Low Loss Surface Mount Power Toroid
Actual Size
Physical Parameters
Inches
A
0.475 ± 0.020
B
0.420 ± 0.020
C
0.290 Max.
D
0.400 Ref.
E
0.075 Ref.
F
0.375 ± 0.020
LLST4R7
LLST10
LLST15
LLST18
LLST22
LLST25
LLST27
LLST33
LLST47
LLST75
LLST100
LLST125
LLST140
LLST150
LLST175
LLST200
LLST220
LLST270
LLST300
LLST350
LLST400
LLST450
LLST500
SERIES
4.7
10
15
18
22
25
27
33
47
75
100
125
140
150
175
200
220
270
300
350
400
450
500
LLST HIGH SATURATION CORE
4.00
6.10
50.0
0.035
2.80
4.10
45.0
0.050
2.10
3.20
40.0
0.055
1.90
3.00
35.0
0.060
1.70
2.80
25.0
0.070
1.60
2.60
20.0
0.080
1.40
2.30
15.0
0.080
1.30
2.20
12.0
0.080
1.00
1.80
10.0
0.120
0.80
1.40
8.0
0.180
0.80
1.40
7.0
0.250
0.64
1.10
6.0
0.250
0.56
0.98
5.0
0.250
0.56
0.98
4.0
0.260
0.54
0.90
3.5
0.325
0.46
0.80
3.2
0.400
0.46
0.80
3.0
0.400
0.46
0.78
2.5
0.500
0.38
0.68
2.0
0.500
0.36
0.62
1.9
0.625
0.28
0.50
1.8
0.700
0.28
0.50
1.7
0.850
0.26
0.50
1.5
1.000
2.600
2.250
2.150
2.050
1.900
1.780
1.780
1.780
1.450
1.190
1.000
1.000
1.000
0.985
0.890
0.795
0.795
0.710
0.710
0.650
0.600
0.550
0.500
Millimeters
12.07 ± 0.50
10.67 ± 0.50
7.37 Max.
7.62 Ref.
1.91 Max.
9.53 ± 0.50
*Insert ‘R’ Designator for RoHS
For surface finish information, refer to www.delevanfinishes.com
Material
High Saturation Nickel/Iron Core.
Inductance
Tested at an AC drive level which does not affect the initial
permeability of the core, the DC drive level was 0 amps.
Incremental Current
The DC current which reduces the inductance
value to the percentage drop tabulated.
Inductor Base
Formed from a high temperature thermoplastic capable of
withstanding approx. 600°F for short periods of time.
Marking
API, Inductance, and Date Code.
Operating Temperature Range
–40°C to +125°C
Power Dissipation
0.285 Max. (Watts)
Weight Max.
(Grams) 2.00
Packaging
Bulk only
Current Rating
Based on a 35° C max. rise from 90°C
ambient.
For more detailed graphs, contact factory
