PDF

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > Passive components> inductor> ADWISM-322522-015K-T

Preview

ADWISM-322522-015K-T: DescriptionGeneral Purpose Inductor, 0.015uH, 10%, 1210,; CategoryPassive components inductor; File Size262KB，3 Pages; ManufacturerAdiva Technology Inc

Download Datasheet Parametric View All

ADWISM-322522-015K-T Overview

General Purpose Inductor, 0.015uH, 10%, 1210,

ADWISM-322522-015K-T Parametric

Parameter Name	Attribute value
Objectid	839020587
package instruction	1210
Reach Compliance Code	unknown
ECCN code	EAR99
uppercase and lowercase codes	1210
structure	Molded Chip
DC Resistance	0.16 Ω
Nominal inductance(L)	0.015 µH
Inductor type	GENERAL PURPOSE INDUCTOR
Package height	2.2 mm
Package length	3.2 mm
Package form	SMT
Package width	2.5 mm
method of packing	TR
Minimum quality factor (at nominal inductance)	19
Maximum rated current	0.45 A
self resonant frequency	2100 MHz
series	ADWISM-322522(10%)
Tolerance	10%

Preview

Download Datasheet

View All

Molded Wire Wound Chip

Surface Mount

ADWISM-322522 and ADWISM-453232 Series

ADWISM-322522 &

ADWISM-453232

SPECIFICATIONS

SIZE

ADWISM-322522

ADWISM-453232

LENGTH (L)

(inch)

mm

.126 ±.008

3.2 ±0.2

.180 ±.0008

4.5 ±0.2

WIDTH (W)

(inch)

mm

.098 ±.008

2.5 ±0.2

.126 ±.0008

3.2 ±0.2

WIDTH (WT)

(inch)

mm

.067 ±.004

1.7 ±0.1

.048 ±.0004

1.2 ±0.2

HEIGHT (H)

(inch)

mm

.087 ±.008

2.2 ±0.2

.126 ±.0008

3.2 ±0.2

HEIGHT (HT)

(inch)

mm

.075 ±.004

1.9 ±0.1

P

(inch)

mm

.02 nominal

.50 nominal

STANDARD SPECIFICATIONS

PACKAGE TYPE

INDUCTANCE

(uH )

0.005

0.010

0.012

0.015

0.018

0.022

0.027

0.033

0.039

0.047

0.056

0.068

0.082

0.10

0.12

0.15

0.18

M

±20

INDUCTANCE

TOLERANCE (%)

K

±10

QUALITY

FACTOR

min. (MHz)

11

15

17

19

21

23

25

26

27

28

30

SRF

RESONANT

min. (MHz)

2700

2500

2300

2100

1900

1700

1500

1400

1300

1200

1100

1000

900

700

500

450

400

DC

RESISTANCE

max. (Ω)

0.12

0.13

0.14

0.16

0.18

0.20

0.22

0.24

0.27

0.30

0.33

0.36

0.40

0.44

0.22

0.25

0.28

ALLOWABLE

DC CURRENT

max. (mA)

450

MEAS.

FREQUENCY

(MHz)

100

25.2

J

O

80

ADWISM-322522-005❑

ADWISM-322522-010❑

ADWISM-322522-012❑

ADWISM-322522-015❑

ADWISM-322522-018❑

ADWISM-322522-022❑

ADWISM-322522-027❑

ADWISM-322522-033❑

ADWISM-322522-039❑

ADWISM-322522-047❑

ADWISM-322522-056❑

ADWISM-322522-068❑

ADWISM-322522-082❑

ADWISM-322522-R10❑

ADWISM-322522-R12❑

ADWISM-322522-R15❑

ADWISM-322522-R18❑

-

T

±5

www.adivatech.com

(888) 30-ADIVA (23482)
