SERIES
CM6594R
CM6594
rm
fo
ns
DA
SH
NU
er
4-Winding
Surface Mount Transformers
*
ER
MB
s
-253
-503
-104
-154
-254
-504
-754
-105
-155
SERIES CM6594 FERRITE CORE
25
0.90
0.04
50
1.10
0.07
100
1.30
0.13
150
1.50
0.19
250
1.70
0.32
500
4.30
0.56
750
6.80
0.90
1000
6.95
1.19
1500
7.00
1.90
1.00
0.90
0.75
0.60
0.50
0.45
0.38
0.30
0.25
*Complete part # must include series # PLUS the dash #
For surface finish information, refer to www.delevanfinishes.com
Actual Size
Physical Parameters
Inches
A
0.435 to 0.465
B
0.385 to 0.405
C
0.375 to 0.405
D
0.205 to 0.235
E (8 places)
F (6 places)
Millimeters
11.05 to 11.81
9.78 to 10.29
9.53 to 10.29
5.21 to 5.97
0.028 Typ.
0.079 Typ.
0.71 Typ.
2.00 Typ.
Mechanical Configuration
ER Core on an 8 Pin Surface Mount Base
Operating Temperature Range
–20°C to +80°C
Maximum Power Dissipation at 25°C
0.140 W
Dielectric Withstanding Voltage
500V RMS, 60Hz, 5 sec.
Current Rating
Current which will cause less than
a +35°C temperature rise maximum, from +25°C Ambient,
with all windings connected in series
Notes ** 1)
Max. leakage inductance measured
@ 1 kHz on Pin 1-8 with all other pins shorted.
2)
Board
connections may be altered to create different
transformer/inductor configurations.
Pad Dimensions
Inches
C
0.425
G
0.368
X
0.063
Y
0.079
Z
0.492
Millimeters
10.80
9.35
1.60
2.00
12.50
Marking
API; CM6594, dash number. Note: An R after CM6594 indicates
a RoHS component. A dot indicates the location of pin 1.
Example: CM6594-503
API
CM6594
503
Packaging
Tape & reel (24mm): 13" reel, 600 pieces max.; 7" reel not
available
270 Quaker Rd., East Aurora NY 14052 • Phone 716-652-3600 • Fax 716-652-4814 • E-mail: apisales@delevan.com • www.delevan.com
